TPI 1.45 KW Corded Portable Infrared Flat Panel Emitter | 120V

Direct Radiant Heat 4,947 BTU Portable Infrared Electric Heater for Workshops & Industrial Applications with High-Efficiency Radiant Heating

The TPI Corporation FSP-1412-1C is a 1,450 W portable infrared electric heater designed to provide targeted radiant heat for workshops, maintenance areas, industrial workstations, and other suitable indoor or sheltered work environments. Delivering 4,947 BTU/h from a 120 V, single-phase electrical supply, this compact heater uses a flat-panel infrared emitter to transfer heat directly to people and objects within its radiant heating pattern. Its gold-anodized aluminum housing provides reflectivity and corrosion resistance, while the heavy-duty wire guard helps protect the heating element and surrounding personnel. The aluminized steel base and large carry handle support convenient positioning, and the factory-installed 15-foot power cord with a NEMA 5-15 molded plug simplifies connection to a compatible grounded receptacle.

Key Benefits

• 4,947 BTU/h Heating Output – Provides targeted supplemental radiant heat for suitable work areas and localized heating applications.
• 1,450 W Electrical Input – Operates on a standard-compatible 120 V, single-phase electrical supply when connected to an appropriately rated circuit.
• Infrared Radiant Heating Technology – Transfers heat directly to people and objects within the radiant pattern rather than relying solely on heating the surrounding air.
• 78.5% Published Radiant Efficiency – Supports effective radiant energy transfer through the flat-panel emitter design.
• 60-Degree Symmetric Heat Pattern – Concentrates radiant output within a defined heating pattern for localized applications.
• Gold-Anodized Aluminum Housing – Provides high reflectivity and corrosion resistance for long-term use in appropriate environments.
• Heavy-Duty Wire Guard – Helps protect the heating element and personnel from direct contact with the emitter.
• Portable Base and Carry Handle – Supports convenient handling and positioning at suitable work locations.
• 15-Foot Factory-Installed Cord – Includes a NEMA 5-15 molded plug for connection to a compatible grounded 120 V receptacle.
• 25,000-Hour Element Life Expectancy – Provides a manufacturer-published expected element life under specified operating conditions.

4,947 BTU/h Radiant Heating Performance

The TPI Corporation FSP-1412-1C delivers a rated heating output of 4,947 BTU/h from its 1,450 W electric heating element. Unlike conventional fan-forced heaters, this infrared unit transfers energy through radiant heat, warming objects and people within its effective radiation pattern. This approach is useful for localized heating where directly warming a work area is preferred over heating a large volume of ambient air. Actual comfort and heating performance depend on mounting or placement distance, surrounding temperatures, surface characteristics, airflow, and environmental conditions.

Flat-Panel Infrared Emitter Technology

The TPI Corporation FSP-1412-1C uses a high-density, medium-wavelength flat-panel infrared emitter designed for radiant heating applications. The manufacturer specifies a symmetric 60-degree heat pattern and a published radiant efficiency of 78.5%. The emitter is designed to provide direct radiant energy transfer to objects and people within the intended heating zone. The manufacturer also identifies the emitter design as suitable for demanding applications where vibration resistance is important. Position the heater according to the manufacturer's installation instructions, maintain the required clearances, and avoid direct exposure to combustible materials or unsuitable surfaces.

Targeted Radiant Heat Distribution

The FSP-1412-1C uses its flat-panel emitter and reflective housing to direct radiant energy toward the intended work area. Its 60-degree symmetric radiation pattern supports localized heating rather than conventional forced-air circulation. This design can be useful for workstations, maintenance tasks, and other applications where heat is required in a defined area. The heater does not rely on a blower to distribute heat, so airflow ratings such as CFM are not applicable to this model. Position the unit to provide suitable radiant coverage while maintaining manufacturer-specified clearances and preventing obstruction of the emitter.

Portable Construction & Flexible Placement

The TPI Corporation FSP-1412-1C features an aluminized steel base, a large carry handle, and a gold-anodized aluminum housing. These components support portable use and convenient positioning in suitable work environments. The manufacturer lists an approximate weight of 17 lb and overall dimensions of 14.5 inches, 11.5 inches, and 25 inches, as presented in its FSP Series dimensional table. The heavy-duty wire guard helps protect the element and personnel. Place the heater on a stable, level surface and maintain all required clearances. Relocate the unit only when it is switched off, disconnected from the electrical supply, and sufficiently cool to handle safely.

Electrical Power & Energy Consumption

The TPI Corporation FSP-1412-1C operates on a 120 V, single-phase electrical supply and draws 1,450 W at a rated current of 12.1 A. The factory-installed 15-foot cord is equipped with a NEMA 5-15 molded plug. Connect the heater only to a compatible grounded receptacle supplied by an appropriately rated circuit. Avoid overloading shared circuits, using damaged extension cords, or operating the heater with compromised electrical connections. Verify the unit nameplate and current manufacturer's instructions for grounding, circuit requirements, and safe electrical operation.

Radiant Comfort & Heating Control

The TPI Corporation FSP-1412-1C provides radiant heat when energized and positioned toward the intended heating area. Its flat-panel emitter and reflective housing support directed heat delivery without requiring a fan or fuel-burning system. The FSP-1412-1C is a basic infrared portable heater; an integrated adjustable thermostat, digital temperature display, timer, or remote control is not specified in the manufacturer's published documentation for this model. Use an appropriately rated external control only if TPI Corporation confirms compatibility with the heater's electrical rating and intended application.

Workshop, Maintenance & Industrial Applications

The TPI Corporation FSP-1412-1C is intended for suitable localized heating applications in workshops, industrial workstations, maintenance areas, and other environments where radiant electric heat is appropriate. Its direct radiant heating pattern can provide warmth to designated work areas without depending on whole-room air heating. The compact base, carry handle, and factory-installed cord support deployment in suitable locations with a compatible electrical supply. Assess the application carefully before use, particularly where dust, combustible materials, moisture, vibration, or other environmental conditions may affect safe operation. Follow the manufacturer's installation and operating instructions and applicable electrical and workplace safety requirements.

Portability & Deployment

The FSP-1412-1C is designed for portable use and includes a large carry handle and an aluminized steel base. Its approximately 17 lb weight supports handling between suitable work locations. Position the heater on a stable surface, orient the emitter toward the intended heating zone, and keep the power cord clear of hot surfaces, walkways, and potential mechanical damage. Maintain the specified clearances from combustible materials and do not place objects on or against the heater. Switch off and disconnect the unit before moving it or adjusting its position.

Safety, Service & Maintenance

The TPI Corporation FSP-1412-1C includes a heavy-duty wire guard designed to protect the heating element and personnel. The gold-anodized aluminum housing provides reflectivity and corrosion resistance, while the base supports stable placement. Regularly inspect the power cord, molded plug, housing, base, emitter, and wire guard for damage or wear. Keep the emitter and surrounding openings free of dust and debris according to the manufacturer's cleaning instructions. Disconnect electrical power and allow the unit to cool completely before cleaning or servicing. Do not operate the heater if the cord, plug, guard, or heating element is damaged. Keep combustible materials at the specified distance and never leave the heater operating in conditions prohibited by the manufacturer. Repairs must be performed by appropriately qualified personnel using manufacturer-approved components.

Warranty

Warranty coverage for the TPI Corporation FSP-1412-1C is subject to the manufacturer's applicable written warranty terms. Refer to TPI Corporation's current warranty documentation for the coverage period, covered components, exclusions, claim procedures, and any registration or installation requirements. Confirm the warranty applicable to the specific model and purchase before ordering.

Recommended Accessories

• Compatible 120 V Grounded Receptacle – Use a properly grounded receptacle compatible with the factory-installed NEMA 5-15 plug and the heater's 12.1 A rated current.
• Replacement Infrared Heating Element – Manufacturer-listed element Part No. 01360102, model 64337-042, rated at 120 V and 1,450 W. Verify compatibility with the exact heater configuration before ordering.
• Replacement Wire Guard and Housing Components – Use manufacturer-approved replacement parts selected from TPI Corporation's official parts documentation for the FSP-1412-1C.

Targeted Radiant Heating with the TPI Corporation FSP-1412-1C

Provide localized electric radiant heat with the TPI Corporation FSP-1412-1C Portable Infrared Heater. Combining 4,947 BTU/h of heating output with a 1,450 W flat-panel emitter, 78.5% published radiant efficiency, a 60-degree symmetric heat pattern, and a durable gold-anodized aluminum housing, this portable heater supports targeted heating in suitable workshops, maintenance areas, and industrial workspaces. Its aluminized steel base, large carry handle, heavy-duty wire guard, and 15-foot factory-installed power cord provide practical portability and convenient connection to a compatible 120 V electrical supply.
