Daikin ductless mini split air handlers feature individual temperature control per room, motion sensors for automatic economy mode operation, and stylish, modern designs that fit in with any home decor. Daikin's ductless systems deliver continuous circulation and filtration quietly, with none of the noise and inconsistent airflow of older furnace and AC systems, all while doing so with greater efficiency and reduced maintenance costs and worries.
Ductless mini split heat pump systems are perfect for old and new homes or buildings, regardless of whether they have existing ductwork installed. Couple that with Daikin's beautifully designed indoor air handlers and you have elegance and efficiency that will last for years to come, guaranteed.
The Daikin FVXS/CTXS indoor unit is packed with features. It features an energy-saving intelligent eye feature, which reduces heating or cooling depending on whether a room is occupied or not. A titanium photocatalytic air filter provides a cleaner environment in your home. The dry program reduces humidity in your home without causing the room temperature to fluctuate. With a wireless remote controller and a weekly timer, it's easy to change operating modes or set the unit to run for a certain amount of time. You can also use the Comfort Control App to control the unit from anywhere in the world.
Ductless mini-split heat pump systems are perfect for old and new homes or buildings, regardless of whether they have existing ductwork installed. Couple that with Daikin's beautifully designed indoor air handlers and you have elegance and efficiency that will last for years to come, guaranteed.
FeaturesThe Daikin RMXS Series 8-Zone Multi-Split system provides a flexible solution for your HVAC needs. You can connect up to eight indoor units to a single outdoor unit, which will reduce the amount of space you need for installation. The RMXS Series is compatible with three indoor unit types in a wide range of capacities, so you can tailor your system to your needs. The RXMS Series also features up to 18.8 SEER and reduces energy uses by 30% or more, lowering your overall energy bill, and it's backed by a 12 year limited warranty.
With ductless mini-split systems, each room can be controlled separately using wireless or wired remotes. The RMXS Series is compatible with Emura, Vista, FTXS, FVXS, FDMQ, and FDXS/CDXS indoor units, allowing you to blend them in almost invisibly with your home's existing furnishings.
FeaturesRefrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 1/2 inch O.D. flared ends, length 35 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.
Features:
Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 1/2 inch O.D. flared ends, length 25 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.
Features:
Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 1/2 inch O.D. flared ends, length 50 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.
Features:
Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 1/2 inch O.D. flared ends, length 30 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.
Features:
Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 1/2 inch O.D. flared ends, length 15 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.
Features:
18,000 BTU Wall Mounted Daikin Mini Split Multi Zone FTXS - Air Handler - R410A | |
---|---|
SKU | FTXS18WVJU9 |
Weight (in lbs) | 31.000000 |
Brand/Manufacturer | Daikin |
Additional Information | Drain: 5/8" |
Cooling BTU | 18000 |
Heating BTU | 18000 |
Maximum CFM | 378-417 CFM |
Decibel Level (dBA) | 32-45 |
Refrigerant | R410A |
Liquid Line | 1/4" |
Suction Line | 1/2" |
Electrical | 208/230v 1 Phase 60 Hz |
BTU/Tonnage | 18,000 BTU/1.5 Ton |
Mini Split Type | Wall Mounted |
Zone Compatibility | Multi Zone |
Height | 23-5/8" |
Width | 27-9/16" |
Depth | 8-1/4" |
Warranty | 12 Years with Online Registration |
Resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
Safety Information | PROPOSITION 65 WARNING
This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please Click Here.
|
48,000 BTU 18.8 SEER Daikin Mini Split RMXS Multi Zone Heat Pump Condenser - R410A | |
SKU | RMXS48LVJU |
Weight (in lbs) | 283.000000 |
Brand/Manufacturer | Daikin |
Additional Information | Heat Pump |
Additional Information | Charge: 8.8 lbs |
Additional Information | Maximum Line Set Length: 49' |
Additional Information | Maximum System Line Set Length: 442' |
Additional Information | Number of Zones: 2-8 |
HSPF | 11.3 |
Cooling BTU | 48000 |
Heating BTU | 54000 |
Decibel Level (dBA) | 57-58 |
Energy Star | No |
Refrigerant | R410A |
EER | 10.3 |
Compressor Type | Scroll |
Liquid Line | 3/8" (1) |
Suction Line | 3/4" (1) |
Electrical | 208/230v 1 Phase 60 Hz |
Max Breaker Size | 30 Amps |
Min. Breaker Size | 27 Amps |
Amperage Requirement | 30 |
Tonnage | 4 Ton |
BTU/Tonnage | 48,000 BTU/4 Ton |
Min/Max Outdoor Temp for Heating | 5°F - 60°F |
Min/Max Outdoor Temp for Cooling | 23°F - 115°F |
Zone Compatibility | Multi Zone |
Height | 52-15/16" |
Width | 35-7/16" |
Depth | 12-5/8" |
Warranty | 12 Years with Online Registration |
Resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
Safety Information | PROPOSITION 65 WARNING
This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please Click Here.
|
Refrigerant Line Set with 1/4" and 1/2" Line Ends - 35 feet | |
SKU | 366401 |
Weight (in lbs) | 35.000000 |
Brand/Manufacturer | Online Supply |
Length | 15' |
Height | 1/2" |
Width | 1/2" |
Safety Information | PROPOSITION 65 WARNING
This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please Click Here.
|
Refrigerant Line Set with 1/4" and 1/2" Line Ends - 25 feet | |
SKU | 366400 |
Weight (in lbs) | 25.000000 |
Brand/Manufacturer | Online Supply |
Length | 25' |
Height | 1/2" |
Width | 1/2" |
Safety Information | PROPOSITION 65 WARNING
This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please Click Here.
|
Refrigerant Line Set with 1/4" and 1/2" Line Ends - 50 feet | |
SKU | 366402 |
Weight (in lbs) | 45.000000 |
Brand/Manufacturer | Online Supply |
Length | 50' |
Height | 1/2" |
Width | 1/2" |
Safety Information | PROPOSITION 65 WARNING
This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please Click Here.
|
Refrigerant Line Set with 1/4" and 1/2" Line Ends - 30 feet | |
SKU | 216741 |
Weight (in lbs) | 30.000000 |
Brand/Manufacturer | Online Supply |
Length | 30' |
Height | 1/2" |
Width | 1/2" |
Safety Information | PROPOSITION 65 WARNING
This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please Click Here.
|
Refrigerant Line Set with 1/4" and 1/2" Line Ends - 15 feet | |
SKU | 201814 |
Weight (in lbs) | 15.000000 |
Brand/Manufacturer | Online Supply |
Length | 15' |
Height | 1/2" |
Width | 1/2" |
Safety Information | PROPOSITION 65 WARNING
This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please Click Here.
|
