AirRex 5 Ton 60,000 BTU Portable Heat Pump | 220V - R454B

High-Capacity 60,000 BTU Cooling & Heating Portable Heat Pump for Commercial & Industrial Applications with R-454B Refrigerant

The Airrex AHSC-60R 220/1 is a 60,000 BTU cooling and 60,000 BTU heating portable heat pump designed to provide high-capacity supplemental heating, cooling, and dehumidification for commercial and industrial environments. Combining 5-ton heating and cooling performance with reversible heat pump technology, ducted air distribution, and R-454B refrigerant, this self-contained climate control system provides year-round temperature management while offering flexible deployment for indoor and outdoor applications. With a rated coverage area of up to 2,000 square feet under suitable conditions, the AHSC-60R provides a portable solution for large workspaces that require substantial heating and cooling capacity.

Key Benefits

• High-Capacity Heating & Cooling Performance – Provides 60,000 BTU of cooling and 60,000 BTU of heating capacity for large commercial and industrial spaces.
• Reversible Heat Pump Technology – Delivers both heating and cooling from a single integrated system for year-round temperature control.
• Heavy-Duty Portable Construction – A rugged cabinet and mobility features support positioning and relocation between suitable work areas.
• Ducted Air Distribution – Separate 16-inch supply and return duct connections support targeted conditioning and flexible installation configurations.
• Indoor & Outdoor Deployment – Supports different installation arrangements when ducting, ventilation, clearances, and operating conditions meet manufacturer requirements.
• High-Capacity Dehumidification – Provides up to 76 gallons per day of moisture removal under specified maximum test conditions to help manage humidity in demanding environments.
• Commercial Electrical Connection – The 220V, single-phase configuration supports high-capacity portable climate control in facilities with an appropriately rated electrical supply.
• Service & Maintenance – Removable, washable mesh air filters and built-in compressor protection features support routine maintenance and equipment protection.

60,000 BTU Heating Performance for Commercial & Industrial Spaces

The Airrex AHSC-60R 220/1 provides 60,000 BTU/h of heating capacity to help maintain comfortable temperatures in suitable commercial and industrial environments. Its specified heating operating range is 50°F to 81°F, subject to the manufacturer's stated ambient temperature and humidity conditions. Reversible heat pump operation transfers heat into the conditioned space, providing supplemental heating for warehouses, manufacturing facilities, equipment areas, workshops, and temporary workspaces. Actual heating performance depends on ambient conditions, installation configuration, and the thermal load of the conditioned space.

60,000 BTU Cooling Performance for Large Commercial Areas

The Airrex AHSC-60R 220/1 provides 60,000 BTU/h of cooling capacity, equivalent to approximately 5 tons, for high-capacity supplemental cooling. Its specified cooling operating range is 65°F to 118°F. The unit is rated for spaces up to approximately 2,000 square feet under suitable conditions, although actual coverage depends on insulation, ceiling height, equipment heat loads, outdoor temperatures, ventilation, and duct configuration. Ducted air distribution supports delivery of conditioned air to the target area while allowing flexible equipment placement. Correct duct sizing and routing are essential for maintaining intended airflow and system performance.

Reversible Heat Pump Technology with R-454B Refrigerant

The Airrex AHSC-60R 220/1 uses reversible heat pump technology to provide both heating and cooling from a single portable system. In cooling mode, the refrigeration cycle removes heat from the conditioned space. In heating mode, the cycle reverses to deliver warm air. The system also provides a dedicated dehumidification mode for moisture removal. The AHSC-60R uses R-454B refrigerant, a lower-global-warming-potential alternative to R-410A. This integrated approach provides year-round temperature control without requiring separate portable heating and cooling equipment. Refrigerant servicing must be performed by qualified personnel using procedures and equipment appropriate for R-454B.

Ducted Airflow & Distribution for Targeted Conditioning

The Airrex AHSC-60R 220/1 incorporates separate supply and return air connections for flexible conditioned-air delivery and circulation. The system uses one 16-inch supply duct and one 16-inch return duct. Its centrifugal indoor fan provides rated airflow of approximately 1,950 CFM, while the outdoor axial fan provides approximately 3,240 CFM. The unit is specified for a maximum external static pressure of 0.9 inches of water column and a maximum equivalent duct length of 65 feet for the applicable indoor duct configuration. These features support ducted installation arrangements in commercial and industrial environments. Duct lengths, routing, clearances, and any required fresh-air supply must follow the manufacturer's installation requirements to maintain appropriate airflow and operating performance.

Portable Design for Flexible Installation & Deployment

The Airrex AHSC-60R 220/1 features a heavy-duty cabinet designed for portable commercial and industrial applications. Published product specifications list approximate dimensions of 29 inches wide by 57 inches deep by 51 inches high, with a net weight of approximately 586 pounds. Its portable construction supports deployment in suitable indoor and outdoor configurations when installed according to manufacturer requirements. Separate duct connections allow conditioned air to be routed to the intended space while supporting flexible equipment placement. Due to the unit's substantial weight, relocation requires appropriate handling equipment and safe movement procedures. Confirm site access, floor loading, clearances, and duct routing before installation.

Integrated Dehumidification for Moisture Control

The Airrex AHSC-60R 220/1 incorporates a dedicated dehumidification mode to help manage excess moisture in commercial and industrial environments. Published specifications identify maximum moisture removal of up to 76 gallons per day at 89°F and 80% relative humidity, with nominal moisture removal of approximately 54 gallons per day at 80°F and 60% relative humidity. Actual moisture removal varies with ambient temperature, humidity, airflow, and operating conditions. The specified dehumidification operating range is 59°F to 118°F. An optional external condensate pump is available for compatible installations requiring continuous condensate removal. Drainage arrangements must be configured according to the manufacturer's instructions.

Controls, Safety Features & Electrical Connection

The Airrex AHSC-60R 220/1 includes operating controls for selecting heating, cooling, and dehumidification functions. Built-in safety devices include high- and low-pressure switches, compressor thermostat protection, fan motor protection, and a three-minute compressor delay timer. The unit operates on a 220V, 60Hz, single-phase electrical supply. Published specifications identify power consumption of 5.68 kW during cooling and 5.6 kW during heating, with current consumption of 26.0 amps during cooling and 25.8 amps during heating. The specified circuit breaker rating is 50 amps, and the minimum-to-maximum operating voltage range is 187V to 242V. The unit does not use a standard factory power cord or NEMA plug in this configuration; the electrical connection must follow the manufacturer's wiring diagram and installation manual. Verify the equipment nameplate, required conductor sizing, overcurrent protection, and disconnect requirements before installation. All electrical work must comply with applicable codes and be performed by qualified personnel.

Commercial & Industrial Applications for Supplemental HVAC

The Airrex AHSC-60R 220/1 is designed for commercial and industrial environments requiring high-capacity portable heating, cooling, and dehumidification. Potential applications include warehouses, manufacturing facilities, workshops, maintenance areas, equipment rooms, production spaces, temporary work areas, and other large environments requiring supplemental HVAC. Its 60,000 BTU heating and cooling capacities, ducted air distribution, and portable construction make it suitable for applications where permanent HVAC installation is impractical or temporary conditioning is required. Proper application sizing, electrical capacity, duct routing, ventilation, ambient operating conditions, and condensate management should be evaluated before deployment.

Mobility & Flexible Deployment Between Work Areas

The Airrex AHSC-60R 220/1 is designed for deployment in different commercial and industrial work areas as temperature-control requirements change. Its heavy-duty construction supports demanding applications, while separate duct connections allow conditioned air to be directed toward the intended space. Given the unit's approximate 586-pound weight, relocation requires appropriate handling equipment and safe movement procedures. Secure the unit in its operating position and follow the manufacturer's instructions for shutdown, duct disconnection, transportation, and repositioning.

Service & Maintenance for Reliable Operation

The Airrex AHSC-60R 220/1 includes removable aluminum and stainless-steel mesh air filters to simplify routine cleaning and help maintain airflow. Regular filter inspection and cleaning are important for maintaining system performance. Built-in protection features include high- and low-pressure switches, compressor thermostat protection, a three-minute delay timer, and fan motor protection. Condensate drainage components should be inspected regularly, and any optional external condensate pump should be maintained according to its manufacturer's instructions. Refrigeration-system servicing, electrical repairs, and internal component maintenance should be performed by qualified service personnel in accordance with the applicable installation and operating manual.

Warranty

The Airrex AHSC-60R 220/1 is covered by the manufacturer's applicable written warranty. Warranty duration, compressor coverage, exclusions, service requirements, and other applicable conditions must be confirmed using the warranty documentation supplied for the purchased unit. Retain proof of purchase and follow the manufacturer's warranty procedures.

Recommended Accessories

• 16-Inch Flexible Supply Duct – Optional flexible ducting for conditioned-air delivery; verify compatible length and connection requirements for the AHSC-60R 220/1.
• 16-Inch Flexible Return Duct – Optional flexible ducting for return-air circulation; confirm compatible duct length and installation requirements.
• Top Exhaust Reducer – Optional accessory for compatible exhaust configurations; verify the required connection size and approved installation arrangement before ordering.
• External Condensate Pump – Optional accessory for compatible installations requiring automatic condensate removal.
• Replacement Washable Air Filters – Compatible replacement mesh filters for routine maintenance when required.

High-Capacity Year-Round Climate Control with the Airrex AHSC-60R 220/1

Experience flexible commercial and industrial climate control with the Airrex AHSC-60R 220/1 portable heat pump. Combining 60,000 BTU of cooling capacity and 60,000 BTU of heating capacity with reversible heat pump technology, R-454B refrigerant, ducted air distribution, and integrated dehumidification, this heavy-duty portable system provides year-round temperature management for large commercial and industrial work areas requiring high-capacity supplemental HVAC performance.

No Return Policy

All AirRex commercial unit sales are final and are non-refundable.
