Berner SHD07 Sanitation Certified High Performance 7 Air Curtain - 48" - Unheated - 240/1/60 - Stainless Steel

Sanitation-Certified High Performance Air Curtain for Environmental Separation and Insect Control

The Berner Sanitation Certified High Performance 7 Air Curtain is an ambient, unheated air curtain designed for commercial and food-service openings where environmental separation and flying insect control are important. Recommended for mounting heights up to 8 feet for environmental separation and certified to NSF 37 for customer entry applications up to 7 feet, the SHD07 creates a controlled air stream across open doorways to help separate interior and exterior environments while maintaining convenient access through the opening. Its high-performance design is well suited for kitchen and employee service doors, shopping cart areas, concessions, drive-thrus, ghost kitchens, and other commercial openings.

The SHD07 is EPH listed per NSF 37 and features 3/4 hp single-speed motor(s), depending on the model configuration. Available in single lengths up to 10 feet, the SHD07 can be wall or top mounted and is designed for simple installation, operation, and maintenance. The ambient, unheated design features a white or black aluminum exterior cover, with stainless steel and custom-color options also available.

Berner SHD07 Sanitation-Certified Air Curtain Features & Benefits

• Sanitation Certified: EPH listed per NSF 37 for food-service applications and flying insect control.
• Mounting Height: Designed for heights up to 7 feet for flying insect control, with environmental separation applications typically using a mounting height about 1 foot higher.
• High-Performance Airflow: Provides a powerful air stream across the doorway for effective environmental and insect control.
• Unheated Operation: Uses ambient-temperature air without adding heat.
• 3/4 HP Motors: Equipped with single-speed 3/4 hp motor(s), depending on model configuration.
• Multiple Lengths: Available in single lengths up to 10 feet for different doorway applications.
• Flexible Mounting: Supports wall and top mounting for installation flexibility.
• Durable Construction: Features a 14-inch-high by 15-inch-deep design with a white or black aluminum exterior cover.
• Easy Installation: No assembly is required, with 1/4-inch keyhole slots for wall mounting and 5/16-inch threaded inserts for top mounting.
• Flexible Controls: Requires an activation device, with door switch and on/off switch options, plus Basic and Deluxe control packages. Building automation and door controller versions are also available.
• 5-Year Warranty: Includes a 5-year parts warranty for ambient models.

What's Included

Your purchase includes the Berner SHD07 Sanitation Certified High Performance 7 Air Curtain and wall plate. No assembly is required.

Safety Features

• Required Electrical Disconnect – Each branch circuit requires a disconnect switch for safe servicing and maintenance.
• Protected Airflow Operation – Keep the air intake and discharge openings unobstructed to maintain proper airflow and prevent overheating.
• Secure Mounting Requirements – Mounting hardware must support a minimum of three times the air curtain's net weight.
• Service Safety – Disconnect power before servicing or cleaning. Electrical work must be performed by qualified personnel.

Warranty Information

Berner International provides a 5-year parts warranty on ambient, unheated SHD07 models, covering defects in workmanship and material when the equipment has been properly cared for, installed, and operated according to the manufacturer's instructions and applicable requirements.

For complete warranty details, coverage requirements, limitations, and exclusions, please refer to the Berner Warranty Document.

---

Control Options

Activation Device (Required – Sold Separately)

• Door switch
• On/off switch

---

Durable and Efficient Design

The BERNER SHD07 Sanitation Certified High Performance Air Curtain helps control flying insects and separate indoor and outdoor environments at commercial entryways. Designed for mounting heights up to 7 feet for insect control, it features a durable 14-inch-high by 15-inch-deep design with 3/4 hp single-speed motor(s), depending on the model. EPH listed per ANSI/NSF 37, the SHD07 features a white or black aluminum exterior cover, with optional stainless steel and custom colors. It supports wall or top mounting and requires no assembly, with simple installation, operation, and maintenance. Ambient models are backed by a five-year parts warranty.

---

Why Choose Berner SHD07 Sanitation Certified High Performance 7 Air Curtain?

Effective Air Barrier for Customer Entryways

The BERNER SHD07 is designed for customer entryways and mounting heights up to 7 feet for insect control. Its high-performance airflow helps create an effective air barrier when the door is open.

Sanitation-Certified and Durable Design

EPH listed per ANSI/NSF 37, the SHD07 features a durable 14-inch-high by 15-inch-deep design with a white or black aluminum exterior cover, plus optional stainless steel and custom colors. Available for 36- to 120-inch openings, it uses 3/4 hp single-speed motor(s) and supports wall or top mounting for flexible installation.

---

Suitable Applications for Berner SHD07 Sanitation Certified High Performance 7 Air Curtain

• Kitchen & Employee Service Doors: Designed for customer entryways and helps control flying insects when doors are open. The SHD07 is designed for mounting heights up to 7 feet for insect control.
