The Carrier WeatherMaker® 50FEQA06A2A5-0A0A0 is a 5-ton commercial heat pump packaged rooftop unit designed to provide reliable year-round heating and cooling for commercial buildings. Combining heat pump heating with single-stage cooling, this all-in-one rooftop system helps deliver dependable comfort while simplifying installation and replacement through a compact packaged design engineered to fit existing Carrier roof curbs. The unit uses Puron Advance™ (R-454B) refrigerant and direct-drive EcoBlue™ Fan Technology for efficient, durable operation.
The integrated heat pump heating system provides 56,000 Btuh of heating capacity at 47°F and 29,000 Btuh at 17°F to help maintain comfortable indoor temperatures during colder weather. The 5-ton 50FEQ model provides a coefficient of performance (COP) of 3.7 at 47°F and 2.2 at 17°F. Carrier also specifies HSPF2 ratings of up to 6.7 across the 50FEQ product family. The system includes commercial defrost control and can be equipped with optional electric heat for supplemental heating applications.
The 50FEQA06A2A5-0A0A0 provides nominal 5-ton cooling capacity with single-stage cooling operation and a 13.4 SEER2 rating. The 50FEQ platform is designed for cooling operation at outdoor temperatures up to 115°F (46°C) and down to 40°F (4°C), helping support reliable commercial cooling across a broad range of outdoor conditions.
The direct-drive EcoBlue™ indoor fan system uses a Vane Axial fan design with an electronically commutated motor. Compared with legacy belt-drive systems, Carrier states that this design has 75% fewer moving parts and uses up to 40% less energy. The beltless configuration eliminates belts, blower bearings, and shafting while providing a permanently lubricated direct-drive ECM evaporator-fan motor.
The packaged rooftop configuration combines the heat pump, cooling system, indoor fan, and controls into a single outdoor unit, helping simplify equipment placement and preserve valuable indoor space. The 50FEQ platform maintains the same footprint as prior Carrier models for original-fit replacement applications and is specifically designed to fit Carrier roof curbs installed as far back as 1989. The unit can be field-converted between vertical and horizontal airflow configurations and includes provisions for thru-the-bottom power entry, single-point electric and controls connections, a full-perimeter base rail, built-in rigging adapters, and fork-truck slots.
The unit features a new control board with intuitive fan-speed adjustment and a simplified control-box arrangement. The 50FEQ platform supports optional SystemVu™ integrated communicating controls as well as electrical mechanical controls. Factory-installed options include temperature-sensing or enthalpy-sensing economizers with barometric relief, return- and supply-air smoke detectors, CO2 sensing, condensate overflow protection, multiple static fan capabilities, and phase monitor/protection.
The Carrier WeatherMaker® 50FEQA06A2A5-0A0A0 is designed for commercial rooftop heating and cooling applications where dependable year-round comfort and straightforward equipment replacement are important. Its 5-ton capacity, packaged rooftop configuration, flexible vertical or horizontal airflow arrangement, and compatibility with existing Carrier roof curbs make it well suited for commercial replacement and light commercial building applications.
The 50FEQ incorporates several features intended to simplify service and maintenance. Easy-grip access-panel handles, no-strip screws, and a tool-less filter access door provide convenient access to service areas. The control board facilitates simple safety-circuit troubleshooting and intuitive fan-speed adjustment. The direct-drive EcoBlue™ indoor fan eliminates belts, blower bearings, and shafting, while permanently lubricated fan and condenser motors help reduce routine maintenance requirements. Optional hinged access panels are also available.
The Carrier 50FEQ includes a standard limited warranty with 5 years of coverage for electric heaters, 5 years of parts-only coverage for the compressor, 3 years of coverage for the SystemVu™ controller, and 1 year of parts-only coverage on all other parts. Additional extended warranty packages are available.
Experience reliable commercial heating and cooling with the Carrier WeatherMaker® 50FEQA06A2A5-0A0A0. Combining heat pump heating, single-stage cooling, Puron Advance™ (R-454B) refrigerant, and direct-drive EcoBlue™ Fan Technology in one packaged rooftop system.
