LB White 500,000 BTU Link Ready Dual Fuel Indirect-Fired Portable Heater | 120V

LINK™ Ready Equipment Monitoring 500,000 BTU Dual-Fuel Indirect-Fired Portable Heater for Construction & Industrial Applications

The L.B. White FOREMAN® 500 DF 2.0 LINK™ Ready is a 500,000 BTU/h portable dual-fuel indirect-fired heater designed to provide high-output supplemental heating for construction sites, industrial facilities, warehouses, loading docks, and suitable temporary enclosures. Operating on liquid propane (LP) or natural gas (NG), this ductable heating system combines a Riello® burner, a fully welded heat exchanger, and a high-volume blower to deliver heated air while keeping combustion exhaust separate from the heated supply air. Its dual 12-inch heated-air outlets, 20-inch air-recirculation inlet, portable industrial frame, and compatibility with approved ducting support flexible deployment across demanding job sites. LINK™ Ready equipment connectivity supports integration with L.B. White's LINK™ monitoring platform, helping equipment managers track equipment utilization, review operating information, and coordinate maintenance across multiple locations.

Key Benefits

• 500,000 BTU/h Heating Capacity – Provides high-output supplemental heat for suitable construction, industrial, and temporary enclosure applications.
• Dual-Fuel LP and Natural Gas Operation – Supports two approved fuel types, providing flexibility for different job-site gas supplies.
• Indirect-Fired Heating Technology – Uses a fully welded heat exchanger to separate combustion exhaust from the heated air supplied to the workspace.
• 3,457 CFM Blower Output – Provides high-volume forced-air circulation for distributing heat through compatible ducting.
• Dual 12-Inch Duct Outlets – Supports flexible heated-air delivery through two discharge connections or an approved single-duct configuration.
• 20-Inch Air-Recirculation Inlet – Accommodates compatible recirculation ducting for flexible system configurations.
• LINK™ Ready Equipment Monitoring – Supports connected equipment monitoring for improved fleet visibility, utilization tracking, and maintenance planning.
• Portable Industrial Construction – Features wheels, a handle, a single-point lifting bail, and forklift pockets to facilitate transportation and positioning.
• Remote Thermostat Compatibility – Supports optional thermostat control for convenient temperature management.
• Two-Year Manufacturer Warranty – Warranty coverage is subject to the manufacturer's applicable written terms and conditions.

500,000 BTU/h High-Output Heating Performance

The L.B. White FOREMAN® 500 DF 2.0 delivers a rated heating input of 500,000 BTU/h for demanding temporary-heating applications. Its forced-air system provides a rated blower output of 3,457 cubic feet per minute (CFM) and a published heated-air output of 2,350 CFM. The fully welded heat exchanger transfers energy from the combustion process to the circulating air while keeping combustion exhaust separate from the heated supply air. This indirect-fired design is suitable for applications requiring heated air to be distributed into work areas without direct mixing of burner exhaust into the supply stream. Actual heating coverage depends on ambient temperature, enclosure dimensions, insulation, air infiltration, duct configuration, and other site conditions.

Dual-Fuel Indirect-Fired Heating Technology

The L.B. White FOREMAN® 500 DF 2.0 uses a Riello® burner and indirect-fired heating technology to provide high-output supplemental heat. The burner heats the fully welded heat exchanger, while the integrated blower circulates air across the exchanger to deliver heated air into the intended space. Combustion gases are routed through a separate exhaust system rather than being mixed directly with the heated supply air. The dual-fuel configuration operates on liquid propane or natural gas, allowing flexibility where either approved fuel supply is available. Manufacturer-published maximum fuel consumption is approximately 23.0 lb/h for LP and 500 cubic feet per hour for natural gas. The specified minimum and maximum inlet gas pressures are 8 and 13.5 inches water column for both fuel types. Correct fuel selection, supply capacity, inlet pressure, combustion-air provisions, and exhaust installation are essential for safe operation. Follow the current L.B. White owner's manual and applicable fuel-gas codes.

3,457 CFM Blower Output & Dual-Duct Heat Distribution

The L.B. White FOREMAN® 500 DF 2.0 features a high-volume blower rated at 3,457 CFM, with a published heated-air output of 2,350 CFM. Two 12-inch outlet duct connections provide flexibility for distributing heated air to designated work areas. The manufacturer specifies a maximum duct length of 100 feet per outlet, subject to the approved installation configuration and a maximum outlet static pressure of 2.5 inches water column. The heater also features a 20-inch air-recirculation inlet for compatible recirculation arrangements. An optional 16-inch duct adapter kit is available for approved alternative configurations that use a single duct connection. Use manufacturer-approved ducting and adapters, maintain unobstructed airflow, and follow the current owner's manual for duct lengths, static-pressure limitations, and connection requirements.

Portable Design & Flexible Installation

The L.B. White FOREMAN® 500 DF 2.0 features a portable industrial design intended for temporary heating applications. Manufacturer-published dimensions are approximately 84.5 inches long, 33.25 inches wide, and 52.5 inches high. The listed unit weight is approximately 617 lb, with a shipping weight of approximately 785 lb. Integrated wheels, a handle, a single-point lifting bail, and forklift pockets support transportation and positioning at suitable work sites. The heater requires a compatible LP or natural gas supply, a suitable electrical connection, approved heated-air ducting, and a properly installed exhaust system. Position the unit securely on a stable surface, maintain the specified clearances, and follow the manufacturer's instructions for fuel connections, duct installation, exhaust routing, lifting, and operation.

Fuel Management & Energy Consumption

The L.B. White FOREMAN® 500 DF 2.0 operates on liquid propane or natural gas, with maximum fuel consumption depending on the selected fuel. Manufacturer specifications list maximum LP consumption of approximately 23.0 lb/h and maximum natural gas consumption of approximately 500 cubic feet per hour. The published minimum and maximum inlet gas pressures are 8 and 13.5 inches water column for both fuel types. Adequate fuel supply capacity and pressure must be maintained during operation to support proper burner performance. L.B. White identifies a dual-fuel regulator, Part No. 25141, for compatible FOREMAN DF models. Natural gas installations may require a different hose diameter and regulator configuration depending on the available supply pressure. Verify regulator selection, hose sizing, gas flow, inlet pressure, and installation requirements against the current manufacturer's documentation. All fuel connections must comply with applicable codes and be installed by appropriately qualified personnel.

Controls, Temperature Management & Electrical Connection

The L.B. White FOREMAN® 500 DF 2.0 supports compatible remote thermostat operation for convenient temperature management. An optional weather-resistant NEMA 4X thermostat with a 25-foot cord is available for compatible configurations. The heater requires a 120 V, 60 Hz, single-phase electrical supply and uses a 1 HP motor. Manufacturer-published electrical specifications list approximately 60 A starting current and 15 A continuous current. Because startup current is significantly higher than continuous operating current, verify circuit capacity, overcurrent protection, grounding, and connection requirements against the unit nameplate and current owner's manual before installation. Electrical connections must comply with the manufacturer's instructions and applicable electrical codes.

Construction, Warehouse & Industrial Applications

The L.B. White FOREMAN® 500 DF 2.0 is designed for supplemental heating in construction sites, warehouses, industrial facilities, loading docks, and suitable temporary enclosures requiring indirect-fired heat. Its 500,000 BTU/h heating input, high-volume blower, dual duct outlets, and dual-fuel capability support applications requiring substantial heated-air delivery. The indirect-fired configuration helps keep combustion gases separate from the heated supply air, while the portable frame supports deployment where temporary heat is needed. The heater is certified to applicable ANSI/CSA standards for the United States and Canada according to the manufacturer's published product specifications. Confirm that the heating capacity, gas supply, electrical connection, duct configuration, exhaust installation, and intended occupancy meet manufacturer requirements and applicable safety regulations.

LINK™ Ready Equipment Monitoring & Fleet Management

The L.B. White FOREMAN® 500 DF 2.0 LINK™ Ready supports connection to the L.B. White LINK™ equipment monitoring platform using compatible monitoring hardware and an activated service configuration. The platform is designed to provide equipment information such as location, runtime, operating status, and critical alerts, depending on the installed hardware and available services. These capabilities help equipment managers monitor utilization, coordinate preventive maintenance, and improve visibility across multiple job sites. Confirm the included telematics hardware, connectivity requirements, activation process, and subscription terms with L.B. White or an authorized dealer before purchase. LINK™ monitoring capabilities should not be interpreted as remote heater on/off control or remote temperature adjustment unless specifically documented for the applicable system configuration.

Mobility & Deployment

The L.B. White FOREMAN® 500 DF 2.0 measures approximately 84.5 inches long, 33.25 inches wide, and 52.5 inches high, with a listed unit weight of approximately 617 lb. Its wheels, handle, single-point lifting bail, and forklift pockets support relocation between suitable temporary-heating locations. Appropriate lifting equipment and handling procedures are essential when loading, unloading, or transporting the heater. Position the unit on a stable surface, maintain the required clearances, and secure it against unintended movement. Route ducting, exhaust components, gas hoses, and electrical connections to prevent damage and trip hazards. Shut off the fuel supply, disconnect electrical power as directed, and allow hot components to cool before moving, cleaning, or servicing the equipment.

Safety, Service & Maintenance

The L.B. White FOREMAN® 500 DF 2.0 incorporates a Riello® burner, a fully welded heat exchanger, and a separate combustion exhaust system. The indirect-fired design helps prevent direct mixing of combustion gases with the heated supply air. The manufacturer identifies the FOREMAN DF series as certified to applicable ANSI/CSA standards for the United States and Canada. Inspect the burner, gas hoses, regulators, fuel connections, electrical components, fan, heat exchanger, ducting, and exhaust system before operation. Check gas connections for leaks using an approved procedure and verify that the selected fuel configuration matches the available supply. Maintain required clearances and unobstructed airflow, and ensure the exhaust system is installed according to the manufacturer's instructions. Combustion exhaust must be discharged safely through the approved exhaust system. Disconnect electrical power and allow hot components to cool before servicing. Follow the current owner's manual for inspection, cleaning, burner maintenance, and troubleshooting. Fuel-system and electrical repairs must be performed by appropriately qualified personnel. Never bypass safety devices or operate the heater with damaged components.

Warranty

Warranty coverage for the L.B. White FOREMAN® 500 DF 2.0 is subject to the manufacturer's applicable written warranty policy. Refer to L.B. White's current warranty documentation for the coverage period, covered components, exclusions, registration requirements, and installation, operation, and maintenance conditions. Confirm the warranty terms applicable to the specific model and configuration with L.B. White or an authorized dealer before purchase.

Recommended Accessories

• LINK™ Monitoring Components – Verify the compatible telematics hardware, included components, activation requirements, and service subscription for the FOREMAN 500 DF 2.0 LINK™ Ready configuration with L.B. White.
• Remote Thermostat, NEMA 4X, with 25-Foot Cord – Manufacturer accessory Part No. 30125. Supports remote temperature control when configured according to the manufacturer's instructions.
• 12-Inch Fire-Retardant Duct, 25-Foot – Manufacturer accessory Part No. 30052, supplied with a clamp. Verify the outlet connection and approved duct arrangement.
• 20-Inch Recirculating Duct, 25-Foot – Manufacturer accessory Part No. 30053, supplied with a clamp. Supports compatible air-recirculation configurations.
• 16-Inch Fire-Retardant Duct, 25-Foot – Manufacturer accessory Part No. 30076, supplied with a clamp. Verify compatibility with the approved duct adapter configuration.
• 16-Inch Duct Adapter Kit – Manufacturer accessory Part No. 30902. Supports compatible single-duct configurations; verify the required setup before ordering.
• 3/4-Inch-by-15-Foot Gas Hose – Manufacturer accessory Part No. 25965, listed for compatible FOREMAN 230/500 models. Verify fuel type, connection size, and supply requirements before ordering.
• Dual-Fuel Gas Regulator – Manufacturer accessory Part No. 25141, listed for compatible FOREMAN DF models. Confirm regulator and hose requirements for the specific LP or natural gas installation.
• 6-Inch Steel Exhaust Pipe Extension – Manufacturer accessory Part No. 30161, listed for compatible FOREMAN DF models. Verify the required exhaust configuration before ordering.
• Rain Cap – Manufacturer accessory Part No. 30162, listed for compatible FOREMAN DF models. Use with the approved exhaust arrangement to help prevent water entry.
• Heater Stacking Kit – Manufacturer accessory Part No. 30903, listed for FOREMAN 500 and 750 models. Confirm approved stacking and storage arrangements with the current owner's manual.

Reliable Dual-Fuel Heating with the L.B. White FOREMAN® 500 DF 2.0 LINK™ Ready

Experience high-output indirect-fired heating with the L.B. White FOREMAN® 500 DF 2.0 LINK™ Ready Portable Heater. Combining 500,000 BTU/h heating input with LP and natural gas compatibility, a Riello® burner, a fully welded heat exchanger, and 3,457 CFM blower output, this industrial heating system provides flexible supplemental heat for suitable construction and industrial applications. Its dual 12-inch discharge outlets, 20-inch air-recirculation inlet, portable frame, lifting bail, and forklift pockets support flexible heat distribution and job-site deployment, while LINK™ equipment monitoring helps equipment managers improve fleet visibility and maintenance coordination.
