Mitsubishi 48,000 BTU SEZ-AD-Series Multi Zone Mini Split Heat Pump Condenser R454B | 230V

MXZ-SM48NL - SMART MULTI Hyper-Heating Heat Pump Outdoor Unit

The MXZ-SM48NL is a high-performance outdoor heat pump unit from Mitsubishi Electric's SMART MULTI series, designed for multi-zone applications. Capable of connecting up to eight indoor units when used with M- and P-Series, or up to twelve units with CITY MULTI indoor units, it offers flexible heating and cooling solutions for both residential and light commercial settings, ensuring year-round comfort. Below are the key features and specifications of this model:

Key Features:

• Variable Speed INVERTER-Driven Compressor: Adjusts compressor speed to match heating or cooling demand, optimizing energy efficiency and maintaining consistent indoor temperatures.
• Quiet Operation: Operates at sound pressure levels as low as 51 dB(A) during cooling and 54 dB(A) during heating, minimizing noise disturbances in your environment.
• Seacoast Protection: Features a heat exchanger and base panel rated for 2,000 hours of protection in accordance with ASTM B117 testing, enhancing durability in coastal regions.
• Comprehensive Protections: Equipped with compressor overcurrent detection, thermal protection, high-pressure protection, and fan motor overheating/voltage protection for enhanced safety and reliability.
• Hyper-Heating Performance: Delivers 100% heating capacity at 5°F and 75% heating capacity at -13°F, ensuring consistent warmth even in extreme cold conditions.
• ENERGY STAR® Certified: Meets ENERGY STAR® standards in non-ducted configurations, promoting energy efficiency and potential cost savings.

Specifications:

• Cooling Capacity at 95°F:
  • Maximum Capacity: 48,000 BTU/h
  • Rated Capacity: 48,000 BTU/h (Non-Ducted), 48,000 BTU/h (Mixed), 48,000 BTU/h (Ducted)
  • Minimum Capacity: 15,000 BTU/h (Non-Ducted), 15,000 BTU/h (Mixed), 15,000 BTU/h (Ducted)
• Heating Capacity at 47°F:
  • Maximum Capacity: 50,000 BTU/h
  • Rated Capacity: 50,000 BTU/h (Non-Ducted), 50,000 BTU/h (Mixed), 50,000 BTU/h (Ducted)
  • Minimum Capacity: 13,000 BTU/h (Non-Ducted), 13,000 BTU/h (Mixed), 13,000 BTU/h (Ducted)
• Heating Capacity at 17°F:
  • Maximum Capacity: 43,000 BTU/h
  • Rated Capacity: 31,400 BTU/h (Non-Ducted), 32,400 BTU/h (Mixed), 33,400 BTU/h (Ducted)
• Heating Capacity at 5°F:
  • Maximum Capacity: 35,400 BTU/h
• Heating Capacity at -13°F:
  • Maximum Capacity: 22,800 BTU/h
• Efficiency Ratings:
  • SEER2: 23.0 (Non-Ducted), 20.0 (Mixed), 17.0 (Ducted)
  • EER2: 12.0 (Non-Ducted), 10.2 (Mixed), 8.4 (Ducted)
  • HSPF2 (IV): 10.4 (Non-Ducted), 9.95 (Mixed), 9.5 (Ducted)
  • COP at 47°F: 4.0 (Non-Ducted), 3.55 (Mixed), 3.10 (Ducted)
  • COP at 17°F (Maximum Capacity): 2.0 (Non-Ducted), 1.88 (Mixed), 1.76 (Ducted)
  • COP at 5°F (Maximum Capacity): 2.10 (Non-Ducted), 2.02 (Mixed), 1.96 (Ducted)
• Electrical Requirements:
  • Power Supply: 208/230 V AC, Single-phase, 60 Hz
  • Guaranteed Voltage Range: 198 - 253 V AC
  • Voltage (Indoor to Outdoor, S1-S2): 230 V AC
  • Short-circuit Current Rating (SCCR): 5 kA
  • Recommended Fuse/Breaker Size if Branch Box Powered by Outdoor Unit: 40 A
  • Recommended Fuse/Breaker Size without Branch Box or Branch Box Powered Separate: 30 A
  • Minimum Circuit Ampacity (MCA) if Branch Box Powered by Outdoor Unit: 42 A
  • Maximum Overcurrent Protection (MOCP) if Branch Box Powered by Outdoor Unit: 70 A
  • Minimum Circuit Ampacity (MCA) without Branch Box or Branch Box Powered Separate: 36 A
  • Maximum Overcurrent Protection (MOCP) without Branch Box or Branch Box Powered Separate: 64 A
• Outdoor Unit Dimensions:
  • Width: 41-17/32 inches
  • Depth: 13 inches
  • Height: 52-11/16 inches
  • Weight: 278 lbs

The MXZ-SM48NL is ideal for applications requiring efficient heating and cooling performance across multiple zones. Its advanced features ensure reliable operation and enhanced comfort throughout the year.
