18,000 BTU 20 SEER Wall Mounted Carrier Mini Split Performance Series Single Zone Heat Pump

By

Carrier

Out of stock
Model

40MAQB18B-3 / 38MAQB18R-3

ID

9767

Availability: Call for Availability

Authorized Carrier Dealer

AHRI Certified

AHRI Number:8738637

Description

OVERVIEW

The 40MAQB18B-3 / 38MAQB18R-3 Performance series single zone mini split is a heat pump solution with a wall mounted air handler for almost any space. With its wide heating and cooling range and quiet operation, the 40MAQB18B-3 / 38MAQB18R-3 is a reasonably priced solution for almost any application.

QUICK FACTS

  • Can generally heat and cool up to a medium-sized room in mild climates
  • 18,000 BTU, 22.5 SEER heat pump wall mounted mini split with remote control
  • Cooling from -13°F - 122°F outside temperatures
  • Integrated base pan heater allows heating from -22°F - 86°F outside temperatures
  • Built-in safety monitoring, including refrigerant leakage detection
  • Improved serviceability
  • Quiet and efficient operation
18,000 BTU, 22.5 SEER

With an output of 18,000 BTU, the 40MAQB18B-3 / 38MAQB18R-3 has the capability to heat and cool up to a medium-sized room in average climates. With an efficiency rating of 22.5 SEER, bringing comfort to that space is possible while maintaining a high efficiency over many other solutions, allowing you to keep more of your hard-earned money over time by not spending it on your electric bill.

Warranty

With an installation that follows your state and local installation codes and registration through the manufacturer within 90 days of installation, the 40MAQB18B-3 / 38MAQB18R-3 is backed by Carrier's 10 year parts and compressor warranty for the original registrant.

Quality of Comfort

With its many settings selectable from the unit's included remote, the 40MAQB18B-3 / 38MAQB18R-3 can match almost any comfort-based need, from its Follow Me setting that senses the temperature at the remote instead of at the unit to your standard, unchanged output setting. These settings along with others and its quiet operation allow the 40MAQB18B-3 / 38MAQB18R-3 to bring a high quality of comfort to almost any space.

Reliable Heating and Cooling

For a much more reliable operation, safety monitors all over the 40MAQB18B-3 / 38MAQB18R-3 are constantly taking readings to prevent any possible problems that may arise from general wear-and-tear on the unit. Moreover, the unit has an integrated base pan heater, allowing it to heat all the way down to -22°F.

Product Specifications

More Information
18,000 BTU 20 SEER Wall Mounted Carrier Mini Split Performance Series Single Zone Heat Pump
SKU40MAQB18B-3 / 38MAQB18R-3
Refrigerant ChargePre-charged for: 26'
Weight (in lbs)80.000000
AHRI Certificate Number8738637
Brand/ManufacturerCarrier
ControllerWireless Included
Additional InformationHeat Pump
Additional InformationMinimum Line Set Length: 10'
Additional InformationMaximum Line Set Length: 98'
Additional InformationDrain: 5/8"
HSPF10.5
Cooling BTU17,000 BTU
Heating BTU18,000 BTU
Maximum CFM310-680 CFM
Energy StarNo
RefrigerantR410A
CapacityDehumidification Rate: 0.475 gal/hr
SEER1 (Efficiency)18-20
EER12.5
Liquid Line1/4"
Suction Line1/2"
Electrical208/230V 1 Phase 60Hz
PhaseSingle Phase
Max Breaker Size25 Amps
Min. Breaker Size18 Amps
Amperage Requirement25A
Tonnage1.5 Ton
System Tonnage1.5 Ton
BTU/Tonnage18,000 BTU/1.5 Ton
Mini-Split TypeWall Mounted
Min/Max Outdoor Temp for Heating-22°F-86°F
Min/Max Outdoor Temp for Cooling-13°F-122°F
Zone CompatibilitySingle Zone
HeightIndoor Unit: 12.4" | Outdoor Unit: 27.63"
WidthIndoor Unit: 38.98" | Outdoor Unit: 33.66"
DepthIndoor Unit: 8.58" | Outdoor Unit: 14.17"
Warranty10 years with online registration, 5 years without
