18,000 BTU Mitsubishi GL-Series Single Zone Wall Mount Mini Split Air Handler – R-410A | 230V

18,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone GL - Air Handler
18,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone GL - Air Handler 18,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone GL - Air Handler HVAC Direct
18,000 BTU Mitsubishi GL-Series Single Zone Wall Mount Mini Split Air Handler – R-410A | 230V
By

Mitsubishi

Out of stock
Model

MSY-GL18NA-1

ID

7101

Be the first to review this product
3 Questions Answered
Out of stock

18,000 BTU Mitsubishi GL-Series Single Zone Wall Mount Mini Split Air Handler – R-410A | 230V

The Mitsubishi MSY-GL18NA wall-mounted air handler delivers quiet, efficient comfort as part of Mitsubishi’s GL-Series lineup. Designed for single-zone applications, this unit combines sleek aesthetics with reliable performance to maintain consistent indoor conditions.

Key Features:

  • Slim Wall-Mounted Design: Modern, space-saving appearance that fits easily in most rooms.
  • Efficient Operation: Works with inverter-driven outdoor condensers for balanced energy use.
  • Whisper-Quiet Comfort: Indoor sound levels as low as 31 dB(A) for undisturbed comfort.
  • Air Filtration: Equipped with long-life filters to improve indoor air quality.
  • Automatic Modes: Built-in features include auto restart and swing vane control for optimized airflow.

Specifications:

  • Cooling Capacity: 18,000 BTU/h
  • Heating Capacity: 20,300 BTU/h
  • Power Supply: 208/230V, 1 phase, 60Hz
  • Refrigerant: R-410A
  • Indoor Unit Dimensions: 42-15/16" W x 9-1/8" D x 13-11/16" H
  • Weight: 31 lbs

Certifications:

  • AHRI Certified
  • cETLus Listed
More Information
18,000 BTU Mitsubishi GL-Series Single Zone Wall Mount Mini Split Air Handler – R-410A | 230V
SKUMSY-GL18NA-1
Weight (in lbs)33.000000
Brand/ManufacturerMitsubishi
ControllerWireless Included
Additional InformationDrain: 5/8"
Cooling BTU18,000 BTU
Maximum CFM297-646 CFM
Decibel Level (dBA)28-49
RefrigerantR410A
CapacityDehumidification Rate: 0.32 gal/hr
Liquid Line1/4"
Suction Line1/2"
Electrical208/230v 1 Phase 60 Hz
PhaseSingle Phase
BTU/Tonnage18,000 BTU/1.5 Ton
Mini Split TypeWall Mounted
Zone CompatibilityMulti Zone
Operating ModeCooling
Height12-13/16"
Width35-5/16"
Depth9-3/8"
Warranty10 Years with Online Registration
Resources You will need Adobe® Acrobat® Reader to view PDF documents.
Safety InformationPROPOSITION 65 WARNING
Write Your Own Review
You're reviewing:18,000 BTU Mitsubishi GL-Series Single Zone Wall Mount Mini Split Air Handler – R-410A | 230V
Your Rating
Customer Questions
How much total cost to install and buy this unite?
For installation questions, please reach out to a local installation company in your area for a quote, as we do not install product. If you have any further questions or need further assistance, please feel free to reach out to one of our experienced customer service representative and they would be happy to assist you. Thank you and have a wonderful day.
Read More
what are the dimensions?
Good question. The dimensions of this air handler are 11-5/8’’ H x 31-7/16’’ W x 9-1/8’’ D. If you any further questions, please give us a call.
Read More
how do I determine the size unit I need
As a good rule of thumb, the 18K BTU unit designed for up to 750 sq ft while the 24K BTU unit is designed for up to 1000 sq ft. There are other factors that can affect this, ceiling height, climate etc. For more information pertaining to knowing the right size of unit for your home/business please refer to out website, https://hvacdirect.com/sizing-air-conditioner-and-heater.html If you have any further questions or need further assistance, please feel free to reach out to one of our experienced customer service representative and they would be happy to assist you. Thank you and have a wonderful day.
Read More
Did you find what you were looking for?
Why Choose Mitsubishi Mini Splits?
Why Choose Mitsubishi Mini Splits?

Mitsubishi mini split air conditioners and heat pumps provide exceptional comfort, energy efficiency, and ultra-quiet performance in any climate. Engineered for reliability and precision, these systems offer year-round heating and cooling while reducing energy costs and enhancing indoor air quality.
