Fantech FKD 10 Mixed Flow Fan 910 CFM Single Phase - FKD 10 230V

By

Fantech

In stock
Model

FKD 10 230V

ID

36622

Authorized Fantech Dealer

$948.70

Product Feat ures
  • Fan bracket included for easy installation
  • Efficiently operate at airstream temperatures up to 140°F
  • Built-in thermal overload protection with automatic reset
  • High-flow fan with backward curved impellers ideal for exhaust & supply applications
Accessories for this product
Customer Reviews
BBB Rating
Best Pricing

Description

Features
  • 910 CFM
  • Single Phase
  • 2946 RPM
  • Max temperature of transported air 60 °C
  • Insulation class F
  • Enclosure class, motor IP44
  • Capacitor - 10 µF
  • Mixed-flow impeller
  • 100% Speed-controllable
  • Integral thermal contacts
  • Air stream temperatures up to 140 °F

A mixed-flow centrifugal type exhaust/supply fan for moderate size ventilation applications specifically designed to bridge the transition from centrifugal to axial. FKD Series fans offer substantially quieter performance and are easier to install than axial arrangements. Fans can be mounted at any angle at any point along with the ductwork and straight-through airflow design allows easy installation. Fans can be easily removed from ductwork for service. Fan motors are capable of operating in airstream temperatures of 140o F. Motor bearings are a permanently sealed, self-lubricating ball type. All fans are 100% speed controllable through a decrease in the voltage by using a solid-state or transformer type control. All FKD Series fans are backed by Fantech’s Three Year Warranty

Product Specifications

More Information
Fantech FKD 10 Mixed Flow Fan 910 CFM Single Phase - FKD 10 230V
SKUFKD 10 230V
Weight (in lbs)19.000000
Brand/ManufacturerFantech
Drive TypeDirect
Maximum CFM1265
Motor RPM2946
Watt514
Electrical120/240 V, Single Phase
Amperage Requirement2.25
CertificationAMCA Air, AMCA Sound, cULus
Height16"
Width17"
Depth17"
Warranty3 Year
