Read our privacy policyThe L.B. White Tradesman® 170N Ultra is a commercial-grade portable natural gas forced-air heater designed to provide dependable supplemental heating for construction sites, industrial work areas, and other suitable temporary-heating environments. Delivering adjustable heating input from 125,000 to 155,000 BTU/h, this direct-fired heating system combines electronic spark ignition, thermostatic temperature control, and variable heat output to accommodate changing heating demands. Its Self Diagnostic Service Saver system with an illuminated diagnostic light supports convenient troubleshooting, while the heavy-gauge combustion chamber, durable Tri-Shield™ coated steel case, and portable construction are designed for demanding work environments.
The L.B. White Tradesman® 170N Ultra provides adjustable heating input from 125,000 to 155,000 BTU/h. Its variable-output design allows heating performance to be adjusted according to changing supplemental heating requirements. The integrated forced-air system delivers a rated heated-air output of 550 cubic feet per minute (CFM), helping distribute warmth throughout the intended work area. The direct-fired design transfers heat directly into the airstream, providing high-output supplemental heating for suitable construction and industrial applications. Actual heating performance and coverage depend on ambient temperature, building construction, ventilation, air infiltration, and other site conditions.
The L.B. White Tradesman® 170N Ultra uses direct-fired forced-air heating technology powered by natural gas. The burner heats the air directly, and the integrated fan distributes the heated airstream into the surrounding area. The manufacturer specifies direct-fired fuel efficiency of 99.97%. Because combustion products enter the heated airstream, adequate ventilation is essential. This heater is designed for temporary construction heating and must not be used to heat human living quarters or in unventilated areas. Operation must comply with the manufacturer's instructions, applicable fuel-gas regulations, and site safety requirements.
The L.B. White Tradesman® 170N Ultra provides a rated heated-air output of 550 CFM. Its integrated fan distributes warm air toward the intended work area, supporting temporary supplemental heating in suitable construction, industrial, and agricultural environments. The forced-air design helps distribute warmth beyond the immediate burner area. Keep the air intake and discharge openings unobstructed during operation, maintain the manufacturer's specified clearances from combustible materials, and do not attach ductwork to the hot-air discharge.
The L.B. White Tradesman® 170N Ultra features a compact portable design intended for temporary heating applications. Manufacturer-published dimensions are approximately 24 inches long, 9.5 inches wide, and 16 inches high, with a shipping weight of approximately 34 lb. The unit requires a compatible natural gas supply, the manufacturer-specified regulator and gas connections, and a grounded electrical supply for fan and ignition operation. Its portable configuration supports deployment between suitable work areas as heating requirements change. Position the heater on a stable surface, maintain the specified clearances, and follow the manufacturer's installation and operating instructions.
The L.B. White Tradesman® 170N Ultra operates on natural gas, with a manufacturer-published fuel consumption range of approximately 125 to 155 cubic feet per hour. The specified acceptable natural gas inlet pressure range is 7 to 13.5 inches of water column at the inlet of the supplied regulator. The burner manifold pressure is specified at 5.5 inches of water column. The variable-output design allows the heater to operate at a lower heating input when full capacity is unnecessary, helping manage fuel consumption. The unit requires a 120 V, 60 Hz, single-phase electrical supply for fan and ignition operation, with a starting current of 3.7 A and a continuous operating current of 1.0 A. Verify the available gas supply capacity, regulator arrangement, pressure requirements, electrical connection, and unit nameplate before installation. Do not connect this natural gas model to a propane supply.
The L.B. White Tradesman® 170N Ultra includes thermostatic temperature control to regulate heating operation according to the selected temperature. Its electronic spark ignition supports burner startup, while variable-output operation helps adjust heating performance to changing demand. The Self Diagnostic Service Saver system and illuminated diagnostic light support troubleshooting when operating issues occur. Electrical specifications include a 120 V, 60 Hz, single-phase supply, a starting current of 3.7 A, and a continuous operating current of 1.0 A. Use a properly grounded electrical receptacle compatible with the factory-installed connection. Confirm the plug configuration, circuit capacity, and connection requirements against the current owner's manual and unit nameplate before operation.
The L.B. White Tradesman® 170N Ultra is designed for temporary supplemental heating in suitable construction, industrial, and agricultural environments. L.B. White identifies the Tradesman series for commercial and industrial worksites, construction projects, and certain agricultural applications. Its adjustable 125,000 to 155,000 BTU/h heating input, 550 CFM heated-air output, and thermostatic control make it suitable for temporary heating where high-output forced-air heat and an approved natural gas supply are available. The Self Diagnostic Service Saver system provides additional troubleshooting support in demanding work environments. Because this is a direct-fired gas heater, the installation must provide the ventilation required by the manufacturer and comply with applicable fuel-gas regulations and site safety procedures.
The L.B. White Tradesman® 170N Ultra measures approximately 24 inches long, 9.5 inches wide, and 16 inches high, with a shipping weight of approximately 34 lb. Its compact construction supports transportation and positioning between suitable work areas. Position the heater securely on a stable surface, maintain the required clearances, and connect the natural gas supply in accordance with the manufacturer's instructions. Disconnect the gas and electrical supplies as directed before moving, inspecting, or servicing the unit. Allow hot components to cool before handling or storage.
The L.B. White Tradesman® 170N Ultra incorporates electronic spark ignition, an air-flow safety switch, a high-temperature safety switch, and the Self Diagnostic Service Saver system with an illuminated diagnostic light. These features support controlled operation, monitoring, and troubleshooting. Its heavy-gauge combustion chamber and burner plate are designed for demanding work environments, while the Tri-Shield™ coated steel case helps resist abrasion and corrosion. Inspect the heater, electrical cord, gas supply connections, regulator, and fittings before use. Check gas connections for leaks using an approved leak-detection procedure, provide adequate ventilation, and maintain the specified clearances from combustible materials. Do not bypass safety devices, operate damaged equipment, or attach ductwork to the hot-air discharge. Cleaning, maintenance, and gas-system servicing must follow the current owner's manual and be performed by appropriately qualified personnel.
Warranty coverage for the L.B. White Tradesman® 170N Ultra should be confirmed directly with L.B. White or an authorized dealer before purchase. Refer to the applicable written manufacturer warranty for the coverage duration, exclusions, registration requirements, and installation, operation, or maintenance conditions that apply to this model. Warranty eligibility may depend on compliance with the manufacturer's instructions.
Experience dependable supplemental heating with the L.B. White Tradesman® 170N Ultra Natural Gas Forced-Air Heater. Combining adjustable heating input from 125,000 to 155,000 BTU/h with 550 CFM heated-air output, thermostatic temperature control, electronic spark ignition, and the Self Diagnostic Service Saver system, this portable heater provides targeted warmth for suitable construction, industrial, and agricultural applications. Its variable-output heating technology, compact construction, illuminated diagnostic light, and durable Tri-Shield™ finish support flexible deployment and convenient troubleshooting wherever natural gas-fired temporary heating is appropriate and the required gas supply, electrical connection, and ventilation are available.
