AHRI Number:211717295
The Stealth central ducted air handlers provide quiet power to move conditioned air throughout your home with maximum efficiency.
Quick Facts
Please note: This air handler must be connected to an outdoor condenser in order to function.
The Stealth central ducted condensers' integrated inverter compressor ensures maximum efficiency by adjusting system BTU output and fan speed to precisely match demand. This functionality happens in both heating and cooling modes. Max Heat technology extends the heat pump operating range down to -22°F outside temperature. With up to a 17 SEER2 rating, these Stealth Central Ducted condensers give you better performance and more features than any other brand.
Max Heat Technology is extended heat pump performance. A secondary benefit of a self-adjusting compressor is the ability to speed or slow refrigerant and air flow at the outside unit - maximizing heat extraction. Older, traditional heat pumps stop working below 30°F, but the Stealth Heat Pump Condenser keeps you comfortable in any weather.
These Stealth condensers are designed with your ultimate comfort in mind. Experience unparalleled flexibility as these innovative condensers can be easily configured to operate at both 24k and 36k capacities, seamlessly adapting to your specific requirements when coupled with the corresponding air handlers. Your comfort, your choice.
Rugged construction and an acrylic resin gold fin coating on the outside condenser coil adds up to a long, trouble-free service life. The inside evaporator has blue fin coating protection and a sturdy 8-speed fan. Precision engineering is behind every Stealth central ducted model, resulting in powerful performance across a punishing range of conditions.
Every Stealth central ducted condenser has a slim, horizontal discharge design, ideal for close lot-line installations. Outside noise level is no more than 55 dBa max, equivalent to a dishwasher. The indoor unit fan has 8 speeds, for near-silent operation. Give your home complete comfort at maximum efficiency with a Stealth central ducted heat pump system.
The Stealth central ducted condensers features a 14-year compressor/5-year parts warranty with online registration. Without registering the warranty, you are still protected by the standard 7-year compressor/5-year parts warranty.
Designed for residential, commercial, and industrial applications, the Cielo Smart Thermostat is the perfect blend of cutting-edge technology and user convenience, allowing home and business owners to create comfortable and energy-efficient living and working environments.
| Stealth 4 Ton 18 SEER Ducted Central Air Inverter Heat Pump Split System | Max Heat | |
|---|---|
| SKU | SC-4860-HP / SC-48-AH |
| AHRI Certificate Number | 211717295 |
| Brand/Manufacturer | Stealth |
| Electric Heat | Heat Pump |
| Tonnage | 4 Ton |
| System Tonnage | 4 Ton |
| BTU/Tonnage | 48,000 BTU/4 Ton |
| Warranty | 14 year compressor, 5 year parts with online registration |
| Resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
| Safety Information | PROPOSITION 65 WARNING |
| 4 Ton Stealth Central Air Handler | |
| SKU | SC-48-AH |
| Refrigerant Charge | 25' |
| Weight (in lbs) | 127.430000 |
| Brand/Manufacturer | Stealth |
| HSPF | 11 |
| Cooling BTU | 22000 BTU |
| Heating BTU | 27000 BTU |
| Maximum CFM | 882 |
| Decibel Level (dBA) | 43 |
| Electric Heat | Heat Pump |
| Electric Backup Heat Capabilities (Optional) | 5 Kilowatts, 10 Kilowatts |
| Energy Star | Yes |
| Refrigerant | R410A |
| SEER1 (Efficiency) | 18-20 |
| EER | 12.5 |
| Liquid Line | 3/8" |
| Suction Line | 3/4" |
| Electrical | 208/230V 1 Phase 60 Hz |
| Max Breaker Size | 15 |
| Min. Breaker Size | 4 |
| Tonnage | 4 Ton |
| BTU/Tonnage | 48,000 BTU/4 Ton |
| Mini-Split Type | Multi-Positional |
| Zone Compatibility | Single Zone |
| Height | 45" |
| Width | 21.02" |
| Depth | 17.52" |
| Warranty | 14 year compressor, 5 year parts with online registration |
| Resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
| Safety Information | PROPOSITION 65 WARNING |
| 4-5 Ton 18 SEER Stealth Central Heat & Air Inverter Condenser | Max Heat | |
| SKU | SC-4860-HP |
| Refrigerant Charge | 31' |
| Weight (in lbs) | 308.000000 |
| Brand/Manufacturer | Stealth |
| HSPF | 10.5 |
| HSPF2 | 9 |
| Cooling BTU | Min: 35,000 BTU | Max: 54,000 BTU |
| Heating BTU | Min: 35,000 BTU | Max: 60,000 BTU |
| Decibel Level (dBA) | 58 Max |
| Electric Heat | Heat Pump |
| Refrigerant | R410A |
| SEER1 (Efficiency) | 18 |
| SEER2 (Efficiency) | 17 |
| Compressor Type | Rotary |
| Liquid Line | 3/8" |
| Suction Line | 3/4" |
| Electrical | 208/230V 1 Phase 60 Hz |
| Max Breaker Size | 45 Amps |
| Min. Breaker Size | 35 Amps |
| Tonnage | 5 Ton |
| BTU/Tonnage | 55,000 BTU/4.5 Ton |
| Mini-Split Type | Multi-Positional |
| Min/Max Outdoor Temp for Heating | -22°F～75°F |
| Min/Max Outdoor Temp for Cooling | 5°F～122°F |
| Ambient Temperature Range | -22°F～122°F |
| Height | 53.63" |
| Width | 39.38" |
| Depth | 14.5" |
| Warranty | 14 year compressor, 5 year parts with online registration |
| Resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
| Safety Information | PROPOSITION 65 WARNING |
| Cielo Smart Thermostat | |
| SKU | CT101WA |
| Weight (in lbs) | 0.500000 |
| Brand/Manufacturer | Cielo |
| Included Items | Thermostat, Thermostat Back Plate, Thermostat Wall Plate, C-Wire Adapter, Install Guide, Wire Labels, Screws, and Anchors |
| Energy Star | Yes |
| Warranty | 3 Year Warranty Against Defects |
| Resources | |
| Safety Information | PROPOSITION 65 WARNING |
