MXZ-SM36NL - SMART MULTI Hyper-Heating Heat Pump Outdoor Unit
The MXZ-SM36NL is a high-performance outdoor heat pump unit from Mitsubishi Electric's SMART MULTI series, designed for multi-zone applications. Capable of connecting up to four indoor units with a branch box, it offers efficient heating and cooling solutions for residential and light commercial settings, ensuring year-round comfort. Below are the key features and specifications of this model:
Key Features:
- Variable Speed INVERTER-Driven Compressor: Adjusts compressor speed to match heating or cooling demand, optimizing energy efficiency and maintaining consistent indoor temperatures.
- Quiet Operation: Operates at sound pressure levels as low as 49 dB(A), minimizing noise disturbances in your environment.
- Seacoast Protection: Features a heat exchanger and base panel rated for 2,000 hours of protection in accordance with ASTM B117 testing, enhancing durability in coastal regions.
- Comprehensive Protections: Equipped with compressor overcurrent detection, thermal protection, high-pressure protection, and fan motor overheating/voltage protection for enhanced safety and reliability.
- Hyper-Heating Performance: Delivers 100% heating capacity at 5°F and 75% heating capacity at -13°F, ensuring consistent warmth even in extreme cold conditions.
- ENERGY STAR® Certified: Meets ENERGY STAR® standards in non-ducted configurations, promoting energy efficiency and potential cost savings.
Specifications:
- Cooling Capacity at 95°F:
- Maximum Capacity: 36,000 BTU/h
- Rated Capacity: 36,000 BTU/h (Non-Ducted), 36,000 BTU/h (Mixed), 36,000 BTU/h (Ducted)
- Minimum Capacity: 13,000 BTU/h (Non-Ducted), 13,000 BTU/h (Mixed), 13,000 BTU/h (Ducted)
- Heating Capacity at 47°F:
- Maximum Capacity: 41,000 BTU/h
- Rated Capacity: 41,000 BTU/h (Non-Ducted), 41,000 BTU/h (Mixed), 41,000 BTU/h (Ducted)
- Minimum Capacity: 12,600 BTU/h (Non-Ducted), 12,600 BTU/h (Mixed), 12,600 BTU/h (Ducted)
- Heating Capacity at 17°F:
- Maximum Capacity: 36,000 BTU/h
- Rated Capacity: 26,400 BTU/h (Non-Ducted), 26,400 BTU/h (Mixed), 26,600 BTU/h (Ducted)
- Heating Capacity at 5°F:
- Maximum Capacity: 29,000 BTU/h
- Heating Capacity at -13°F:
- Maximum Capacity: 18,600 BTU/h
- Efficiency Ratings:
- SEER2: 23.0 (Non-Ducted), 20.6 (Mixed), 18.2 (Ducted)
- EER2: 14.1 (Non-Ducted), 12.05 (Mixed), 10.0 (Ducted)
- HSPF2 (IV): 11.0 (Non-Ducted), 10.5 (Mixed), 10.0 (Ducted)
- COP at 47°F: 4.0 (Non-Ducted), 3.55 (Mixed), 3.10 (Ducted)
- COP at 17°F (Maximum Capacity): 2.04 (Non-Ducted), 1.92 (Mixed), 1.80 (Ducted)
- COP at 5°F (Maximum Capacity): 2.20 (Non-Ducted), 2.08 (Mixed), 1.98 (Ducted)
- Electrical Requirements:
- Power Supply: 208/230 V AC, Single-phase, 60 Hz
- Guaranteed Voltage Range: 198 - 253 V AC
- Voltage (Indoor to Outdoor, S1-S2): 230 V AC
- Short-circuit Current Rating (SCCR): 5 kA
- Recommended Fuse/Breaker Size if Branch Box Powered by Outdoor Unit: 40 A
- Recommended Fuse/Breaker Size without Branch Box or Branch Box Powered Separate: 30 A
- Minimum Circuit Ampacity (MCA) if Branch Box Powered by Outdoor Unit: 42 A
- Maximum Overcurrent Protection (MOCP) if Branch Box Powered by Outdoor Unit: 70 A
- Minimum Circuit Ampacity (MCA) without Branch Box or Branch Box Powered Separate: 36 A
- Maximum Overcurrent Protection (MOCP) without Branch Box or Branch Box Powered Separate: 64 A
- Outdoor Unit Dimensions:
- Width: 41-17/48 inches
- Depth: 13 inches
- Height: 52-11/16 inches
- Weight: 276 lbs
The MXZ-SM36NL is ideal for applications requiring efficient heating and cooling performance across multiple zones. Its advanced features ensure reliable operation and enhanced comfort throughout the year.
