VENTS-US Commercial Heat Recovery Ventilator (HRV), 120 Volts, 266 CFM, VUE 350 VB EC

With heat recovery for air filtering, fresh air supply, and stale air extraction, the air-handling units are ventilation systems with all the bells and whistles. The extremely effective plate heat exchanger transfers heat from the extract air to the supply air stream while it is running. Up to 266 CFM of airflow.

An enthalpy counter - flow heat exchanger is included with the VUE VB EC units. The enthalpy heat exchanger transfers heat and moisture from the extract air stream to the supply air stream during the cold season, minimizing heat losses via ventilation. In the warm season, the enthalpy heat exchanger transfers the heat and moisture from the ambient air to the exhaust air stream.

Features

• EC motors are characterised with high performance and optimum control across the entire speed range.
• Supply and exhaust air is purified in panel filters with filtering class MERV8 and MERV13
• Casing Made of high-quality polymer coated steel
• Equipped with a built-in automation system.
