LB White 230,000 BTU Link Ready Dual Fuel Indirect-Fired Portable Heater | 120V

Dual-Fuel Indirect-Fired Heating 230,000 BTU Portable Heater for Construction & Industrial Applications

The L.B. White FOREMAN® 230 DF 2.0 LINK™ Ready is a 230,000 BTU/h portable indirect-fired heater designed to deliver clean, dry heated air for construction sites, industrial facilities, warehouses, loading docks, and suitable temporary enclosures. Operating on liquid propane (LP) or natural gas (NG), this self-contained heating system combines a Beckett® burner, a fully welded heat exchanger, and forced-air circulation to separate combustion exhaust from the heated air supplied to the workspace. Its dual-fuel configuration, ductable design, remote thermostat compatibility, and portable wheeled frame provide flexibility for demanding temporary-heating applications. The LINK™ Ready configuration supports connection to L.B. White's LINK™ equipment monitoring platform when the required service is activated, helping equipment managers monitor equipment information, track runtime, and coordinate maintenance across job sites.

Key Benefits

• 230,000 BTU/h Heating Capacity – Provides high-output supplemental heat for suitable construction, industrial, and temporary enclosure applications.
• Dual-Fuel LP and Natural Gas Operation – Supports two fuel types, providing flexibility for different site fuel supplies.
• Indirect-Fired Heating Technology – Uses a fully welded heat exchanger to keep combustion gases separate from the heated air delivered into the workspace.
• High-Volume Forced-Air Heating – Distributes heated air through compatible ductwork to help warm designated work areas.
• Ductable Heat Distribution – Supports flexible heater placement and delivery of heated air through approved duct configurations.
• Remote Thermostat Compatibility – Supports optional remote temperature control for convenient heating management.
• LINK™ Ready Connectivity – Supports connection to compatible monitoring hardware for remote equipment visibility and maintenance planning.
• Portable Construction – Features wheels, a handle, and a single-point lifting bail to facilitate transportation and positioning.
• Durable Industrial Design – Combines a fully welded heat exchanger with a powder-coated protective frame for demanding work environments.
• Two-Year Manufacturer Warranty – Supported by the manufacturer's published two-year warranty, subject to applicable written warranty terms.

230,000 BTU/h High-Output Heating Performance

The L.B. White FOREMAN® 230 DF 2.0 delivers a rated heating input of 230,000 BTU/h for temporary heating in construction, industrial, and other suitable applications. Its forced-air system distributes heat through compatible outlet ducting, helping deliver warmth to designated areas. The fully welded heat exchanger transfers energy from the combustion process to the heated-air stream while routing combustion gases through a separate exhaust system. This indirect-fired configuration is beneficial when an application requires clean, dry heated supply air without direct mixing of combustion exhaust into the occupied or working space. Actual heating coverage depends on ambient temperature, enclosure dimensions, insulation, air infiltration, duct configuration, and other site conditions.

Dual-Fuel Indirect-Fired Heating Technology

The L.B. White FOREMAN® 230 DF 2.0 uses a Beckett® burner and indirect-fired heating technology, operating on either liquid propane or natural gas. The burner heats the fully welded heat exchanger, while an integrated fan circulates air across the exchanger to deliver heated air into the intended space. Combustion gases are routed through a separate exhaust system instead of being mixed directly with the heated supply air. The dual-fuel design provides flexibility for sites with different approved fuel supplies. Manufacturer-published maximum fuel consumption is approximately 10.6 lb/h for LP and 230 cubic feet per hour for natural gas. Proper fuel configuration, gas pressure, combustion-air provisions, and exhaust installation are essential for safe operation. Follow the current L.B. White owner's manual and applicable fuel-gas codes.

Forced-Air Distribution & Ducting Flexibility

The L.B. White FOREMAN® 230 DF 2.0 is designed to distribute heated air through compatible ducting for temporary heating applications. Its ductable configuration allows the heater to be positioned away from the area receiving heat, providing flexibility for construction sites, warehouses, industrial work areas, and suitable temporary enclosures. L.B. White's FOREMAN product literature describes ducting configurations of up to 100 feet, depending on the model and approved arrangement. The 230 DF 2.0 supports compatible outlet duct connections, with an optional adapter available for approved alternative configurations. Confirm the allowable duct diameter, length, and connection arrangement against the current owner's manual before installation. Use manufacturer-approved ducting, maintain adequate airflow, and keep intake and discharge openings unobstructed.

Portable Design & Flexible Installation

The L.B. White FOREMAN® 230 DF 2.0 features a portable, self-contained design intended for temporary heating applications. Its wheels and balanced handle support movement and positioning, while the single-point lifting bail provides an approved lifting option when used with suitable equipment. The FOREMAN 230 series is designed to facilitate storage on end when permitted by the manufacturer's handling and storage instructions. The heater requires a compatible LP or natural gas supply, an appropriate electrical connection, and a correctly installed exhaust system. Position the unit on a stable surface, maintain all specified clearances, and follow the owner's manual for gas connections, duct installation, exhaust routing, and safe operation. Verify the exact model's dimensions and operating weight from the current manufacturer's specification sheet before planning transport or installation.

Fuel Management & Energy Consumption

The L.B. White FOREMAN® 230 DF 2.0 operates on liquid propane or natural gas. Manufacturer-published maximum fuel consumption is approximately 10.6 lb/h for LP and 230 cubic feet per hour for natural gas. The listed minimum and maximum inlet gas pressure range is 7 to 13.5 inches water column for both fuel types. The gas supply, regulator, hose, and connections must be configured for the selected fuel and meet the manufacturer's specified pressure and flow requirements. The heater uses a 120 V, 60 Hz, single-phase electrical supply for its operating controls and fan. Verify the current model-specific electrical requirements, gas inlet specifications, and nameplate information before installation. Use only approved fuel-system components and have gas connections installed and inspected by qualified personnel.

Controls, Temperature Management & Electrical Connection

The L.B. White FOREMAN® 230 DF 2.0 supports compatible remote thermostat operation, allowing heating to respond to the selected ambient temperature rather than relying solely on manual operation. A fan-only ventilation mode is available within the FOREMAN series for air circulation without burner operation, subject to the specific model's controls and operating instructions. The heater requires a 120 V, 60 Hz, single-phase electrical supply. Optional accessories include a weather-resistant NEMA 4X thermostat with a 25-foot cord. Confirm the model-specific starting current, continuous current, grounding requirements, circuit capacity, and connection configuration against the current owner's manual and unit nameplate before installation. Electrical work must comply with the manufacturer's instructions and applicable electrical codes.

Construction, Warehouse & Industrial Applications

The L.B. White FOREMAN® 230 DF 2.0 is designed for supplemental heating in construction sites, warehouses, industrial facilities, loading docks, and suitable temporary enclosures requiring indirect-fired heat. Its 230,000 BTU/h heating capacity, dual-fuel operation, and ductable configuration provide flexibility for applications where heated supply air must remain separate from combustion exhaust. The indirect-fired design supports use in suitable enclosed work areas when the heater is installed and operated in accordance with the manufacturer's instructions. Proper exhaust routing, combustion-air supply, gas connections, and ventilation of the heater installation remain essential. Confirm application suitability, occupancy requirements, and local safety regulations before selecting the heater for a specific space.

LINK™ Ready Equipment Monitoring & Fleet Management

The L.B. White FOREMAN® 230 DF 2.0 LINK™ Ready is configured to support connection to the L.B. White LINK™ equipment monitoring platform. When the required compatible telematics hardware and service are installed and activated, the platform can provide access to equipment information such as location, runtime, operating status, and critical alerts, depending on the installed configuration. These capabilities can help equipment managers coordinate preventive maintenance, track utilization, and improve visibility across multiple job sites. LINK™ Ready identifies the equipment configuration for connected monitoring; verify the supplied hardware, activation requirements, cellular connectivity, and any subscription fees with L.B. White or an authorized dealer before purchase. Monitoring functions should not be assumed to include remote heater activation or thermostat adjustment unless expressly documented for the specific configuration.

Mobility & Deployment

The L.B. White FOREMAN® 230 DF 2.0 incorporates wheels, a handle, and a single-point lifting bail to support relocation between suitable temporary-heating locations. Its portable frame helps simplify deployment as site heating requirements change. Use the designated lifting point and appropriate handling equipment when lifting or transporting the unit. Position the heater securely on a stable surface, maintain the specified clearances, and route gas hoses, exhaust components, ducting, and electrical connections to prevent damage and trip hazards. Shut off the fuel supply, disconnect electrical power as directed, and allow hot components to cool before moving, cleaning, or servicing the heater.

Safety, Service & Maintenance

The L.B. White FOREMAN® 230 DF 2.0 incorporates an indirect-fired burner system, a fully welded heat exchanger, and a separate combustion exhaust system. Its design helps keep combustion gases separate from the heated supply air. L.B. White's published FOREMAN documentation identifies the series as certified to applicable ANSI/CSA standards for the United States and Canada. Inspect the burner, gas hoses, regulators, fuel connections, electrical components, fan, heat exchanger, ducting, and exhaust components before operation. Check fuel connections for leaks using an approved procedure and verify that the exhaust system is correctly installed. Maintain unobstructed airflow and the specified clearances, and remove accumulated dust or debris as directed by the manufacturer. Indirect-fired operation does not eliminate the need to discharge combustion exhaust safely outdoors. Shut off the heater, disconnect electrical power, and allow hot components to cool before servicing. Follow the current owner's manual for inspection, cleaning, burner maintenance, and troubleshooting. Gas-system and electrical repairs must be performed by appropriately qualified personnel. Never bypass safety devices or operate equipment with damaged components.

Warranty

The L.B. White FOREMAN® 230 DF 2.0 is covered by the manufacturer's published two-year warranty, subject to the applicable written warranty terms. Refer to L.B. White's current warranty documentation for coverage details, exclusions, registration requirements, and installation, operation, and maintenance conditions. Warranty eligibility may depend on compliance with the manufacturer's instructions and use of approved fuel-system components. Confirm the current warranty terms with L.B. White or an authorized dealer before purchase.

Recommended Accessories

• Remote Thermostat, NEMA 4X, with 25-Foot Cord – Manufacturer accessory Part No. 30125. Supports remote temperature control when configured according to L.B. White instructions.
• 12-Inch Fire-Retardant Duct, 25-Foot – Manufacturer accessory Part No. 30052, supplied with a clamp. Verify compatibility with the selected outlet configuration.
• 20-Inch Recirculating Duct, 25-Foot – Manufacturer accessory Part No. 30053, supplied with a clamp. Confirm the intended recirculation arrangement and installation requirements before ordering.
• 16-Inch Fire-Retardant Duct, 25-Foot – Manufacturer accessory Part No. 30076, supplied with a clamp. Verify compatibility with the approved adapter configuration.
• 16-Inch Duct Adapter Kit – Manufacturer accessory Part No. 30902. Confirm compatibility with the FOREMAN 230 DF 2.0 and the intended duct arrangement.
• LP Gas Hose – Manufacturer accessory Part No. 25965, listed as a 3/4-inch-by-15-foot hose for compatible FOREMAN 230/500 dual-fuel models. Verify suitability for the selected fuel and installation pressure.
• Dual-Fuel Gas Regulator – Manufacturer accessory Part No. 25141, listed for FOREMAN DF models. Confirm inlet pressure, outlet pressure, and natural gas installation requirements before ordering.
• 6-Inch Steel Exhaust Pipe Extension – Manufacturer accessory Part No. 30161, listed for FOREMAN 230, 500, and 750 DF models. Verify the required exhaust configuration and extension requirements.
• Rain Cap – Manufacturer accessory Part No. 30162, listed for FOREMAN 230, 500, and 750 DF models. Use with the approved exhaust arrangement to help prevent water entry.
• LINK™ Monitoring Components – Verify the correct module, activation requirements, and service subscription with L.B. White for the specific LINK™ Ready configuration.

Clean, Dry Heating Performance with the L.B. White FOREMAN® 230 DF 2.0 LINK™ Ready

Experience high-output indirect-fired heating with the L.B. White FOREMAN® 230 DF 2.0 LINK™ Ready Portable Heater. Combining 230,000 BTU/h heating capacity with dual-fuel LP and natural gas operation, a Beckett® burner, a fully welded heat exchanger, and ductable heat distribution, this portable heating system delivers clean, dry heated air for suitable construction, warehouse, and industrial applications. Its wheeled frame, single-point lifting bail, remote thermostat compatibility, and LINK™ Ready equipment monitoring capability support flexible deployment and equipment management wherever temporary indirect-fired heating is required.
