AmeriCool 5 Ton 61,000 BTU Industrial Portable Air Conditioner | 208/230V - R454B

Efficient 5 Ton Portable Air Conditioner with 60,000 BTU/h Cooling Capacity for Commercial and Industrial Applications – AmeriCool WPC-15000SPR

The AmeriCool WPC-15000SPR is a 60,000 BTU/h portable air conditioner designed to provide high-capacity, targeted cooling for commercial, industrial, and temporary cooling applications. Combining 5 tons of nominal cooling capacity with dedicated spot-cooling and room-cooling thermostat settings, three included 6-inch cold-air nozzles, and a portable self-contained design, this system delivers supplemental temperature control without requiring a permanent HVAC installation. Its flexible ducting options and wheeled construction allow the unit to be positioned where cooling is needed, making it suitable for server rooms, hospitals, manufacturing facilities, process cooling, multi-workstation environments, and emergency cooling applications.

Key Benefits

• 60,000 BTU/h Cooling Performance – Provides high-capacity supplemental cooling for demanding commercial and industrial environments.
• Spot and Room Cooling Settings – Allows users to select targeted cooling for specific equipment or work areas, or temperature control based on room conditions.
• Three 6-Inch Cold-Air Nozzles – Directs conditioned air toward multiple workstations, employees, or equipment locations.
• Portable Construction – Supports flexible deployment and relocation as cooling requirements change.
• 20-Inch Exhaust Duct Connection – Supports the routing of warm condenser air away from the conditioned space.
• Automatic Condensate Pump – Removes collected condensate automatically to reduce the need for manual tank emptying.
• 208/230V Electrical Connection – Operates on a single-phase, 60Hz electrical supply with a NEMA 6-50P plug configuration.
• Automatic Restart and Self-Diagnostics – Restarts after a power interruption and provides diagnostic indications to assist with troubleshooting.

High-Capacity Cooling Performance

The AmeriCool WPC-15000SPR provides a nominal cooling capacity of 60,000 BTU/h, equivalent to 5 tons of refrigeration. Its single-phase electrical system operates on a 208/230V, 60Hz power supply. The manufacturer's published specifications list current consumption of 32 amps at 208V and 30 amps at 230V, with nominal power consumption of 7 kW. The unit is designed for ambient operating temperatures between 64°F and 113°F. These performance characteristics make it suitable for commercial and industrial environments requiring substantial supplemental cooling, including equipment rooms, manufacturing facilities, and other spaces with concentrated heat loads. Actual cooling performance depends on ambient conditions, heat load, airflow, and installation configuration.

Spot Cooling and Targeted Temperature Control

The AmeriCool WPC-15000SPR features dedicated spot-cooling and room-cooling thermostat settings to accommodate different operating requirements. Spot cooling controls operation according to the temperature of the discharged cold air, allowing conditioned air to be directed toward specific equipment, employees, or workstations. Room cooling controls operation according to the temperature of the air returning to the unit. Three included 6-inch cold-air nozzles support targeted cooling at multiple locations. This flexibility is useful in environments where cooling an entire building is impractical or where concentrated heat loads require additional temperature control. When operating in an enclosed room, warm condenser air must be exhausted outside the conditioned space to prevent heat buildup and maintain effective cooling performance.

Airflow and Distribution

The AmeriCool WPC-15000SPR provides evaporator airflow rates of 2,000 CFM on high speed and 1,870 CFM on low speed. Condenser airflow is rated at 3,600 CFM. Three included 6-inch cold-air nozzles allow cooled air to be directed toward selected work areas, while compatible duct assemblies can support alternative distribution configurations. The unit uses a 20-inch hot-air exhaust duct connection. The manufacturer's 2026 product brochure specifies maximum hot-air exhaust and cold-air duct lengths of 100 feet and 60 feet, respectively. Follow the installation instructions for the applicable unit revision when determining allowable duct lengths, routing, and configuration to maintain proper airflow and cooling performance.

Portable Design and Flexible Installation

The self-contained AmeriCool WPC-15000SPR is designed for portable deployment in locations requiring high-capacity supplemental cooling without a permanent central HVAC installation. The unit measures approximately 28.9 inches wide, 51.5 inches deep, and 59.8 inches high, with a listed weight of approximately 661 pounds. Its portable construction supports positioning in suitable industrial and commercial areas, while the duct connections allow cooled air and warm condenser air to be directed according to the installation requirements. The unit requires a 20-inch hot-air exhaust duct connection and adequate clearance around the air intake and filters. Because of its weight, use suitable material-handling equipment and follow the manufacturer's lifting, movement, and installation instructions.

Condensate Management

The AmeriCool WPC-15000SPR includes an automatic condensate pump to remove moisture collected during cooling operation. As the unit cools the air, moisture condenses and must be discharged through the condensate drainage system. The factory-installed pump helps manage the larger condensate volume associated with this high-capacity unit and reduces the need for manual collection-tank emptying. AmeriCool states that the WPC-15000 pump can discharge condensate to a height of up to 30 feet. Follow the manufacturer's instructions for condensate hose routing, lift limitations, and drainage connections, and inspect the discharge line periodically to ensure that condensate can flow freely.

Controls, Comfort and Electrical Connection

The AmeriCool WPC-15000SPR supports spot-cooling and room-cooling operation and incorporates a control panel with operating-status and diagnostic indications. Its automatic restart function allows the unit to resume operation when power returns following an interruption. The unit requires a 208/230V, 60Hz, single-phase electrical supply and uses a NEMA 6-50P plug configuration. AmeriCool's published specifications list current consumption of 32 amps at 208V and 30 amps at 230V, a 50-amp circuit breaker size, a 7 kW power consumption rating, an 8 AWG power cord, and a 6-foot power cord length. Confirm the correct receptacle, circuit protection, grounding, and electrical supply against the manufacturer's documentation for the specific unit before installation. Electrical work must comply with applicable codes and be performed by qualified personnel where required.

Commercial and Industrial Applications

The AmeriCool WPC-15000SPR is designed for commercial and industrial environments requiring high-capacity portable cooling, including server rooms, computer rooms, hospitals, manufacturing facilities, process-cooling applications, multi-workstation areas, special events, and emergency or short-term cooling requirements. Its 60,000 BTU/h cooling capacity and three cold-air nozzles support applications with substantial localized heat loads. The combination of spot-cooling and room-cooling thermostat settings provides flexibility for different operating environments, while its ducted exhaust arrangement allows warm condenser air to be discharged outside the conditioned space. The unit is particularly useful where installing a permanent HVAC system would be impractical or where supplemental cooling is needed quickly.

Mobility and Deployment

The AmeriCool WPC-15000SPR is designed to provide portable cooling for changing commercial and industrial requirements. Its self-contained construction supports deployment in suitable work areas without permanent HVAC integration. At approximately 661 pounds, the unit requires appropriate handling equipment and a stable, level installation surface. Before relocating the unit, switch it off, disconnect the electrical supply, and follow the manufacturer's instructions for handling the exhaust duct and condensate connections. Once positioned, verify that the air intake is unobstructed, the exhaust duct is correctly routed, and the electrical connection is suitable for the unit's rated load.

Service and Maintenance

The AmeriCool WPC-15000SPR is designed to simplify routine maintenance through washable air filters, a self-diagnostic control system, and an automatic condensate pump. AmeriCool identifies vinyl chloride evaporator filters and aluminum condenser filters as compatible product-series components. Regularly inspect and clean the filters according to the manufacturer's instructions to maintain airflow and cooling performance. Check the exhaust duct for secure connections and obstructions, and inspect the condensate pump and discharge hose periodically. Before cleaning or servicing the unit, switch it off and disconnect the electrical supply. Follow the manufacturer's maintenance schedule and troubleshooting guidance, and refer refrigeration-system or electrical repairs to qualified service personnel.

Warranty

AmeriCool's published product catalog specifies a one-year parts-and-labor warranty for the complete unit and three years of parts-and-labor coverage for the compressor. Warranty coverage is subject to the manufacturer's applicable terms, conditions, and exclusions. Refer to the warranty documentation supplied with the specific WPC-15000SPR unit to confirm coverage requirements, exclusions, and service procedures.

Recommended Accessories

• 6-Inch x 20-Inch Cool-Air Duct Assembly – An optional accessory for directing cooled air toward selected work areas; confirm the required quantity and configuration before ordering.
• Vinyl Chloride Evaporator Filter – A manufacturer-listed filter for evaporator air filtration and routine maintenance.
• Aluminum Condenser Filter – A manufacturer-listed filter for condenser air filtration and maintenance.
• Condensate Pump – Included with the WPC-15000SPR according to AmeriCool's product information; verify the correct replacement pump and compatible discharge connections if required.
• 20-Inch Exhaust Duct Flange – An optional accessory for connecting the hot-air exhaust duct to the unit.
• 20-Inch Flexible Exhaust Duct – Routes warm condenser air away from the conditioned space; follow the manufacturer's specified duct diameter and allowable length.
• WPCPLENUM-9000 – A manufacturer-listed plenum accessory for compatible WPC-9000 installations; verify whether a suitable configuration is available for the WPC-15000SPR before ordering.
• WPCREMOTE Remote Control Unit – An optional remote-control accessory listed by AmeriCool for compatible portable air-conditioning units; confirm compatibility with the WPC-15000SPR.

High-Capacity Portable Cooling with the AmeriCool WPC-15000SPR

Experience flexible, targeted cooling with the AmeriCool WPC-15000SPR portable air conditioner. Combining 60,000 BTU/h of cooling capacity with spot-cooling and room-cooling thermostat settings, three 6-inch cold-air nozzles, high-volume airflow, and an automatic condensate pump, this 5-ton portable air-conditioning system provides supplemental temperature control for commercial facilities, industrial workspaces, server rooms, process-cooling applications, and temporary cooling requirements.

No Return Policy

All AmeriCool commercial unit sales are final and are non-refundable.

Please Note: This unit does not currently have any remote control options available
