Carrier Totaline Universal Non-Integrated HSI Module 120V - P671-1000

Carrier Totaline Universal Non-Integrated HSI Module 120V - P671-1000

The Carrier P671-1000 is a universal non-integrated hot surface ignition module designed for compatible non-integrated gas-fired forced-air furnaces and boilers using a 120V carbide hot surface igniter.

Product Details

• Manufacturer: Carrier
• Manufacturer Part Number: P671-1000
• Part Type: Universal Non-Integrated Hot Surface Ignition Module
• Condition: New
• Igniter Voltage: 120 VAC
• Control Input: 18-30 VAC, 25 VAC nominal
• Stages: Single stage
• Dimensions: 4.13 in. W x 4.13 in. H x 1.5 in. D
• Package Quantity: 10 modules

Replacement Information

This part replaces or cross-references the following control numbers:

• Honeywell S8910U1000
• White-Rodgers 50E47-843
• Carrier 1380655
• Carrier 1380669
• Carrier 1380677
• Carrier 1380694

Application

For use with compatible non-integrated gas-fired forced-air furnaces and boilers using a 120V carbide hot surface igniter.
