LB White Tradesman 170 Portable Forced Air Heater - Propane Gas

SAVE $196.00
By

LB White

In stock
Model

Tradesman 170

ID

151620

Was $686.00 Your Low Price Special Price $490.00
In Stock - Ready to Ship
Free Shipping

High-Output 170,000 BTU Portable Gas Heater for Construction & Industrial Applications with Adjustable Directional Heating

The L.B. White Tradesman® 170 is a commercial-grade portable forced-air gas heater designed to provide high-output supplemental heating for construction sites, industrial work areas, and other suitable temporary-heating environments. Delivering 125,000 - 170,000 BTU/h with propane vapor withdrawal, this direct-fired heating system combines dependable electronic spark ignition, thermostatic temperature control, and an adjustable front leg for directional heat delivery. Its heavy-gauge combustion chamber, durable Tri-Shield protective finish, and portable construction support reliable operation in demanding work environments. A natural gas configuration is also available, with a rated maximum heating input of 155,000 BTU/h.

Key Benefits

  • High-Output Heating Performance – Delivers up to 170,000 BTU/h on propane or 155,000 BTU/h on natural gas to provide supplemental heat for suitable work areas.
  • Direct-Fired Gas Heating Technology – Transfers combustion heat directly into the airstream, with manufacturer-stated direct-fired fuel efficiency of 99.97%.
  • Portable Construction – Compact dimensions and an approximately 29 lb shipping weight support transportation and positioning between suitable work areas.
  • Forced-Air Heat Distribution – Uses an integrated fan to circulate heated air toward the intended work area.
  • Adjustable Directional Heating – An adjustable front leg helps position the heater to direct heat where it is needed.
  • Fuel Management – Compatible propane or natural gas operation allows the heater to be configured for the available approved fuel supply.
  • Thermostatic Temperature Control – Integrated thermostatic control helps maintain the selected temperature and regulate heating operation.
  • Ignition & Safety Systems – Electronic spark ignition, an air-proving switch, high-limit protection, and an automatic-reset backflash switch support controlled operation.

170,000 BTU/h Heating Performance

The L.B. White Tradesman® 170 provides a maximum heating input of 170,000 BTU/h when configured for propane vapor withdrawal. The natural gas version has a maximum rated input of 155,000 BTU/h. The propane model also has a published minimum input of 125,000 BTU/h, allowing variable-output operation according to the applicable model configuration. This heating performance supports temporary supplemental heating for construction and industrial work areas. Actual heating performance and coverage depend on ambient temperature, building construction, ventilation, air infiltration, and other site conditions.

Direct-Fired Gas Heating Technology

The L.B. White Tradesman® 170 uses direct-fired forced-air gas heating technology. The burner heats the air directly, and the integrated fan distributes the heated airstream into the surrounding area. The heater is available in propane vapor withdrawal and natural gas configurations, with the natural gas model providing a maximum input of 155,000 BTU/h. The manufacturer states a direct-fired fuel efficiency of 99.97%. Because combustion products enter the heated airstream, adequate ventilation is essential. This construction heater must not be used to heat human living quarters or in unventilated areas and must be operated only in applications permitted by the manufacturer.

Forced-Air Heat Distribution

The L.B. White Tradesman® 170 incorporates an integrated fan to distribute heated air toward the intended work area. Its adjustable front leg helps position the unit for directional heat delivery. This forced-air design supports temporary supplemental heating in suitable construction and industrial environments. A verified model-specific airflow value is not included here because the official owner's manual consulted does not provide a clearly identifiable CFM rating for the CP170. Keep the air intake and discharge openings unobstructed, and do not attach ductwork to the heater's hot-air discharge.

Portable Design & Flexible Installation

The L.B. White Tradesman® 170 features a compact portable design intended for temporary heating applications. The manufacturer's owner's manual lists dimensions of approximately 24 inches long, 10 inches wide, and 16 inches high, with an approximate shipping weight of 29 lb. An adjustable front leg allows the heater to be positioned for directional heat delivery. The unit requires an approved propane or natural gas supply, the appropriate manufacturer-specified regulator and connections, and a grounded electrical supply for the fan and ignition system. Installation must be performed in accordance with the manufacturer's instructions and applicable fuel-gas, electrical, and safety codes.

Fuel & Energy Management

The L.B. White Tradesman® 170 is available in propane vapor withdrawal and natural gas configurations. The propane model has a maximum fuel consumption of approximately 7.89 lb/h and a minimum consumption of approximately 5.8 lb/h. The natural gas version has a maximum listed consumption of 155 cubic feet per hour. For the propane model, the manufacturer's manual specifies an inlet gas pressure of 11.1 inches water column at the heater connection and a burner manifold pressure of 11.0 inches water column. The natural gas configuration has different pressure requirements. Verify the exact fuel configuration, supply pressure, regulator, hose, and connection requirements against the heater's nameplate and current owner's manual before installation. The heater also requires a 120 V, 60 Hz, single-phase electrical supply for fan and ignition operation.

Controls, Temperature Management & Electrical Connection

The L.B. White Tradesman® 170 includes thermostatic temperature control to regulate heating operation according to the selected temperature. Its electronic spark ignition supports burner startup, while the integrated fan and safety controls support normal operation. The manufacturer's owner's manual specifies a 120 V, 60 Hz, single-phase electrical supply, a starting current of 3.7 A, and a continuous operating current of 1.0 A for the CP170. The unit uses a grounded three-prong electrical plug and must be connected to a properly grounded receptacle. The specific plug configuration and power cord length should be verified against the exact unit. Follow the manufacturer's electrical and gas connection requirements and applicable local codes.

Commercial, Construction & Industrial Applications

The L.B. White Tradesman® 170 is designed for temporary supplemental heating in suitable construction and industrial environments. Manufacturer literature identifies Tradesman portable forced-air heaters for commercial, industrial, and construction worksites, as well as agricultural and greenhouse applications. Its high heating input, directional forced-air delivery, and thermostatic temperature control make it suitable for work areas requiring temporary heat where an approved gas supply and adequate ventilation are available. The heater is not intended for residential living quarters or recreational vehicles. Final suitability depends on the heating load, fuel infrastructure, ventilation, and applicable site safety requirements.

Mobility & Deployment

The L.B. White Tradesman® 170 has compact dimensions of approximately 24 inches long, 10 inches wide, and 16 inches high. Its approximate shipping weight of 29 lb supports transportation and positioning between suitable work areas. The adjustable front leg facilitates directional placement, allowing the heated airstream to be aimed toward the intended work zone. Position the heater on a stable surface, maintain the specified clearances from combustible materials, and secure the gas supply according to the manufacturer's instructions. Disconnect the fuel and electrical supplies as directed before moving or servicing the unit.

Safety, Service & Maintenance

The L.B. White Tradesman® 170 incorporates electronic spark ignition, an air-proving switch, high-limit protection, and an automatic-reset backflash switch. These systems help monitor operating conditions and protect against unsafe operation. The heavy-gauge combustion chamber and burner plate are designed for demanding work environments, while the Tri-Shield finish provides extended protection against abrasion and corrosion. Inspect the heater, electrical cord, gas hose, regulator, and fittings before each use, and check gas connections for leaks using an approved leak-detection procedure. Provide adequate ventilation and maintain the manufacturer's specified clearances from combustible materials. Do not operate the heater with any safety device bypassed, and do not attach ductwork to the hot-air discharge. Cleaning, servicing, and gas-system adjustments must follow the owner's manual and be performed by appropriately qualified personnel.

Warranty

Warranty coverage for the L.B. White Tradesman® 170 should be confirmed directly with L.B. White or an authorized dealer before purchase. The manufacturer's published product page and owner's manual should be consulted for the warranty terms applicable to the exact model and configuration. Refer to the applicable written warranty for coverage duration, exclusions, registration requirements, and any installation, operation, or maintenance conditions.

Recommended Accessories

  • Manufacturer-Specified Gas Hose & Regulator – Use the approved hose and regulator assembly compatible with the selected propane configuration and the heater's required inlet pressure.
  • Propane Supply Components – Provide a properly sized propane cylinder or supply system with compatible connections and sufficient capacity for the heater's fuel consumption.
  • Natural Gas Supply Components – For natural gas configurations, provide a compatible gas supply and regulator arrangement that meets the manufacturer's specified pressure and flow requirements.
  • Electrical Power Connection Components – Use a compatible, properly grounded 120 V, 60 Hz electrical supply and manufacturer-approved connection components.
  • Manufacturer-Approved Replacement Parts – Verify model and configuration compatibility using the official L.B. White parts diagrams and service documentation before ordering replacement components.

High-Output Portable Heating with the L.B. White Tradesman® 170

Experience dependable supplemental heating with the L.B. White Tradesman® 170 Portable Forced-Air Gas Heater. Combining up to 170,000 BTU/h of propane-fired heating input, electronic spark ignition, thermostatic temperature control, adjustable directional heating, and a durable Tri-Shield finish, this portable heater provides targeted warmth for suitable commercial, construction, and industrial applications. Its compact design and proven forced-air heating technology support flexible deployment wherever temporary gas-fired heating is appropriate and the required fuel supply, electrical connection, and ventilation are available.

More Information
LB White Tradesman 170 Portable Forced Air Heater - Propane Gas
FeatureSpec
SKUTradesman 170
Weight (in lbs)30
Brand/ManufacturerLB White
Heating BTU125,000 - 170,000
Maximum CFM550
Operating ModeHeating
Ignition Type Continuous Spark
Fuel TypePropane
ColorWhite
Length24"
Height16″
Width9.5″
Resources You will need Adobe Acrobat Reader to view PDF documents.
Safety Information
This gas appliance requires a trained technician to install. Improperly connecting gas lines or improperly connecting a gas flue or venting may result in death. By purchasing this item, you are agreeing that you are using a trained technician to install this gas appliance. We will not be responsible for any injury or property damage arising from improper service or service procedures. Whoever installs or services this unit assumes responsibility for any personal injury or property damage which may result. Many jurisdictions require a license to install this equipment.
