AirRex 1.0 Ton 13,600 BTU Portable Heat Pump Cooling & Heating | 115V - R454B

Year-Round Heating & Cooling 13,600 BTU Portable Heat Pump for Commercial & Industrial Applications with Flexible Mobility

The Airrex AHSC-14R is a 13,600 BTU cooling and 15,000 BTU heating portable heat pump designed to provide supplemental heating and cooling for commercial, industrial, and temporary work environments. Combining compact heating and cooling performance with reversible heat pump technology, this self-contained heating and cooling system provides year-round temperature control while offering flexible placement and easy relocation between work areas.

Key Benefits

• Heating & Cooling Performance – Provides 13,600 BTU of cooling and 15,000 BTU of heating for flexible supplemental temperature control.
• Reversible Heat Pump Technology – Provides both heating and cooling from a single portable unit, reducing the need for separate seasonal equipment.
• Mobile Portable Design – Four swivel casters, including two locking casters, allow the unit to be moved and positioned where conditioned air is needed.
• Adjustable Airflow – A directional discharge louver allows conditioned air to be directed upward, downward, left, or right toward the intended area.
• Flexible Installation – A self-contained design and standard 115V electrical connection support deployment in suitable locations without permanent HVAC installation.
• Condensate Management – An integrated 5-gallon condensate tank with automatic shutoff helps manage collected moisture during operation.
• Digital Controls & Electrical Protection – Digital temperature controls, adjustable fan speeds, programmable timer functions, and an LCDI-protected power cord support convenient operation.
• Service & Maintenance – Removable, washable air filters simplify routine maintenance, while compressor protection features help safeguard equipment operation.

13,000 BTU Heating Performance for Supplemental Temperature Control

The Airrex AHSC-14R provides 15,000 BTU of heating capacity to help maintain comfortable temperatures in suitable commercial and industrial environments. Its specified heating operating range is 46°F to 81°F, allowing the unit to provide supplemental warmth when ambient conditions require additional temperature control. Reversible heat pump operation enables the system to transfer heat to the conditioned space without relying solely on conventional resistance heating.

13,600 BTU Cooling Performance for Commercial & Industrial Spaces

The Airrex AHSC-14R provides 13,600 BTU of cooling capacity to help maintain comfortable temperatures during warmer conditions. Its specified cooling operating range is 61°F to 115°F. The portable system is intended for supplemental and spot cooling applications where localized temperature control is required. A directional air outlet helps deliver conditioned air toward the target area, while the integrated fan circulates air through the unit during operation.

Reversible Heat Pump Technology for Year-Round Operation

The Airrex AHSC-14R uses reversible heat pump technology with a four-way reversing valve to provide both heating and cooling from a single portable system. In cooling mode, the refrigeration cycle removes heat from the conditioned space. In heating mode, the cycle reverses to deliver warm air. The unit also includes a dehumidification mode for moisture removal when operating conditions are suitable. This integrated approach allows the unit to provide seasonal temperature control without requiring separate portable heating and cooling equipment.

Directional Airflow for Targeted Temperature Control

The Airrex AHSC-14R incorporates an adjustable discharge louver that allows conditioned air to be directed upward, downward, left, or right. High and low fan-speed settings provide flexibility for different operating conditions and airflow preferences. This directional airflow capability supports spot conditioning by helping deliver heated or cooled air toward specific work areas, equipment, or occupied zones.

Portable Design for Flexible Installation & Deployment

The self-contained portable design allows the Airrex AHSC-14R to be positioned where supplemental heating or cooling is needed without requiring a permanent HVAC installation. Its cabinet measures approximately 22 inches wide, 25 inches deep, and 49 inches high. Four 4-inch swivel casters, including two locking casters, support transportation and positioning. The unit features a 12-inch-diameter top hot-air exhaust outlet and requires appropriate heat-rejection arrangements and fresh-air supply for proper operation. An optional ceiling-tile exhaust kit is available for compatible installations. The unit requires a 115V, single-phase electrical supply.

Integrated Condensate Management for Moisture Control

The Airrex AHSC-14R incorporates an internal condensate collection tank with a 5-gallon capacity and an automatic shutoff function to help manage moisture generated during operation. The automatic shutoff helps prevent continued operation when the tank reaches its operating limit. An optional compatible condensate pump is available for installations that require automatic condensate removal and reduced manual tank-emptying requirements.

Digital Controls, Comfort Settings & Electrical Connection

The Airrex AHSC-14R features a digital controller for temperature selection and operating-mode adjustment. Its controls support heating and cooling operation, high and low fan speeds, programmable timer functions, and a temperature setting range of 64°F to 86°F. The unit operates on a 115V, single-phase, 60Hz electrical supply and is equipped with a 10-foot, 14 AWG, three-core LCDI-protected power cord with a NEMA 5-15P plug. A 15-amp circuit is recommended. Electrical installation must comply with the applicable electrical codes and the manufacturer's instructions. The unit also incorporates compressor protection with high- and low-pressure warnings and a compressor delay function.

Commercial & Industrial Applications for Supplemental HVAC

The Airrex AHSC-14R is designed for commercial and industrial environments that require flexible, localized heating and cooling. Suitable applications may include workshops, manufacturing facilities, maintenance areas, server rooms, equipment rooms, temporary work areas, and other spaces requiring supplemental temperature control. Its portable construction and reversible heat pump operation make it useful for locations where permanent HVAC modifications are impractical or where seasonal conditioning requirements change. Proper application sizing, exhaust arrangements, fresh-air supply, and operating conditions should be evaluated before installation.

Mobility & Flexible Deployment Between Work Areas

The Airrex AHSC-14R features four swivel casters, two of which are locking, to facilitate movement and positioning on suitable level surfaces. Its compact vertical cabinet allows the unit to be deployed in different work areas as heating and cooling requirements change. The locking casters help secure the unit in position during operation. Before relocating the equipment, follow the manufacturer's instructions for shutdown, condensate management, and safe movement.

Service & Maintenance for Reliable Operation

The Airrex AHSC-14R includes removable, washable air filters to simplify routine cleaning and help maintain airflow. Regular filter inspection and cleaning are important for maintaining performance. The unit's compressor protection system includes high- and low-pressure warnings and switches, as well as a delay timer to help protect the refrigeration system. The internal condensate tank should be monitored and emptied as required unless a compatible condensate pump is installed. Perform maintenance and troubleshooting in accordance with the manufacturer's operating manual.

Warranty

The Airrex AHSC-14R is listed with a one-year limited warranty and a three-year compressor warranty. Coverage, exclusions, registration requirements, and other applicable conditions are subject to the manufacturer's written warranty documentation. Review the applicable warranty terms before installation and operation.

Recommended Accessories

• 12-Inch Ceiling Tile Exhaust Kit – Optional kit with a 12-inch-diameter exhaust duct and compatible ceiling tile for suitable installations.
• 115V Condensate Pump – Optional accessory for compatible condensate removal installations.
• Compatible Exhaust Ducting – Use manufacturer-approved or confirmed-compatible ducting and installation components as required by the application.
• Replacement Air Filters – Use compatible replacement filters when the original filters require replacement.

Flexible Year-Round Temperature Control with the Airrex AHSC-14R

Experience flexible supplemental heating and cooling with the Airrex AHSC-14R portable heat pump. Combining 13,600 BTU of cooling capacity and 15,000 BTU of heating capacity with reversible heat pump technology, directional airflow, and a mobile cabinet, this portable system provides year-round temperature control for commercial and industrial work areas requiring localized conditioning.

No Return Policy

All AirRex commercial unit sales are final and are non-refundable.
