TPI 4200/5600W Fan Forced Portable Unit Heater | 208/240V

Rapid Heat Circulation 19,107 BTU Fan-Forced Portable Electric Heater for Commercial & Industrial Spaces with Adjustable Mounting Flexibility

The TPI Corporation HF686TC 680 Series Bulldog Fan-Forced Portable Unit Heater is a compact electric heater designed to provide supplemental heating for workshops, garages, utility areas, maintenance spaces, and other suitable indoor environments. Delivering up to 19,107 BTU/h at 240 V and 14,330 BTU/h at 208 V, this single-phase heating system combines a finned steel tubular heating element, forced-air circulation, and an adjustable temperature-control thermostat for targeted heating. Its swivel mounting base supports wall, floor, or ceiling mounting in approved configurations, providing flexibility for different space requirements. The integrated fan delivers 262 CFM of airflow with an approximately 10-foot air throw, while the internal manual-reset thermal cut-out provides additional overtemperature protection.

Key Benefits

• High-Output Electric Heating – Delivers 5,600 W at 240 V or 4,200 W at 208 V to provide supplemental heat for suitable indoor spaces.
• Up to 19,107 BTU/h Heating Capacity – Provides high-output heating performance for workshops, maintenance areas, garages, and other compatible applications.
• Finned Steel Tubular Heating Element – Transfers heat to the moving air for effective fan-forced space heating.
• 262 CFM Airflow – Circulates heated air with a published air throw of approximately 10 feet to distribute warmth into the surrounding area.
• Adjustable Temperature Control – Features an integrated thermostat with a 60°F to 110°F adjustment range for convenient temperature management.
• Swivel Mounting Base – Accommodates wall, floor, or ceiling mounting in approved configurations to support flexible installation.
• Manual-Reset Thermal Protection – Incorporates an internal manual-reset thermal cut-out to help protect against overheating.
• Compact Construction – Weighs approximately 20 lb, supporting convenient handling and installation.
• Factory-Installed Power Cord – Includes a 6-foot cord with a molded plug for connection to a compatible electrical supply.

19,107 BTU/h Heating Performance for Supplemental Space Heating

The TPI Corporation HF686TC provides a maximum heating output of 19,107 BTU/h at 240 V and 14,330 BTU/h at 208 V. Its rated electrical input is 5,600 W at 240 V or 4,200 W at 208 V, making it suitable for supplemental heating in appropriately sized indoor spaces. Manufacturer-published specifications list a temperature rise of approximately 75°F under the specified test conditions. Actual room temperature performance depends on ambient temperature, insulation, air infiltration, room dimensions, and other environmental factors. Select the operating voltage and heater capacity according to the available electrical supply and the heating requirements of the intended application.

Finned Steel Tubular Electric Heating Technology

The TPI Corporation HF686TC uses a finned steel tubular heating element to convert electrical energy into heat. As the element warms, the integrated fan moves air across the heated surface, transferring thermal energy into the surrounding space. This fan-forced design distributes heat without requiring a fuel supply, combustion burner, or combustion exhaust system. The heater operates on a compatible 208 V or 240 V, single-phase electrical supply. Install and operate the unit in accordance with the manufacturer's instructions, required clearances, and applicable electrical and building codes.

262 CFM Airflow & Forced-Air Heat Distribution

The TPI Corporation HF686TC delivers approximately 262 cubic feet per minute (CFM) of airflow, with a published air throw of approximately 10 feet. The integrated fan circulates heated air away from the unit to support localized temperature control and supplemental space heating. Its forced-air operation helps distribute warmth beyond the immediate surface of the heating element. Maintain unobstructed air intake and discharge openings, and position the heater to allow adequate air circulation. Do not cover the heater or obstruct airflow during operation.

Compact Design & Flexible Mounting

The TPI Corporation HF686TC features a compact housing measuring approximately 13.5 inches wide, 17.5 inches high, and 11.5 inches deep. Its approximate operating weight is 20 lb. The swivel base accommodates wall, floor, or ceiling mounting in approved configurations, allowing the heater to be positioned according to the available space and intended heat distribution. The unit can be positioned as permitted by the manufacturer's instructions or secured using an appropriate mounting arrangement. An optional wall/ceiling mounting bracket, catalog number A1560, is listed in the manufacturer's documentation for compatible 680 Series and ICH 240C Series heaters. Confirm compatibility with the HF686TC before ordering. Ensure that the supporting surface or structure can accommodate the heater and that all required clearances are maintained.

Electrical Power & Energy Consumption

The TPI Corporation HF686TC operates on a 208 V or 240 V, single-phase electrical supply and is rated for 50/60 Hz operation. Its electrical input is 4,200 W at 208 V and 5,600 W at 240 V. Manufacturer-published current ratings are approximately 20.2 A at 208 V and 23.3 A at 240 V. The unit is supplied with a 6-foot power cord and a molded NEMA 6-30P plug, as specified for the HF685TC and HF686TC models in the manufacturer's 680 Series catalog. Verify the receptacle, circuit capacity, overcurrent protection, grounding, and connection requirements against the heater nameplate and current manufacturer's documentation before installation. Do not connect the heater to an incompatible receptacle or electrical supply. Electrical work must be performed by appropriately qualified personnel in accordance with applicable codes.

Controls, Comfort & Temperature Management

The TPI Corporation HF686TC incorporates a temperature-control thermostat with a published adjustment range of approximately 60°F to 110°F. This integrated control allows the user to regulate heating operation according to the surrounding temperature. The heater also incorporates an internal manual-reset thermal cut-out to help protect against overheating. Maintain adequate airflow around the unit and follow the manufacturer's reset and troubleshooting instructions if the thermal protection activates. Do not bypass or disable the thermal cut-out. Disconnect power before inspecting the unit or performing maintenance.

Commercial, Workshop & Industrial Applications

The TPI Corporation HF686TC is intended for suitable indoor applications requiring supplemental electric heat. Potential applications include workshops, garages, maintenance areas, utility rooms, and other appropriately sized indoor workspaces with a compatible electrical supply. Its 5,600 W maximum input at 240 V, adjustable thermostat, and flexible mounting base support a variety of suitable heating arrangements. The fan-forced design helps circulate heated air into the surrounding area, while the electric heating configuration eliminates the need for onsite fuel storage or a combustion exhaust system. Confirm that the intended location, electrical supply, mounting arrangement, and clearances comply with the manufacturer's requirements and applicable safety regulations.

Mounting Flexibility & Deployment

The TPI Corporation HF686TC features a swivel base designed to accommodate wall, floor, or ceiling mounting in approved configurations. Its approximately 20 lb weight and compact dimensions support handling during installation and relocation. The factory-installed 6-foot cord and NEMA 6-30P plug provide the specified electrical connection for compatible installations. Secure the heater according to the manufacturer's mounting instructions and use suitable fasteners and structural support for the selected arrangement. Maintain the specified separation from combustible materials, furnishings, and other obstructions. Disconnect electrical power before installation, relocation, cleaning, or servicing.

Safety, Service & Maintenance

The TPI Corporation HF686TC incorporates an internal manual-reset thermal cut-out designed to help protect against overheating. TPI Corporation's 680 Series documentation identifies the HF686TC as part of the fan-forced portable unit heater range. The manufacturer's published catalog specifically marks the HF684TC as UL listed only; do not assume that the same listing applies to the HF686TC without confirming the certification for the exact model. Regularly inspect the housing, power cord, plug, electrical connections, heating element, fan, and mounting hardware for damage or wear. Keep the air intake and discharge openings clear of dust, lint, and other obstructions. Disconnect power and allow the unit to cool before cleaning or performing maintenance. If the thermal cut-out activates repeatedly, discontinue use and investigate the cause according to the manufacturer's troubleshooting instructions. Never operate the heater with a damaged cord, obstructed airflow, loose mounting hardware, or compromised electrical components. Repairs and electrical servicing must be performed by appropriately qualified personnel.

Warranty

Warranty coverage for the TPI Corporation HF686TC is subject to the manufacturer's applicable written warranty terms. Refer to TPI Corporation's current warranty documentation for the coverage period, covered components, exclusions, claim procedures, and any registration or installation requirements. Confirm the warranty applicable to the specific model and purchase before ordering.

Recommended Accessories

• Optional Wall/Ceiling Mounting Bracket – Catalog number A1560, manufacturer catalog number 06835002. Listed for compatible HF680 and ICH 240C Series heaters. Confirm compatibility with the HF686TC and the intended mounting arrangement before ordering.
• Compatible 208/240 V Electrical Receptacle – Use a properly rated NEMA 6-30R receptacle and branch circuit compatible with the factory-installed NEMA 6-30P plug. Verify circuit and installation requirements against the unit nameplate and manufacturer's instructions.
• Replacement Heating Element – Select the manufacturer-approved replacement element for the HF686TC 208/240 V, 5,600/4,200 W configuration using TPI Corporation's official replacement-parts documentation.
• Replacement Thermostat and Thermal Cut-Out Components – Use manufacturer-approved replacement components specified for the HF686TC and its production configuration.

High-Output Supplemental Electric Heating with the TPI Corporation HF686TC

Provide flexible supplemental heating with the TPI Corporation HF686TC 680 Series Bulldog Fan-Forced Portable Unit Heater. Combining up to 19,107 BTU/h of heating output with a finned steel tubular heating element, 262 CFM of airflow, an adjustable 60°F to 110°F thermostat, and an internal manual-reset thermal cut-out, this compact electric heater supports suitable indoor heating applications. Its 208/240 V single-phase operation, lightweight construction, factory-installed power cord, and swivel mounting base provide flexibility for workshops, garages, utility areas, and other compatible spaces.
