TPI 30KW Portable Electric Salamander Heater | 480V

Versatile 102,390 BTU 30 kW Portable Electric Salamander Heater for Commercial & Industrial Applications with High-Volume Forced-Air Heating

The TPI Corporation Heat Wave™ FES-3048-3A is a 30 kW portable electric salamander heater designed to provide high-output supplemental heating for construction sites, warehouses, workshops, manufacturing facilities, and other suitable commercial and industrial environments. Delivering 102,390 BTU/h of heating capacity from a 480 V, three-phase electrical supply, this portable heating system combines long-life finned tubular heating elements, forced-air circulation, and an adjustable thermostat to support temporary heating requirements. Its safety-yellow steel enclosure, protective air intake and discharge screens, and heavy-duty cart with 10-inch wheels facilitate deployment between work areas. The heater also features a 90-degree housing pivot adjustment, fan-only operation, and an automatic-reset high-limit thermal cutout to support practical operation in demanding work environments.

Key Benefits

• 102,390 BTU/h Heating Capacity – Provides high-output supplemental heating for suitable construction, commercial, and industrial applications.
• 30 kW Electric Heating Performance – Delivers 30,000 W of heating power using a compatible 480 V, three-phase electrical supply.
• Long-Life Finned Tubular Heating Elements – Transfer heat to the moving air stream for dependable electric space heating.
• 800 CFM Forced-Air Circulation – Distributes heated air throughout the intended work area to support temporary heating requirements.
• Adjustable Thermostat – Provides a temperature adjustment range of approximately 40°F to 100°F for convenient heating control.
• Fan-Only Operation – Allows air circulation without active heating when the fan-only mode is selected.
• Automatic-Reset High-Limit Protection – Helps protect the heater against excessive operating temperatures.
• 90-Degree Pivoting Housing – Allows the heater housing to be adjusted around its center axis for flexible heat direction.
• Heavy-Duty Cart with 10-Inch Wheels – Supports transportation and repositioning between suitable job-site and industrial work areas.
• Safety-Yellow Steel Enclosure – Provides a durable housing with protective screens over the air intake and discharge openings.
• Optional 25-Foot Power Cord – Supports compatible electrical installations using an appropriately rated SO-type oil-resistant cable and a separately selected plug.
• ETL Listed – The manufacturer's product literature identifies the FES series as ETL listed for the United States and Canada; verify the certification marking on the specific unit.

102,390 BTU/h Heating Performance for Demanding Applications

The TPI Corporation Heat Wave™ FES-3048-3A delivers a rated heating output of 102,390 BTU/h from its 30 kW electric heating system. This high-output capacity supports temporary space heating in appropriately sized commercial and industrial environments. The manufacturer-published specifications list a temperature rise of approximately 45°F under specified operating conditions. Actual temperature rise and heating coverage depend on ambient temperature, room dimensions, insulation, air infiltration, airflow restrictions, and other site conditions. Select the heater according to the calculated heating requirements of the intended application and the electrical supply available at the installation location.

Long-Life Finned Tubular Electric Heating Technology

The TPI Corporation Heat Wave™ FES-3048-3A uses finned tubular electric heating elements to transfer thermal energy to the moving air stream. As the elements heat, the integrated fan circulates air across them and distributes the resulting warm air into the surrounding space. This electric resistance heating design eliminates the need for onsite propane, kerosene, or diesel fuel and does not produce combustion exhaust. The finned tubular elements are designed for long service life under suitable operating conditions. Operate the heater according to the manufacturer's instructions, maintain the required clearances, and ensure that the electrical supply and surrounding environment are appropriate for the unit.

800 CFM Airflow & Forced-Air Heat Distribution

The TPI Corporation Heat Wave™ FES-3048-3A provides a manufacturer-published airflow rating of 800 cubic feet per minute (CFM). Its integrated fan circulates air across the finned heating elements to distribute heated air into the intended work area. This forced-air configuration supports supplemental heating in workshops, construction areas, warehouses, and other suitable spaces where active air circulation is beneficial. The heater also provides a fan-only operating mode for air circulation without active electric heating. Keep the air intake and discharge openings unobstructed, and follow the manufacturer's instructions regarding airflow, placement, and operating clearances.

Portable Steel Construction & Flexible Placement

The TPI Corporation Heat Wave™ FES-3048-3A features a safety-yellow steel enclosure with protective screens covering the air intake and discharge openings. Its heavy-duty cart, handle, and 10-inch wheels facilitate transportation between suitable job-site and industrial locations. The manufacturer lists an approximate unit weight of 83 lb. The housing features a 90-degree pivot adjustment from the center axis, allowing the discharge direction to be adjusted for suitable heating arrangements. The cart-mounted configuration allows the heater to be positioned where supplemental heating is needed without requiring permanent HVAC installation. Place the unit on a stable surface, maintain the manufacturer's specified clearances, and allow the heater to cool before moving or servicing it.

Electrical Power & Energy Management

The TPI Corporation Heat Wave™ FES-3048-3A operates on a 480 V, three-phase electrical supply and provides 30 kW of rated heating output. The manufacturer's published specifications list a current rating of 36 A. An optional 25-foot SO-type oil-resistant power cord is available for compatible installations; the manufacturer identifies a 6/4 SO cord configuration for this model. The optional cord is supplied without a plug, so the appropriate connector must be selected for the electrical installation. Verify the unit nameplate, electrical frequency, circuit capacity, overcurrent protection, grounding, conductor sizing, and connection requirements before installation. Do not assume that a standard household receptacle or plug is suitable for this industrial heater. Electrical installation must comply with applicable codes and the manufacturer's instructions.

Adjustable Thermostat & Operating Modes

The TPI Corporation Heat Wave™ FES-3048-3A features an adjustable thermostat with a published temperature setting range of approximately 40°F to 100°F. This control supports heating operation according to the selected temperature setting and surrounding conditions. The fan-only operating mode allows air circulation without active heating. The unit also incorporates an automatic-reset high-limit thermal cutout to help protect against excessive operating temperatures. Maintain unobstructed airflow and follow the manufacturer's operating and troubleshooting instructions if the high-limit protection activates. If the protection repeatedly interrupts operation, discontinue use and have the cause investigated by qualified service personnel.

Construction, Workshop & Commercial Applications

The TPI Corporation Heat Wave™ FES-3048-3A is designed for supplemental heating in construction sites, warehouses, workshops, manufacturing facilities, maintenance areas, and other suitable commercial and industrial environments. Its 102,390 BTU/h heating capacity and 800 CFM airflow support temporary heating requirements where compatible 480 V three-phase electrical power is available. The portable cart allows the unit to be repositioned as work areas and heating requirements change. Because the heater uses electric resistance heating rather than fuel combustion, it does not require an onsite fuel tank or combustion exhaust system. Confirm that the intended location is suitable for electric heater operation and that the installation complies with the manufacturer's requirements and applicable workplace safety regulations.

Mobility & Deployment

The Heat Wave™ FES-3048-3A is equipped with a heavy-duty handle, cart assembly, and 10-inch wheels to facilitate transportation between suitable work areas. Its approximate 83 lb weight should be considered when planning movement, loading, and unloading. The 90-degree pivoting housing allows directional adjustment within the limits of the manufacturer's instructions. Position the heater on a stable surface and direct the discharge toward the intended heating area without directing hot air toward combustible materials or sensitive equipment. Route the electrical cable to avoid hot surfaces, pinch points, vehicle traffic, and trip hazards. Disconnect electrical power and allow hot components to cool before relocating, cleaning, or servicing the heater.

Safety, Service & Maintenance

The TPI Corporation Heat Wave™ FES-3048-3A incorporates an automatic-reset high-limit thermal cutout to help protect against excessive operating temperatures. Protective screens cover the air intake and discharge openings, while the integrated fan supports forced-air heat distribution. Regularly inspect the enclosure, cart, wheels, handle, power connections, electrical wiring, fan, heating elements, and protective screens for damage or wear. Keep the air openings clear of dust, lint, and other obstructions to maintain airflow and reduce overheating risk. Disconnect the electrical supply and allow the heater to cool before cleaning or performing maintenance. If the high-limit protection activates repeatedly, discontinue use and investigate the cause according to the manufacturer's troubleshooting instructions. Never bypass safety devices or operate the heater with damaged electrical components or obstructed airflow. Electrical repairs must be performed by appropriately qualified personnel using manufacturer-approved replacement parts.

Warranty

Warranty coverage for the TPI Corporation Heat Wave™ FES-3048-3A is subject to the manufacturer's applicable written warranty terms. Refer to TPI Corporation's current warranty documentation for the coverage period, covered components, exclusions, claim procedures, and any registration or installation requirements. Confirm the warranty applicable to the specific model and purchase before ordering.

Recommended Accessories

• Optional 25-Foot SO-Type Power Cord – TPI Corporation lists an optional 25-foot, 6/4 SO-type oil-resistant power cord for the FES-3048-3A. The cord is supplied without a plug. Verify the required connector, electrical ratings, and installation compatibility before ordering.
• Compatible 480 V Three-Phase Electrical Connection – Provide an appropriately rated circuit, overcurrent protection, grounding, and connection hardware based on the unit nameplate and manufacturer's wiring instructions.
• Replacement Finned Tubular Heating Elements – Select manufacturer-approved heating elements specifically listed for the FES-3048-3A using TPI Corporation's official replacement-parts documentation.
• Replacement High-Limit Thermal Cutout – Use the manufacturer-approved replacement safety component specified for the FES-3048-3A.
• Replacement Fan and Electrical Components – Select manufacturer-approved replacement parts for the blower, thermostat, switches, and other serviceable components using TPI Corporation's official parts documentation.
• Replacement Wheels and Cart Components – Use compatible manufacturer-approved replacement parts to maintain safe mobility and structural support.

High-Output Portable Electric Heating with the TPI Corporation Heat Wave™ FES-3048-3A

Provide dependable supplemental heating with the TPI Corporation Heat Wave™ FES-3048-3A Portable Electric Salamander Heater. Combining 102,390 BTU/h of heating capacity with a 30 kW electric heating system, 800 CFM forced-air circulation, and an adjustable 40°F to 100°F thermostat, this portable heater supports temporary heating applications in suitable commercial and industrial environments. Its finned tubular heating elements, automatic-reset high-limit protection, fan-only operation, safety-yellow steel enclosure, and heavy-duty cart with 10-inch wheels provide practical functionality for changing job-site heating requirements. Designed for a compatible 480 V three-phase electrical supply, the FES-3048-3A delivers high-output electric heating without onsite fuel storage or combustion exhaust.
