TPI 10KW Portable Electric Salamander Heater | 240V

Durable Industrial Design 34,130 BTU Portable Electric Salamander Heater for Commercial & Industrial Applications with Adjustable Thermostat & High-Volume Airflow

The TPI Corporation Heat Wave™ FES-1024-1CA is a 10 kW portable electric salamander heater designed to provide supplemental heating for construction sites, workshops, industrial facilities, commercial buildings, and other suitable indoor or protected outdoor environments. Delivering 34,130 BTU/h of heating capacity from a 240 V, single-phase electrical supply, this forced-air heating system combines long-life finned tubular heating elements, an 800 CFM blower, and an adjustable thermostat to provide targeted temperature control. Its durable yellow steel enclosure, protective air intake and discharge screens, and portable cart with 10-inch wheels support convenient deployment between work areas. A factory-installed 10-foot power cable with a straight-blade range plug simplifies electrical connection to a compatible supply, while the automatic-reset high-limit thermal cutout provides overtemperature protection.

Key Benefits

• 34,130 BTU/h Heating Capacity – Provides high-output supplemental heating for suitable construction, commercial, and industrial applications.
• 10 kW Electric Heating Performance – Delivers 10,000 W of heating power using a compatible 240 V, single-phase electrical supply.
• Finned Tubular Heating Elements – Provide durable electric heat transfer for repeated use in demanding work environments.
• 800 CFM Forced-Air Circulation – Distributes heated air throughout the intended work area to support supplemental space heating.
• Adjustable Thermostat – Provides a temperature adjustment range of approximately 40°F to 100°F for convenient heating control.
• Fan-Only Operation – Allows air circulation without energizing the heating elements when the operating mode is selected appropriately.
• Automatic-Reset High-Limit Protection – Helps protect the heater against excessive operating temperatures.
• Magnetic Contactor – Supports electrical switching of the heater's heating load.
• Portable Cart with 10-Inch Wheels – Facilitates transportation and repositioning between suitable work locations.
• Protective Intake and Discharge Screens – Help guard the air openings and internal components during operation.
• Factory-Installed Power Cable – Includes a 10-foot cable and straight-blade range plug for connection to a compatible electrical supply.
• ETL Certification – The manufacturer's product literature identifies the FES series as ETL listed for the United States and Canada; verify the exact unit's certification marking.

34,130 BTU/h Heating Performance for Demanding Applications

The TPI Corporation Heat Wave™ FES-1024-1CA delivers a rated heating output of 34,130 BTU/h from its 10 kW electric heating system. Designed for supplemental space heating, the unit combines high-output electric heat with forced-air circulation to distribute warmth throughout an appropriate work area. The manufacturer specifies a temperature rise of approximately 30°F under its stated operating conditions. Actual temperature rise and heating coverage depend on ambient temperature, room dimensions, insulation, air infiltration, duct or airflow restrictions, and other site conditions. Select the heater according to the heating requirements of the intended application and the available electrical supply.

Long-Life Finned Tubular Electric Heating Technology

The TPI Corporation Heat Wave™ FES-1024-1CA uses finned tubular electric heating elements to transfer thermal energy to the moving air stream. As the elements heat, the integrated blower circulates air through the heater and distributes the resulting warm air into the surrounding space. This electric heating design eliminates the need for onsite propane, kerosene, or diesel fuel and does not produce combustion exhaust. The finned tubular elements are designed for long service life in suitable operating environments. Operate the heater according to the manufacturer's instructions, maintain the required clearances, and ensure that the electrical supply and surrounding conditions are appropriate for the unit.

800 CFM Airflow & Forced-Air Heat Distribution

The TPI Corporation Heat Wave™ FES-1024-1CA provides a manufacturer-rated airflow of 800 cubic feet per minute (CFM). Its integrated fan circulates air across the finned heating elements to distribute heated air into the intended work area. This forced-air configuration supports supplemental heating in workshops, construction areas, and other suitable spaces where active air circulation is beneficial. The heater also offers a fan-only operating mode for air circulation without active electric heating. Keep the air intake and discharge openings unobstructed, and follow the manufacturer's instructions regarding airflow, placement, and operating clearances.

Portable Steel Construction & Flexible Placement

The TPI Corporation Heat Wave™ FES-1024-1CA features a durable yellow steel enclosure with protective screens at the air intake and discharge openings. Its portable cart and 10-inch wheels support movement between suitable job-site and industrial locations. The manufacturer lists an approximate unit weight of 60 lb. The cart-mounted configuration allows the heater to be positioned where supplemental heating is needed without requiring permanent HVAC installation. Place the unit on a stable surface, maintain the manufacturer's specified clearances, and position the heater so that heated air can circulate freely. Disconnect the electrical supply and allow the unit to cool before moving or servicing it.

Electrical Power & Energy Consumption

The TPI Corporation Heat Wave™ FES-1024-1CA operates on a 240 V, 50/60 Hz, single-phase electrical supply. Its rated heating input is 10 kW, with a manufacturer-published current rating of 42 A. The unit is supplied with a factory-installed 10-foot power cable and a straight-blade range plug. Verify the plug configuration, receptacle compatibility, circuit capacity, overcurrent protection, grounding, and electrical installation requirements against the heater's nameplate and current manufacturer's documentation before use. The electrical circuit must be suitable for the heater's rated load and starting characteristics. Do not use an incompatible receptacle or an inadequately rated extension cord. Electrical installation must comply with applicable codes and the manufacturer's instructions.

Adjustable Thermostat & Operating Modes

The TPI Corporation Heat Wave™ FES-1024-1CA features an adjustable thermostat with a published temperature setting range of approximately 40°F to 100°F. This control allows the heater to regulate heating operation according to the selected temperature setting and surrounding conditions. The heater also provides a fan-only operating mode for air circulation without active heating. A magnetic contactor supports switching of the electrical heating load, while the automatic-reset high-limit thermal cutout helps protect against excessive temperatures. Maintain unobstructed airflow and follow the manufacturer's operating and troubleshooting instructions if the high-limit protection activates.

Construction, Workshop & Commercial Applications

The TPI Corporation Heat Wave™ FES-1024-1CA is designed for supplemental heating in construction sites, new building developments, workshops, industrial facilities, and suitable commercial environments. Its 34,130 BTU/h heating capacity and 800 CFM airflow support temporary heating requirements where an appropriate electrical supply is available. The portable cart allows the unit to be repositioned as work areas and heating needs change. Because the heater uses electric resistance heating rather than fuel combustion, it does not require a fuel tank or combustion exhaust system. Confirm that the intended location is suitable for electric heater operation and that the installation complies with the manufacturer's requirements and applicable workplace safety regulations.

Mobility & Deployment

The Heat Wave™ FES-1024-1CA is equipped with a portable cart and 10-inch wheels to facilitate transportation between suitable work areas. Its approximately 60 lb unit weight should be considered when planning movement, loading, and unloading. Position the heater on a stable surface and orient the discharge toward the intended heating area without directing hot air toward combustible materials or sensitive equipment. Route the 10-foot power cable to avoid hot surfaces, pinch points, vehicle traffic, and trip hazards. Disconnect electrical power before relocating, cleaning, or servicing the heater, and allow hot components to cool before handling.

Safety, Service & Maintenance

The TPI Corporation Heat Wave™ FES-1024-1CA incorporates an automatic-reset high-limit thermal cutout to help protect against excessive operating temperatures. Protective screens cover the air intake and discharge openings, and the unit uses a magnetic contactor to support switching of the heating load. Regularly inspect the enclosure, wheels, power cable, plug, electrical connections, fan, heating elements, and protective screens for damage or wear. Keep the air openings clear of dust, lint, and other obstructions to maintain airflow and reduce overheating risk. Disconnect the electrical supply and allow the heater to cool before cleaning or performing maintenance. If the high-limit protection activates repeatedly, discontinue use and investigate the cause according to the manufacturer's troubleshooting instructions. Never bypass safety devices or operate the heater with damaged electrical components or obstructed airflow. Electrical repairs must be performed by appropriately qualified personnel using manufacturer-approved replacement parts.

Warranty

Warranty coverage for the TPI Corporation Heat Wave™ FES-1024-1CA is subject to the manufacturer's applicable written warranty terms. Refer to TPI Corporation's current warranty documentation for the coverage period, covered components, exclusions, claim procedures, and any registration or installation requirements. Confirm the warranty applicable to the specific model and purchase before ordering.

Recommended Accessories

• Optional 25-Foot SO-Type Power Cord – TPI Corporation offers optional 25-foot SO-type oil-resistant power cords for compatible FES-series models. The optional cord is supplied without a plug. Verify compatibility with the FES-1024-1CA, conductor requirements, current rating, and appropriate plug configuration before ordering.
• Compatible 240 V Electrical Receptacle – Provide a receptacle compatible with the factory-installed straight-blade range plug and the heater's 42 A rated load. Confirm the exact plug configuration and circuit requirements using the unit nameplate and manufacturer's documentation.
• Replacement Finned Tubular Heating Elements – Select manufacturer-approved heating elements specifically listed for the FES-1024-1CA using TPI Corporation's official parts documentation.
• Replacement High-Limit Thermal Cutout – Use the manufacturer-approved replacement safety component specified for the FES-1024-1CA.
• Replacement Fan and Electrical Components – Select manufacturer-approved replacement parts for the blower, magnetic contactor, switches, and other serviceable components using the official TPI Corporation parts documentation.

High-Output Portable Electric Heating with the TPI Corporation Heat Wave™ FES-1024-1CA

Provide dependable supplemental heating with the TPI Corporation Heat Wave™ FES-1024-1CA Portable Electric Salamander Heater. Combining 34,130 BTU/h of heating capacity with a 10 kW electric heating system, 800 CFM forced-air circulation, and an adjustable 40°F to 100°F thermostat, this portable heater supports temporary heating applications in suitable commercial and industrial environments. Its finned tubular heating elements, automatic-reset high-limit protection, fan-only operation, yellow steel enclosure, and portable cart with 10-inch wheels provide practical functionality for changing job-site heating requirements. The factory-installed 10-foot cable and straight-blade range plug provide a convenient connection when used with a compatible 240 V electrical installation.
