Fantech FKD 18 XL Mixed Flow Fan 6225 CFM Three Phase - FKD 18XL 230-460/3/60




FKD 18XL 230-460/3/60



Availability: Ships in 3-4 Weeks

Authorized Fantech Dealer

Suggested Retail $3,365.00 Your Low Price Special Price $2,975.00
Free Shipping
Accessories for this product
Call 1-800-397-1392 for Best Pricing
Customer Reviews
BBB Rating
Best Pricing


  • 6225 CFM
  • Single Phase
  • 1715 RPM
  • Max temperature of transported air 104 °F
  • Insulation class F
  • Enclosure class, motor IP54
  • Mixed-flow impeller
  • 100% Speed-controllable
  • Integral thermal contacts
  • Air stream temperatures up to 140 °F

A mixed-flow centrifugal type exhaust/supply fan for moderate size ventilation applications specifically designed to bridge the transition from centrifugal to axial. FKD Series fans offer substantially quieter performance and are easier to install than axial arrangements. Fans can be mounted at any angle at any point along with the ductwork and straight-through airflow design allows easy installation. Fans can be easily removed from duct work for service. Fan motors are capable of operating in air stream temperatures of 140o F. Motor bearings are a permanently sealed, self lubricating ball type. All fans are 100% speed controllable through a decrease in the voltage by using a solid-state or transformer type control. All FKD Series fans are backed by Fantech’s Three Year Warranty.

Product Specifications

More Information
Fantech FKD 18 XL Mixed Flow Fan 6225 CFM Three Phase - FKD 18XL 230-460/3/60
SKUFKD 18XL 230-460/3/60
Weight (in lbs)108.000000
Drive TypeDirect
Maximum CFM6225
Motor RPM1715
Electrical208 - 230 / 460 V, 3 Phase
Amperage Requirement4
CertificationAMCA Air, AMCA Sound, cULus
Warranty3 Year
Safety InformationPROPOSITION 65 WARNING
