AmeriCool 1 Ton 10,000 BTU Portable Air Conditioner | 115V - R32

Modular 1 Ton 10,000 BTU Portable Air Conditioner for Commercial and Industrial Cooling with Four Flexible Installation Configurations

The AmeriCool WMC-2500R is a 10,000 BTU/h (approximately 1-ton) modular portable air conditioner designed to provide targeted spot cooling and supplemental room cooling for commercial facilities, server rooms, offices, medical environments, manufacturing workstations, and temporary work areas. Combining a compact modular design with flexible installation options, automatic condensate pumping, and electronic temperature controls, this self-contained cooling system provides localized temperature control without requiring a conventional permanent HVAC installation. The WMC-2500R operates on a 115V, single-phase, 60 Hz electrical supply and uses R-32 refrigerant according to the current AmeriCool product brochure. Its modular configuration supports four installation arrangements, including portable placement, server rack installation, suspended installation, and stacked installation, subject to the manufacturer's installation requirements.

Key Benefits

• 10,000 BTU/h Cooling Performance – Provides approximately 1 ton of cooling capacity for supplemental temperature control in smaller commercial and industrial spaces.
• Modular Installation Flexibility – Supports four installation configurations to accommodate different equipment layouts and space constraints.
• Targeted Spot Cooling – Delivers conditioned air toward equipment, electronics, workstations, and other areas requiring localized temperature control.
• Compact Design – Its compact cabinet supports installation in space-constrained environments, including suitable server rack and equipment areas.
• Flexible Ducting – Supports separate cold-air supply and warm-air exhaust duct arrangements within the manufacturer's specified length limits.
• Automatic Condensate Pump – Removes collected condensate to simplify moisture management during cooling operation.
• Standard Electrical Supply – Operates on a 115V, single-phase, 60 Hz electrical supply with a NEMA 5-15P plug configuration.
• Automatic Restart – Restarts automatically after a power interruption, according to the manufacturer's documented product features.

10,000 BTU Cooling Performance and Refrigeration Technology

The AmeriCool WMC-2500R provides a nominal cooling capacity of 10,000 BTU/h, equivalent to approximately 1 ton of refrigeration. Its self-contained, air-cooled refrigeration system is designed to provide supplemental cooling for equipment, workstations, and smaller enclosed spaces. The current AmeriCool product brochure specifies R-32 refrigerant with a listed refrigerant charge of approximately 0.61 pounds. The manufacturer specifies an operating ambient temperature range of approximately 64°F to 113°F. Actual cooling performance depends on ambient temperature, internal heat loads, ventilation, insulation, and other environmental conditions. The WMC-2500R is intended for applications such as computer rooms, hospitals, process cooling, multiworkstation cooling, special events, and temporary emergency cooling.

Spot Cooling and Targeted Temperature Control

The AmeriCool WMC-2500R is designed to provide targeted cooling for equipment and designated work areas. Its modular configuration supports different installation arrangements to accommodate equipment layouts and available space. The unit's spot cooling and room cooling thermostat settings allow it to be configured for localized cooling or supplemental cooling of an enclosed area. Cold-air ducting can direct conditioned air toward equipment or workstations, subject to the manufacturer's approved installation configuration and duct-length limitations. For enclosed-room installations, warm condenser air must be exhausted outside the cooled space to prevent heat accumulation and maintain effective cooling performance.

Airflow and Distribution

The AmeriCool WMC-2500R provides evaporator airflow of approximately 280 CFM on high speed and 250 CFM on low speed, according to the current AmeriCool product brochure. Condenser airflow is approximately 750 CFM on high speed and 700 CFM on low speed. The unit supports a maximum cold-air duct length of approximately 30 feet and a maximum hot-air exhaust duct length of approximately 10 feet in the current brochure. The published hot-air duct diameter is 6 inches. Duct connections and routing must comply with the manufacturer's installation instructions. Keeping the air inlets, filters, cold-air outlets, and warm-air exhaust unobstructed helps maintain proper airflow and cooling performance.

Portable Design and Flexible Installation

The AmeriCool WMC-2500R features a compact modular cabinet designed for flexible placement in commercial and industrial environments. The current AmeriCool brochure lists approximate dimensions of 18 inches wide, 24 inches deep, and 20 inches high, with a net weight of approximately 110 pounds. Its modular design supports portable placement on casters, compatible server rack installation, suspended installation, and stacked installation when configured according to the manufacturer's requirements. The unit requires a 115V, single-phase, 60 Hz electrical supply and uses a NEMA 5-15P plug configuration. The published electrical specifications list approximately 10 amps of current consumption, 1.05 kW of power consumption, and a 15-amp circuit breaker size. Verify the exact unit nameplate and installation documentation before connecting the equipment. Suspended, stacked, and rack-mounted configurations require appropriate structural support, clearances, and approved installation hardware.

Condensate Management

The AmeriCool WMC-2500R includes an automatic condensate pump to remove moisture collected during cooling operation. This feature helps simplify condensate management and reduces the need for routine manual tank emptying. Condensate discharge must be routed to an appropriate drainage point in accordance with the manufacturer's instructions. Drainage tubing and connections should be inspected periodically for kinks, blockages, and leaks. Proper drainage and routine maintenance help support reliable operation, particularly during extended cooling periods or in environments with elevated humidity.

Controls, Comfort, and Electrical Connection

The AmeriCool WMC-2500R features spot cooling and room cooling thermostat settings to accommodate different applications. The manufacturer's documented features include automatic restart following a power interruption. The unit is designed for use with a standard compatible electrical outlet and can also operate with a suitable generator when electrical supply requirements are met. The current product brochure specifies a 115V, single-phase, 60 Hz electrical supply, approximately 10 amps of current consumption, 1.05 kW of power consumption, and a 15-amp circuit breaker size. The listed plug configuration is NEMA 5-15P, and the current brochure specifies a 14 AWG power cord. Verify the supplied cord length, exact electrical nameplate, grounding requirements, and circuit suitability before installation. Electrical connections must comply with the manufacturer's instructions and applicable local codes.

Commercial and Industrial Applications

The AmeriCool WMC-2500R is designed for supplemental cooling in commercial and industrial environments, including computer rooms, server racks, hospitals, process cooling applications, multiworkstation areas, offices, special events, and temporary emergency cooling installations. Its compact modular design supports applications where floor space is limited or where the unit must be integrated with compatible equipment layouts. The ability to configure the unit for portable, rack-mounted, suspended, or stacked installation provides flexibility for suitable facilities. Proper structural support, warm-air exhaust routing, electrical service, and maintenance access must be provided for reliable operation.

Mobility and Deployment

The AmeriCool WMC-2500R combines a compact cabinet with a modular installation design to support deployment in changing work environments. Portable installation allows the unit to be positioned where supplemental cooling is needed, while compatible rack-mounted, suspended, and stacked configurations can accommodate space-constrained facilities. Before moving or installing the equipment, verify the intended mounting configuration, structural load capacity, access clearances, electrical supply, and duct routing. Suspended and stacked installations must use suitable support structures and manufacturer-approved installation procedures.

Service and Maintenance

The AmeriCool WMC-2500R requires routine maintenance to help maintain airflow and reliable cooling performance. Air filters, air inlets, cold-air outlets, and the warm-air exhaust should be inspected regularly and kept free of dust and obstructions. The automatic condensate pump and discharge tubing should be checked periodically for proper drainage, blockages, and leaks. Duct connections should be inspected for damage or restrictions, and any rack-mounted or suspended installation should be checked for secure support. Disconnect the electrical supply before performing maintenance and follow the manufacturer's instructions for cleaning, inspection, and servicing.

Warranty

The AmeriCool WMC-2500R is covered by the manufacturer's limited warranty applicable to the product. The AmeriCool WMC-2500 owner manual specifies a 12-month warranty against defects in materials and workmanship under normal use and service, including compressor coverage, subject to the stated conditions and exclusions. Warranty eligibility may require the original invoice and compliance with the manufacturer's installation, operating, and maintenance requirements. Confirm the current written warranty terms applicable to the WMC-2500R configuration with AmeriCool or an authorized distributor before purchase.

Recommended Accessories

• 6-Inch Warm-Air Exhaust Duct – Compatible ducting for routing condenser exhaust away from the cooled space; observe the manufacturer's maximum exhaust duct length of approximately 10 feet.
• Cold-Air Supply Ducting – Compatible ducting for directing conditioned air toward equipment or designated work areas; observe the manufacturer's maximum cold-air duct length of approximately 30 feet.
• Server Rack Installation Accessories – Compatible mounting hardware for approved server rack configurations; confirm rack dimensions, load capacity, and required installation components.
• Suspended Installation Hardware – Manufacturer-approved support hardware for suitable suspended installations; verify mounting requirements and structural capacity before ordering.
• Replacement Air Filters – Compatible replacement filters for routine maintenance; confirm the correct filter dimensions and model compatibility with AmeriCool.
• Condensate Drain Tubing – Compatible tubing and fittings for routing automatic condensate-pump discharge to an appropriate drain; confirm the required connection size and routing limitations.

Flexible Modular Cooling with the AmeriCool WMC-2500R

Experience flexible supplemental cooling with the AmeriCool WMC-2500R modular portable air conditioner. Combining 10,000 BTU/h of cooling capacity with four installation configurations, automatic condensate pumping, flexible ducting, and automatic restart functionality, this compact cooling system provides targeted temperature control for computer rooms, server racks, medical environments, manufacturing workstations, and other space-constrained commercial applications. Its 115V electrical configuration and modular installation options make it a practical solution for facilities requiring localized cooling without a conventional permanent HVAC installation.

No Return Policy

All AmeriCool commercial unit sales are final and are non-refundable.

Auto Pump Included
