Today's Hours 8am - 11pm estNavac Vacuum Pump 7 CFM 2-Stage 15 Microns A2L Pro Series
In Stock - 14 Ready to Ship
By
Navac
In stock
Model
NP7DP2
ID
206238
$525.53
Product Features
- Flow Rate: 7 CFM dual-stage pump
- Vacuum Level: Down to 15 microns
- Motor: ¾ HP, 115V AC with forced oil circulation
- Features: Check valve, gas ballast, oil mist filter, lifting hook
The NP7DP2 is a robust, AC-powered HVAC/R pump delivering 7 CFM flow and achieving deep vacuum levels down to 15 microns. Designed for A2L refrigerants (like R‑32, R‑454B), it features a reliable dual-stage cylinder, forced oil circulation, internal check valve to prevent oil backflow, and a handy lifting hook for portability. With ¾ HP motor, 115 V power supply, 15 oz oil reservoir, and ¼″, ⅜″, & ½″ flare inlet ports, it’s built for high-performance evacuation on residential or light-commercial systems—all in a compact 26 lb body and backed by a 1‑year warranty
Features
- Flow Rate: 7 CFM dual-stage pump
- Vacuum Level: Down to 15 microns
- Motor: ¾ HP, 115V AC with forced oil circulation
- Features: Check valve, gas ballast, oil mist filter, lifting hook
- Refrigerant Ready: A2L-compatible (R-32, R-454B, and more)
- Inlet Ports: ¼", ⅜", and ½" flare fittings
- Oil Capacity: 15 oz
- Weight: 26 lb | Warranty: 1 year
