PUY-AK12NL - Outdoor Unit for Wall-Mounted Air Conditioning System
The PUY-AK12NL is a high-efficiency outdoor unit designed for use with wall-mounted air conditioning systems. It delivers reliable cooling performance for commercial and residential applications. Below are the key features and specifications of this outdoor unit:
Key Features:
- Blue Fin Coating: An anti-corrosion treatment applied to the heat exchanger's aluminum fins, protecting against corrosion from salt, sulfur, and other airborne contaminants, especially in coastal and industrial areas.
- Continuous Operation: Capable of 24-hour continuous operation in cooling mode, providing consistent comfort around the clock.
- Fast Restart: Quickly resumes operation after power interruptions, minimizing downtime and maintaining comfort.
- High Pressure Protection: Equipped with safeguards to protect the system from high-pressure anomalies, ensuring reliable performance and safe operation.
- INVERTER-Driven Compressor: Adjusts compressor speed according to cooling demands, enhancing energy efficiency and maintaining stable temperatures across a wide range of conditions.
- Low Ambient Cooling: Provides full cooling capacity down to 0°F with the addition of wind baffles, making it suitable for various climates.
- Pre-Charged Refrigerant: The unit is pre-charged with refrigerant for specific line lengths, simplifying installation and reducing setup time. For capacities between 12,000 and 18,000 BTU/h, the unit is pre-charged for up to 165 feet; for capacities between 24,000 and 30,000 BTU/h, up to 225 feet.
- Seacoast Protection: Features a robust anti-corrosion system, including treated external panels and a coated heat exchanger coil, rated for 2,000 hours under ASTM B117 testing standards, ensuring durability in coastal environments.
- Superior Energy Efficiency: Designed to deliver high performance while minimizing energy consumption, contributing to lower operational costs and environmental impact.
Specifications:
- Cooling Capacity at 95°F:
- Maximum Capacity: 12,200 BTU/h
- Rated Capacity: 12,000 BTU/h
- Minimum Capacity: 4,300 BTU/h
- Power Consumption:
- Maximum Power Input: 830 W
- Rated Power Input: 810 W
- Moisture Removal: 3 pints/h
- Energy Efficiency Ratings:
- Electrical Requirements:
- Voltage: 208/230 V AC, Single-phase, 60 Hz
- Guaranteed Voltage Range: 198 - 264 V AC
- Indoor-Outdoor Voltage (S1-S2): 208/230 V AC
- Short-circuit Current Rating (SCCR): 5 kA
- Recommended Outdoor Fuse/Breaker Size: 20 A
- Recommended Wire Size (Indoor to Outdoor): 14 AWG
- Outdoor Unit Dimensions (W x D x H): 34-19/64 x 11-13/16 x 24-13/16 inches (871 x 300 x 630 mm)
- Outdoor Unit Weight: 99 lbs (45 kg)
The PUY-AK12NL outdoor unit is engineered to provide efficient and reliable cooling, making it an excellent choice for maintaining comfortable indoor environments in various commercial and residential settings.
