TPI 4.30 KW Portable Infrared Flat Panel Emitter | 240V

Direct Heat Delivery 14,972 BTU Heavy-Duty Portable Infrared Electric Heater for Industrial & Commercial Applications with Targeted Radiant Heat

The TPI Corporation FSP-4324-3 is a heavy-duty portable infrared electric heater designed to provide targeted radiant heat for industrial workstations, manufacturing facilities, maintenance areas, and other suitable commercial and industrial environments. Delivering 4,300 W of heating power at 240 V, this heater produces approximately 14,972 BTU/h using a flat-panel infrared emitter that transfers heat directly to people and objects within its radiant heating pattern. Its gold-anodized aluminum housing provides reflectivity and corrosion resistance, while the heavy-duty wire guard helps protect the heating element and personnel. Mounted on a portable steel handcart with 6-inch wheels, the heater supports convenient transportation between suitable work areas. The FSP-4324-3 is designed for a compatible 240 V electrical supply and three-phase operation.

Key Benefits

• 4,300 W Heating Capacity – Delivers approximately 14,972 BTU/h of radiant heating output for localized supplemental heating in suitable industrial and commercial environments.
• Infrared Radiant Heating Technology – Transfers heat directly to people and objects within the radiation pattern rather than relying exclusively on warming the surrounding air.
• Heavy-Duty Flat-Panel Emitter – Provides focused radiant heat for industrial workstations and targeted heating applications.
• Gold-Anodized Aluminum Housing – Provides reflective properties and corrosion resistance for demanding service environments.
• Portable Steel Handcart – Features 6-inch wheels to support movement between suitable work locations.
• Heavy-Duty Wire Guard – Helps protect the heating element and personnel from direct contact with the emitter.
• 240 V Electrical Operation – Provides 4,300 W of heating performance when connected to a compatible electrical supply.
• Three-Phase Electrical Configuration – Supports compatible industrial electrical installations where three-phase power is available.
• Localized Heat Delivery – Provides radiant warmth to designated work areas without requiring a fuel supply, combustion burner, or combustion exhaust system.

14,672 BTU/h Radiant Heating Performance

The TPI Corporation FSP-4324-3 delivers 4,300 W of electrical heating power, equivalent to approximately 14,972 BTU/h. Its infrared heating system is designed to transfer thermal energy directly to objects and people within the effective radiation pattern. This makes the heater suitable for localized supplemental heating where warming a designated work area is preferable to heating an entire building volume. Actual heating performance depends on the distance between the heater and the target area, ambient temperature, surrounding surfaces, air movement, and other environmental conditions. Position the heater according to the manufacturer's instructions to achieve suitable radiant coverage while maintaining required safety clearances.

Heavy-Duty Flat-Panel Infrared Heating Technology

The TPI Corporation FSP-4324-3 uses the FSP Series flat-panel infrared emitter technology to provide radiant heat for industrial and commercial applications. The electrical heating element converts electrical energy into infrared radiation, which transfers heat to surfaces and objects within its radiation pattern. Its gold-anodized aluminum housing provides reflectivity and corrosion resistance, while the heavy-duty wire guard helps protect the emitter and personnel. Because the heater uses radiant heating rather than conventional fan-forced heat distribution, a blower airflow rating in cubic feet per minute (CFM) is not applicable. Follow the manufacturer's instructions for positioning, electrical connection, operating clearances, and protection of nearby combustible materials.

Targeted Radiant Heat Distribution

The FSP-4324-3 is designed to direct radiant energy toward a designated work area. Its flat-panel emitter and reflective housing support localized heating without requiring forced-air circulation. This configuration is suitable for applications where heat is needed at a workstation, maintenance position, or other defined area. Radiant heating performance depends on the heater's orientation, distance from the target, and the characteristics of the surfaces receiving the heat. Position the unit to provide appropriate coverage and avoid obstructing the emitter or placing combustible materials within prohibited clearance zones.

Portable Construction & Flexible Placement

The TPI Corporation FSP-4324-3 features a portable steel handcart with 6-inch wheels to facilitate transportation between suitable job-site and industrial locations. Its gold-anodized aluminum housing provides reflective and corrosion-resistant properties, while the heavy-duty wire guard helps protect the heating element. The FSP-43 series documentation lists approximate dimensions of 17.5 inches, 20 inches, and 37.5 inches, with an approximate weight of 32 lb for the documented series configuration. Verify the exact dimensions and weight for the FSP-4324-3 against the current manufacturer specification before planning installation or transport. Position the heater on a stable surface, keep it clear of combustible materials, and allow the unit to cool before moving or handling it.

Electrical Power & Energy Consumption

The TPI Corporation FSP-4324-3 is rated for 240 V electrical operation with a 4,300 W heating load. The manufacturer identifies the model within the FSP-43 series of portable infrared heaters and specifies a three-phase configuration. The published series documentation lists an approximate current draw of 10.36 A at 240 V for three-phase operation. Verify the exact nameplate current, electrical frequency, phase configuration, grounding requirements, branch-circuit rating, and connection method before installation. The model-specific manufacturer documentation should be used to confirm the required electrical connection; do not assume that a standard household plug or receptacle is suitable. Electrical installation must comply with the manufacturer's instructions and applicable electrical codes.

Radiant Comfort & Heating Control

The TPI Corporation FSP-4324-3 provides radiant heat while energized and correctly positioned toward the intended heating area. Its flat-panel emitter directs thermal energy toward people and objects within the radiation pattern, supporting localized heating without a fan or fuel-burning system. An integrated adjustable thermostat, digital temperature display, timer, or remote control is not confirmed in the manufacturer's published documentation for this model. If external temperature controls are required, verify their electrical compatibility and suitability with TPI Corporation before use.

Industrial, Manufacturing & Commercial Applications

The TPI Corporation FSP-4324-3 is intended for suitable industrial and commercial applications requiring localized electric radiant heat. Potential applications include manufacturing workstations, maintenance areas, workshops, assembly areas, and other environments where targeted heating is appropriate. Its 4,300 W heating capacity provides approximately 14,972 BTU/h of radiant output, while the portable handcart supports movement between suitable work areas. The electric heating design eliminates the need for onsite fuel storage or a combustion exhaust system. Before selecting the heater, confirm that the intended application, electrical supply, environmental conditions, mounting or placement arrangement, and required clearances meet the manufacturer's specifications and applicable safety regulations.

Mobility & Deployment

The FSP-4324-3 belongs to the TPI Corporation FSP-43 series, which uses a steel handcart equipped with 6-inch wheels for transportation to suitable job-site locations. This portable arrangement supports repositioning as heating requirements change. Move the heater only when it is switched off, disconnected from electrical power, and sufficiently cool to handle. Secure the unit during transportation and keep the power connection protected from mechanical damage. When deployed, position the heater on a stable surface, orient the emitter toward the intended heating zone, and maintain the manufacturer's specified clearances from combustible materials and other obstructions.

Safety, Service & Maintenance

The TPI Corporation FSP-4324-3 incorporates a heavy-duty wire guard designed to help protect the heating element and personnel. Its gold-anodized aluminum housing provides reflective properties and corrosion resistance, while the steel handcart supports portable deployment. Regularly inspect the emitter, wire guard, housing, cart, wheels, electrical connections, and power-supply components for damage or wear. Keep the heating element and surrounding components clean according to the manufacturer's maintenance instructions. Disconnect electrical power and allow the heater to cool completely before cleaning, inspecting, or servicing the unit. Do not operate the heater with a damaged electrical connection, compromised wire guard, or damaged heating element. Maintain the required clearances and never bypass safety provisions. Electrical repairs and replacement of heating components must be performed by appropriately qualified personnel using manufacturer-approved parts.

Warranty

Warranty coverage for the TPI Corporation FSP-4324-3 is subject to the manufacturer's applicable written warranty terms. Refer to TPI Corporation's current warranty documentation for the coverage period, covered components, exclusions, claim procedures, and any registration or installation requirements. Confirm the warranty applicable to the specific model and purchase before ordering.

Recommended Accessories

• Compatible 240 V Three-Phase Electrical Connection – Provide an appropriately rated electrical connection, branch circuit, and grounding arrangement based on the exact heater nameplate and manufacturer's installation instructions.
• Replacement Infrared Heating Element – Select the manufacturer-approved heating element specifically listed for the FSP-4324-3 using TPI Corporation's official replacement-parts documentation.
• Replacement Wire Guard – Use the manufacturer-approved replacement guard compatible with the FSP-43 series configuration.
• Replacement Housing and Handcart Components – Select manufacturer-approved replacement wheels, cart components, and housing parts using the official TPI Corporation parts documentation.
• Electrical Service Components – Use appropriately rated connectors, wiring, and protective devices selected by a qualified electrician according to the unit nameplate and applicable electrical codes.

Targeted Industrial Radiant Heating with the TPI Corporation FSP-4324-3

Provide targeted supplemental heat with the TPI Corporation FSP-4324-3 Heavy-Duty Portable Infrared Heater. Combining 4,300 W of heating power with approximately 14,972 BTU/h of radiant output, a flat-panel infrared emitter, a gold-anodized aluminum housing, and a heavy-duty wire guard, this heater supports localized heating in suitable industrial and commercial environments. Its portable steel handcart with 6-inch wheels facilitates movement between work areas, while its 240 V three-phase electrical configuration supports compatible industrial installations.
