Eltwin Hyper SureStart Single Phase Soft Starter 230V (8-16 FLA) - SS1B08-16SN

By

Eltwin

Model

SS1B08-16SN

ID

140883

Availability: Call for Availability

Authorized Eltwin Dealer

$239.00


Save up to $5,500 off Local HVAC Prices

Accessories for this product
Call 1-800-397-1392 for Best Pricing
Customer Reviews
BBB Rating
Best Pricing

Description

Give large compressors and motors a soft start and extend their lifetime. Achieve over 60% reduction in startup current for your AC unit and pumps with our range of single phase SureStart solutions.

SureStart Series is the original single-phase soft starter specifically targeted to reduce light flicker caused by the startup of fixed speed permanent split-capacitor motors (PSC). These motors are often of the scroll compressor types which are commonly used in air-conditioning and heat pump applications.

Features

  • 60-70% reduction in direct on-line (DOL) or in-rush current
  • Sophisticated under voltage protection
  • Motor reversal protection
  • Self-adjusting up to nominal 7 hp for optimal start performance
  • 50/60 Hz compatible
  • ETL, CE, EMC, and RoHs compliant
  • Tolerant to “dirty power” conditions
  • Versions available for retrofit installations or OEM production use
  • Fault LED
  • Internal Current Limiting

Designed for

  • Motors Between 1.5 - 7 HP
  • For applications w/ 8-16 Full Load Amps (FLA)

Applications

  • HVAC/R
  • Irrigation/submersible pumps
  • Compressors
  • Marine/RV
  • Solar power
  • RV/trucks
  • Military/government
  • Backup generators

Product Specifications

More Information
Eltwin Hyper SureStart Single Phase Soft Starter 230V (8-16 FLA) - SS1B08-16SN
SKUSS1B08-16SN
Weight (in lbs)2.000000
Brand/ManufacturerEltwin
Additional InformationPower Supply & Control voltage: Auto-Start at Power Up
Electrical208 / 230 V. 1 Phase 50Hz/60Hz
Amperage Requirement8A - 16A max FLA range
Temperature Control Range-4° F to 140° F
Height2"
Width3"
Depth5 1/4"
Warranty1 Year
