Berner CHD10 Commercial High Performance 10 Air Curtain - 72" - Electric Heated - 480/3/60 - White

Commercial High Performance Air Curtain for Environmental Separation and Insect Control

The Berner Commercial High Performance 10 Air Curtain is designed for commercial service entries and main entrances where environmental separation and flying insect control are important. Recommended for mounting heights up to 10 feet for environmental separation and 8 feet for insect control, the CHD10 creates a controlled air stream across open doorways to help separate interior and exterior environments while allowing convenient access through the opening. Its high-performance design is well suited for service entries, employee doors, main entrances, and other commercial openings.

The CHD10 is available in ambient, unheated configurations and electric-heated models, with single lengths from 3 to 10 feet and one-, two-, or three-motor configurations depending on the model. Ambient and electric-heated models use 1/2 hp three-speed motor(s). Ambient models include a factory-installed fan speed switch, while electric-heated models include a factory-installed fan speed/heat switch. The series features a 14-inch-high by 15-inch-deep cabinet and supports wall and top mounting. White or black aluminum exterior covers are standard, with stainless steel and custom-color options available.

Berner CHD10 Commercial High Performance Air Curtain Features & Benefits

• High-Performance Design: Designed for commercial service entries and main entrances to help provide environmental separation and flying insect control.
• Mounting Height: Recommended for mounting heights up to 10 feet for environmental separation and 8 feet for insect control.
• Ambient and Heated Options: Available in ambient, unheated configurations and electric-heated models for different commercial applications.
• Three-Speed Motors: Equipped with 1/2 hp three-speed motor(s), with the number of motors varying by model configuration.
• Multiple Width Options: Available in single lengths from 3 to 10 feet, with one-, two-, or three-motor configurations depending on the model.
• Factory-Installed Controls: Ambient models include a factory-installed fan speed switch, while electric-heated models include a factory-installed fan speed/heat switch.
• Durable Cabinet: Features a 14-inch-high by 15-inch-deep cabinet with a white or black aluminum exterior cover.
• Flexible Mounting: Designed for wall and top mounting, with 5/16-inch threaded inserts provided for top mounting.
• Multiple Finish Options: Available with white or black aluminum exterior covers, with optional stainless steel and custom-color finishes.
• Simple Installation: Manufactured in single construction lengths with no assembly required.
• Optional Air Filtration: A washable 3/8-inch aluminum air inlet filter is available as an optional accessory.
• Control Options: Optional Basic, Deluxe, Comfort Plus, and Automation Control Packages are available, along with remote speed selectors, Hand/Off/Automatic switches, disconnect switches, thermostats, and temperature sensors.
• Indoor Installation: UL Listed for indoor mounting only and designed to be mounted on the inside of the building.

What's Included

Your purchase includes the Berner CHD10 Commercial High Performance 10 Air Curtain. No assembly is required. Wall mounting plate and other accessories are available separately.

Safety Features

• Secure Mounting Options – Designed for wall or suspended top mounting, with 1/4-inch keyhole mounting slots for wall mounting and 1/4-inch threaded inserts for suspended mounting.
• Accessible Service Components – A minimum of 4 inches of clearance is required above the air curtain for installation and removal of the inlet screen and access to the electrical compartment.
• Indoor Use – The CHD10 air curtain is UL Listed for indoor mounting only and shall be mounted on the inside of the building.
• Secure Installation – Mounting hardware must be capable of supporting a minimum of three times the net weight of the air curtain.
• Electrical Safety – Installation and electrical connections must be performed by qualified personnel in accordance with applicable electrical codes, and a disconnect switch is required for each branch circuit.

Warranty Information

Berner International warrants unheated CHD10 models for 5 years and heated models for 2 years from the original date of shipment, covering defects in workmanship and material, provided the equipment has been properly cared for, installed, and operated in accordance with the manufacturer's instructions and the limits specified on the nameplate.

For complete warranty details, coverage requirements, limitations, and exclusions, please refer to the Berner Warranty Document.

---

Control Options

Activation Device (Required – Sold Separately)

• Door switch
• On/off switch

---

High-Performance Design for Commercial Openings

The BERNER Commercial High Performance 10 (CHD10) Air Curtain is designed to help provide environmental separation and flying insect control at commercial openings. Designed for mounting heights up to 10 feet for environmental separation and 8 feet for insect control, it features a 14-inch-high by 15-inch-deep design with 1/2 hp three-speed motor(s). The CHD10 is available with a white or black aluminum exterior cover, with optional stainless steel and custom-color finishes available. It supports wall or top mounting and requires no assembly. Ambient, unheated models are backed by a five-year limited warranty, while electric-heated models carry a two-year limited warranty.

---

Why Choose Berner CHD10 Commercial High Performance 10 Air Curtain?

Environmental Separation and Insect Control

The BERNER CHD10 is designed for commercial openings and recommended for mounting heights up to 10 feet for environmental separation and 8 feet for insect control. It is ideal for service entries and main entrances where environmental separation and flying insect control are important.

High-Performance and Flexible Design

The CHD10 features a 14-inch-high by 15-inch-deep design with 1/2 hp three-speed motor(s). Available in single lengths from 3 to 10 feet, it features a white or black aluminum exterior cover, with optional stainless steel and custom-color finishes available. The CHD10 supports wall or top mounting and requires no assembly.

---

Suitable Applications for Berner CHD10 Commercial High Performance 10 Air Curtain

• Service & Employee Entrances: Designed for service and employee entrance applications, with recommended mounting heights up to 10 feet for environmental separation and 8 feet for insect control.
• Main Entrances: Ideal for commercial main entrance applications where environmental separation and flying insect control are important.
• Commercial Openings: Suitable for commercial openings requiring an air curtain to help separate indoor and outdoor environments while allowing convenient passage.

---
