AirRex 5 Ton 60,000 BTU Portable Heat Pump | 220V - R410A

High-Capacity 60,000 BTU Heating & Cooling Portable Heat Pump for Commercial & Industrial Applications with Ducted Air Distribution

The Airrex AHSC-60 220/1 is a 60,000 BTU cooling and 60,000 BTU heating portable heat pump designed to provide high-capacity supplemental heating, cooling, and dehumidification for commercial and industrial environments. Combining 5-ton heating and cooling capacity with reversible heat pump technology and ducted air distribution, this self-contained climate control system provides year-round temperature management while offering flexible deployment in suitable applications. Designed for demanding workspaces, the AHSC-60 provides a portable alternative to permanent HVAC installations where high-capacity temperature control is required.

Key Benefits

• High-Capacity Heating & Cooling Performance – Provides 60,000 BTU of cooling and 60,000 BTU of heating capacity for large commercial and industrial spaces.
• Reversible Heat Pump Technology – Delivers heating and cooling from a single integrated system to support year-round temperature management.
• Portable Heavy-Duty Construction – Integrated handles and caster wheels support positioning and relocation between suitable work areas.
• Ducted Air Distribution – Separate 12-inch supply and 16-inch return duct connections support targeted conditioning and flexible installation arrangements.
• Flexible Installation – A self-contained design supports temporary and supplemental HVAC applications when ducting, ventilation, and clearances meet manufacturer requirements.
• High-Capacity Dehumidification – Removes up to 77 gallons of moisture per day under specified maximum test conditions to help manage humidity in demanding environments.
• Digital Controls & Electrical Connection – Digital operating controls and a 220V single-phase electrical supply support commercial climate-control applications.
• Service & Maintenance – Removable, washable aluminum and stainless-steel mesh filters and built-in compressor protection features support routine maintenance.

60,000 BTU Heating Performance for Commercial & Industrial Spaces

The Airrex AHSC-60 220/1 provides 60,000 BTU/h (17.6 kW) of heating capacity to help maintain comfortable temperatures in suitable commercial and industrial environments. Its specified heating operating range is 50°F to 81°F, subject to the manufacturer's stated ambient temperature and humidity conditions. Reversible heat pump operation transfers heat into the conditioned space, providing supplemental heating for workshops, warehouses, manufacturing facilities, equipment areas, and temporary workspaces. Actual heating performance depends on ambient conditions, installation configuration, and the thermal load of the conditioned space.

60,000 BTU Cooling Performance for Large Commercial Areas

The Airrex AHSC-60 220/1 provides 60,000 BTU/h (17.6 kW) of cooling capacity, equivalent to approximately 5 tons, for high-capacity supplemental cooling. Its specified cooling operating range is 65°F to 113°F. The unit is intended for applications requiring substantial cooling capacity, including industrial work areas, equipment rooms, and temporary commercial spaces. Actual cooling performance depends on ambient temperature, insulation, ceiling height, equipment heat loads, ventilation, and duct configuration. Correct duct sizing and routing are essential for maintaining airflow and system performance.

Reversible Heat Pump Technology with R-410A Refrigerant

The Airrex AHSC-60 220/1 uses reversible heat pump technology to provide both heating and cooling from a single portable system. In cooling mode, the refrigeration cycle removes heat from the conditioned space. In heating mode, the cycle reverses to deliver warm air. The system also provides a dedicated dehumidification mode for moisture removal. The AHSC-60 220/1 uses R-410A refrigerant, with a listed refrigerant charge of approximately 6.62 lb. This integrated approach provides year-round temperature control without requiring separate portable heating and cooling equipment. Refrigerant servicing must be performed by qualified personnel using appropriate procedures and equipment.

Ducted Airflow & Distribution for Targeted Conditioning

The Airrex AHSC-60 220/1 incorporates separate supply and return air connections for flexible conditioned-air delivery and circulation. The indoor centrifugal fan provides a rated airflow of approximately 1,620 CFM for cooling, heating, and dehumidification. The system uses one 12-inch supply duct connection and one 16-inch return duct connection, with a maximum external static pressure of 0.9 inches of water column and a maximum equivalent duct length of 65 feet. The outdoor axial fan provides approximately 3,240 CFM of airflow. These features support ducted installation arrangements in commercial and industrial environments. Duct lengths, routing, clearances, and ventilation must follow the manufacturer's installation requirements to maintain appropriate airflow and operating performance.

Portable Design for Flexible Installation & Deployment

The Airrex AHSC-60 220/1 features a heavy-duty cabinet designed for portable commercial and industrial applications. Published specifications list approximate dimensions of 29.1 inches wide by 57.1 inches deep by 50.7 inches high, with a net weight of approximately 586 lb. Integrated handles and caster wheels support positioning on suitable surfaces. Separate duct connections allow conditioned air to be routed toward the intended space while supporting flexible equipment placement. The unit requires a 220V, 60Hz, single-phase electrical supply. Due to its substantial weight, relocation requires appropriate handling equipment and safe movement procedures. Confirm site access, floor loading, clearances, and duct routing before installation.

Integrated Dehumidification for Moisture Control

The Airrex AHSC-60 220/1 incorporates a dedicated dehumidification mode to help manage excess moisture in commercial and industrial environments. Published specifications identify maximum moisture removal of up to 77 gallons per day at 89°F and 80% relative humidity, with nominal moisture removal of approximately 53 gallons per day at 80°F and 60% relative humidity. Actual moisture removal varies with ambient temperature, humidity, airflow, and operating conditions. The specified dehumidification operating range is 59°F to 113°F. An optional condensate pump is available for compatible installations requiring continuous condensate removal. Drainage arrangements must be configured according to the manufacturer's instructions.

Digital Controls, Comfort Settings & Electrical Connection

The Airrex AHSC-60 220/1 features a digital controller with temperature adjustment, cooling, heating, fan, and dehumidification modes, as well as an off-timer function. The display indicates room temperature and configured operating settings. The unit operates on a 220V AC, 60Hz, single-phase electrical supply. Published specifications identify power consumption of 7.2 kW during cooling and 7.0 kW during heating, with current consumption of 33.7 amps during cooling and 42.3 amps during heating. The specified circuit breaker rating is 60 amps, and the acceptable voltage range is 187V to 242V. The unit does not use a standard factory power cord or NEMA plug in this configuration. Electrical connections, conductors, disconnect equipment, and overcurrent protection must be selected in accordance with the manufacturer's wiring diagram, equipment nameplate, and applicable electrical codes. Installation must be performed by qualified personnel.

Commercial & Industrial Applications for Supplemental HVAC

The Airrex AHSC-60 220/1 is designed for commercial and industrial environments requiring high-capacity portable heating, cooling, and dehumidification. Potential applications include warehouses, manufacturing facilities, workshops, maintenance areas, equipment rooms, production spaces, temporary work areas, and other locations requiring supplemental HVAC. Its 60,000 BTU heating and cooling capacities, ducted air distribution, and portable construction make it suitable for applications where permanent HVAC installation is impractical or temporary conditioning is required. Proper application sizing, electrical capacity, duct routing, ventilation, ambient operating conditions, and condensate management should be evaluated before deployment.

Mobility & Flexible Deployment Between Work Areas

The Airrex AHSC-60 220/1 is designed for deployment in different commercial and industrial work areas as temperature-control requirements change. Its cabinet incorporates handles and caster wheels to support positioning on suitable surfaces, while the separate duct connections allow conditioned air to be directed toward the intended space. Given the unit's approximate 586 lb weight, relocation requires appropriate handling equipment and safe movement procedures. Secure the equipment in its operating position and follow the manufacturer's instructions for shutdown, duct disconnection, transportation, and repositioning.

Service & Maintenance for Reliable Operation

The Airrex AHSC-60 220/1 includes removable aluminum and stainless-steel mesh air filters to simplify routine cleaning and help maintain airflow. Regular filter inspection and cleaning are important for maintaining system performance. Built-in protection features include high- and low-pressure switches, a three-minute compressor delay timer, compressor thermostat protection, and fan motor protection. The control panel includes an error indicator to alert users to certain operating faults. Condensate drainage components should be inspected regularly, and any optional condensate pump should be maintained according to its manufacturer's instructions. Refrigeration-system servicing, electrical repairs, and internal component maintenance should be performed by qualified service personnel in accordance with the applicable installation and operating manual.

Warranty

The Airrex AHSC-60 220/1 is supplied with warranty coverage subject to the manufacturer's written warranty terms. The applicable warranty period, coverage, exclusions, proof-of-purchase requirements, and service conditions should be confirmed using the warranty documentation provided with the purchased unit. Retain purchase records and follow the manufacturer's procedures when requesting warranty service.

Recommended Accessories

• 12-Inch Flexible Supply Duct – Compatible ducting for conditioned-air delivery; verify the required length and connection configuration.
• 16-Inch Flexible Return Duct – Compatible ducting for return-air circulation; confirm the appropriate duct length and installation requirements.
• External Condensate Pump – Optional accessory for compatible installations requiring automatic condensate removal.
• Replacement Washable Air Filters – Compatible replacement aluminum and stainless-steel mesh filters for routine maintenance when required.
• Compatible Duct Adapters and Installation Components – Verify duct dimensions and accessory compatibility against the manufacturer's installation documentation before ordering.

High-Capacity Year-Round Climate Control with the Airrex AHSC-60 220/1

Experience flexible commercial and industrial climate control with the Airrex AHSC-60 220/1 portable heat pump. Combining 60,000 BTU of cooling capacity and 60,000 BTU of heating capacity with reversible heat pump technology, R-410A refrigerant, ducted air distribution, and integrated dehumidification, this heavy-duty portable system provides year-round temperature management for commercial and industrial work areas requiring high-capacity supplemental HVAC performance.

No Return Policy

All AirRex commercial unit sales are final and are non-refundable.
