36,000 BTU 19.1 SEER Mitsubishi Quad Zone H2i Hyper Heat Pump System 9+9+12+15

By

Mitsubishi

Model

MXZ-SM36NAMHZ / 2-MSZ-FH09 / MSZ-FH12 / MSZ-FH15

ID

7936

Rating:
98% of 100
Availability: Hurry! Limited Stock

Authorized Mitsubishi Dealer

Suggested Retail $7,304.00
Your Low Price $6,993.00

Free Shipping

Required Fields *

Customize 36,000 BTU 19.1 SEER Mitsubishi Quad Zone H2i Hyper Heat Pump System 9+9+12+15
36,000 BTU Mult Zone Condenser - Hyper Heat
36,000 BTU Mult Zone Condenser - Hyper Heat   + $4,099.00
9,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler
9,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler   + $663.00
9,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler
9,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler   + $663.00
12,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler
12,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler   + $735.00
15,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler
15,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler   + $833.00
36,000 BTU 19.1 SEER Mitsubishi Quad Zone H2i Hyper Heat Pump System 9+9+12+15
36,000 BTU 19.1 SEER Mitsubishi Quad Zone H2i Hyper Heat Pump System 9+9+12+15
36,000 BTU 19.1 SEER Mitsubishi Quad Zone H2i Hyper Heat Pump System 9+9+12+15

$6,993.00

Accessories for this product
Call 1-800-397-1392 for Best Pricing
Customer Reviews
BBB Rating
Best Pricing

Description

The Mitsubishi Quad Zone Mini Split Systems are state of the art ductless mini split heat pump systems, providing both heating and cooling for your home. Rated at 19 SEER, with an inverter-driven compressor, this efficient system will keep operating costs down while providing year-round comfort. Each living space has its own air-handling unit and each unit has its own wireless electronic temperature controller.

Indoor Units

The Mitsubishi Series MSZ-FH mini-split wall mounted air handlers are a perfect fit for your home. With multiple operating modes, multiple fan speeds, and multiple airflow directions, this unit fits the needs of nearly any room.

The MSZ-FH's i-see Sensor 3D monitors the floor and ceiling of its zone for fluctuations in temperature. If it detects an underserved area and will temporarily adjust airflow to ensure complete comfort throughout the zone. This sensor also serves as an occupancy detector, allowing the indoor unit to enter energy saving mode if no human heat signatures are detected within the zone.

The MSZ-FH series uses two advanced filters to clean and deodorize the air that passes through it. The deodorizing filter utilizes a ceramic surface element and platinum nanoparticles to absorb any offending smells. The second filter is an enzyme-based anti-allergy filter that captures and destroys bacteria and particulates.

Mitsubishi's hot start technology prevents cold drafts by delaying fan operation until the heat exchanger has warmed up.

The powerful setting on the Mitsubishi MSZ-FH series makes it easy to get your zone to the perfect temperature quickly. When it is activated, the unit temporarily increases refrigerant flow and fan speed to provide quick comfort through rapid heating or cooling.

By slowly adjusting the cooling set point and swinging the horizontal vanes, the MSZFH06NA can improve the efficiency of cooling operations without compromising the comfort provided.

When the indoor unit is run in dry mode, the coil's temperature stays just below the dew point of the return air, removing unwanted moisture. This improves your comfort and reduces the chance of mold growth and other property damage in the conditioned space.

Optimal air flow is easy to achieve with the MSZFH06NA thanks to two vane control options, standard and wide. These functions provide access to five different horizontal vane positions, six different vertical vane positions, two swing modes, a horizontal vane auto mode, and a vertical vane wide mode. Auto mode selects the best vane position based on operating mode and the swing modes cycle through all positions for maximum coverage. When wide mode is activated, fan speed increases beyond the current setting.

Outdoor Unit

The Mitsubishi Ductless Mini Split MXZ Series Heat Pump and Air Conditioner Condenser has an INVERTER-driven compressor pump that cools or warms refrigerant and sends it inside to an air handler through small pipes. Each living space has its own air-handling unit and each unit has its own wireless electronic temperature controller.

With the Mitsubishi Ductless Mini Split MXZ Series Heat Pump Air Conditioner Multi zone condenser each room or zone operates independently with its own wireless or wired remote controller so people in different rooms can choose the temperature that makes them most comfortable. This unit will work with a variety of indoor unit combinations; with indoor options such as Wall mounted ductless, Floor mounted ductless, Ceiling recessed cassette ductless, horizontal ducted ductless or even multi position ducted air handlers.

For more Quad Zone Mini Split System

36,000 BTU 23 SEER Mitsubishi Multi-Zone Ductless H2i Hyper Heat Pump Condenser w/ Base Pan Heater

OVERVIEW

The Mitsubishi MXZ-SM36NAMHZ is a heat pump condenser designed to be used in multi zone system setups. As one air handler is needed per room that you are trying to heat and cool, multiple single zone condensers can take up a lot of space in your yard, making a multi zone unit more practical in many applications. With its integrated drain pan heater allowing it to heat down to 5°F, the MXZ-SM36NAMHZ will keep you warm even through the coldest months of the year.

FEATURES

  • 36,000 BTU multi zone heat pump condenser
  • Variable speed Inverter-driven compressor with quiet operation features
  • Requires a branch box
  • Hyper Heat technology, supporting enhanced comfort down to 5°F
36,000 BTU

The Mitsubishi MXZ-SM36NAMHZ is rated to handle a total of 36,000 BTU, which generally should be the same or greater than the total BTU count across all air handlers that this unit is paired with. In some instances, a certified pairing will have a higher BTU count total than this condenser’s rating. This is intentional, as the condenser can easily handle more, however anything higher than this rating can potentially lower the speed that the unit can heat and cool, as well as limit the functional outputs of each air handler if they are all running at the same time.

Warranty

Mitsubishi offers a 5 year parts and 7 year compressor warranty on all of its products. When the unit is registered online through the manufacturer after an installation that follows your state and local codes, the warranty is upgraded to a 10 year parts and compressor warranty.

Required Equipment

The Mitsubishi MXZ-SM36NAMHZ is designed with only one set of line set ports, allowing it to support a higher BTU output than units with multiple sets. As such, at least one branch box is required for this unit to function to allow it to connect to multiple air handlers. Along with branch boxes, this condenser requires air handlers, controllers, and other basic installation equipment to function, all of which are available at an additional cost.

Enhanced Comfort

With its variable speed compressor, the MXZ-SM36NAMHZ can provide more precise adjustments to the covered spaces with the right air handlers. This also slightly improves electrical efficiency by ramping the compressor up and down based on the unit’s air handlers’ needs, as well as providing a more stable temperature output from the connected air handlers to provide superior comfort.

Intelligent Control

For ease of control, many air handlers that are compatible with the MXZ-SM36NAMHZ can use any Mitsubishi-brand thermostat or adapter. The most convenient to control—the Kumo cloud WiFi adapter, found herethe Kumo cloud WiFi adapter, found here—allows each air handler to be accessed from anywhere that you have Internet. Please note that in most applications, you will need one thermostat or adapter per indoor air handler that you want to be able to control with it.

9,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler

Please note that in order to function, this air handler must be installed with a condenser and other installation equipment, available at an additional cost.

  • Able to cover up to a small room in ideal conditions
  • 9,000 BTU wall-mounted air handler with remote
  • Built-in I-SEE sensor to direct airflow more effectively
  • .225 gallon per hour dehumidification rate

The Mitsubishi MSZ-FS09NA air handler is designed to be able to function as a single zone system or with a multi zone system setup. With integrated I-SEE sensor technology, this air handler can constantly read the temperature from multiple directions in the room, allowing it to aim airflow in the direction that it is needed most. This allows your room to maintain a more constant temperature and decreases the unit’s run time. Keeping health in mind, Mitsubishi also factory-installed an enhanced filtration system.

12,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler

Please note that in order to function, this air handler must be installed with a condenser and other installation equipment, available at an additional cost.

  • Able to cover up to a small room in ideal conditions
  • 12,000 BTU wall-mounted air handler with remote
  • Built-in I-SEE sensor to direct airflow more effectively
  • .375 gallon per hour dehumidification rate

The Mitsubishi MSZ-FS12NA air handler is designed to be able to function as a single zone system or with a multi zone system setup. With integrated I-SEE sensor technology, this air handler can constantly read the temperature from multiple directions in the room, allowing it to aim airflow in the direction that it is needed most. This allows your room to maintain a more constant temperature and decreases the unit’s run time. Keeping health in mind, Mitsubishi also factory-installed an enhanced filtration system.

15,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler

Please note that in order to function, this air handler must be installed with a condenser and other installation equipment, available at an additional cost.

  • Able to cover up to a medium-sized room in ideal conditions
  • 15,000 BTU wall-mounted air handler with remote
  • Built-in I-SEE sensor to direct airflow more effectively
  • .405 gallon per hour dehumidification rate

The Mitsubishi MSZ-FS15NA air handler is designed to be able to function as a single zone system or with a multi zone system setup. With integrated I-SEE sensor technology, this air handler can constantly read the temperature from multiple directions in the room, allowing it to aim airflow in the direction that it is needed most. This allows your room to maintain a more constant temperature and decreases the unit’s run time. Keeping health in mind, Mitsubishi also factory-installed an enhanced filtration system.

Product Specifications

More Information
36,000 BTU 23 SEER Mitsubishi Multi-Zone Ductless H2i Hyper Heat Pump Condenser w/ Base Pan Heater
SKUMXZ-SM36NAMHZ
Weight (in lbs)275.000000
Brand/ManufacturerMitsubishi
ReplacesMXZ-SM36NAMHZ
HSPF11
Cooling BTU36,000
Heating BTU33,000
Decibel Level (dBA)49
RefrigerantR410A
SEER1 (Efficiency)23
EER15
Liquid Line3/8"
Suction Line5/8"
Electrical230 V. 1 Phase 60 Hz
Max Breaker Size45 amps
Min. Breaker Size40 amps
Amperage Requirement50
Tonnage3 Ton
BTU/Tonnage36,000 BTU/3 Ton
Zone CompatibilityMulti Zone
Height52"
Width41"
Depth16"
WarrantyLimited warranty: five years parts and seven years compressors
Resources You will need Adobe® Acrobat® Reader to view PDF documents
Safety InformationPROPOSITION 65 WARNING
9,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler
SKUMSZ-FS09NA
Weight (in lbs)29.000000
Brand/ManufacturerMitsubishi
ControllerWireless Included
Additional InformationDrain: 5/8"
Cooling BTU9,000
Heating BTU10,900
Maximum CFM117-381 CFM
Decibel Level (dBA)20-42
RefrigerantR410A
CapacityDehumidification Rate: 0.23 gal/hr
Liquid Line1/4"
Suction Line3/8"
Electrical208/230V 1 Phase 60 Hz
BTU/Tonnage9,000 BTU/0.75 Ton
Mini-Split TypeWall Mounted
Zone CompatibilityMulti Zone
Operating ModeCooling, Heating
Height12-11/16"
Width36-7/16"
Depth9-3/16"
Warranty10 Years with Online Registration
Resources You will need Adobe® Acrobat® Reader to view PDF documents.
Safety InformationPROPOSITION 65 WARNING
12,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler
SKUMSZ-FS12NA
Weight (in lbs)29.000000
Brand/ManufacturerMitsubishi
ControllerWireless Included
Additional InformationDrain: 5/8"
Cooling BTU12,000
Heating BTU13,600
Maximum CFM117-398 CFM
Decibel Level (dBA)21-42
RefrigerantR410A
CapacityDehumidification Rate: 0.38 gal/hr
Liquid Line1/4"
Suction Line3/8"
Electrical208/230V 1 Phase 60 Hz
PhaseSingle Phase
BTU/Tonnage12,000 BTU/1 Ton
Mini-Split TypeWall Mounted
Zone CompatibilityMulti Zone
Operating ModeCooling, Heating
Height12-11/16"
Width36-7/16"
Depth9-3/16"
Warranty10 Years with Online Registration
Resources You will need Adobe® Acrobat® Reader to view PDF documents.
Safety InformationPROPOSITION 65 WARNING
15,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone FS Series - Air Handler
SKUMSZ-FS15NA
Weight (in lbs)29.000000
Brand/ManufacturerMitsubishi
ControllerWireless Included
Additional InformationDrain: 5/8"
Cooling BTU15,000
Heating BTU18,000
Maximum CFM194-497 CFM
Decibel Level (dBA)25-46
RefrigerantR410A
CapacityDehumidification Rate: 0.41 gal/hr
Liquid Line1/4"
Suction Line1/2"
Electrical208/230V 1 Phase 60 Hz
PhaseSingle Phase
BTU/Tonnage15,000 BTU/1.25 Ton
Mini-Split TypeWall Mounted
Zone CompatibilityMulti Zone
Operating ModeCooling, Heating
Height12-11/16"
Width36-7/16"
Depth9-3/16"
Warranty10 Years with Online Registration
Resources You will need Adobe® Acrobat® Reader to view PDF documents.
Safety InformationPROPOSITION 65 WARNING
