24,000 BTU Mitsubishi FX-Series 20 SEER2 Three Zone Ceiling Cassette Mini Split Heat Pump System - R454B | 6 + 6 + 9

MSZ-FX06NL Air Handler Overview

The MSZ-FX06NL air handler is a compact, high-performance unit designed to deliver efficient cooling and heating for residential and light commercial applications. Paired with the MUZ-FX06NLHZ outdoor unit, this air handler ensures year-round comfort, offering reliable temperature control with minimal energy consumption. It combines advanced technologies, quiet operation, and a sleek design, making it a great choice for those seeking effective and cost-efficient climate control solutions.

Key Features

• High Energy Efficiency: The MSZ-FX06NL is built with energy-efficient features that help reduce operating costs without sacrificing performance, making it an environmentally-friendly option for both cooling and heating.
• Quiet Operation: Designed for low noise levels, the MSZ-FX06NL operates quietly, ensuring a comfortable indoor environment, especially in spaces like bedrooms, living rooms, or offices.
• Compact and Stylish Design: The sleek and compact design allows the MSZ-FX06NL to blend seamlessly into various interior spaces without taking up valuable room. Its aesthetic appeal fits well with modern and contemporary interiors.
• Advanced Filtration System: This air handler comes equipped with an advanced filtration system that helps purify the air by capturing dust, allergens, and other particles, thus contributing to a cleaner and healthier indoor environment.
• Corrosion-Resistant Coating: The MSZ-FX06NL is designed with a corrosion-resistant coating to ensure durability and extend the lifespan of the unit, even in environments where moisture or contaminants are present.

Specifications

• Cooling Capacity: 6,000 BTU/h
• Heating Capacity: 7,000 BTU/h
• Power Supply: 208-230V, 60Hz, 1-phase
• Dimensions: 33-7/16" (W) x 11-5/8" (H) x 25-1/4" (D)
• Weight: 24 lbs

Advanced Features and Benefits

• Hyper Heating Technology: The MSZ-FX06NL air handler features Hyper Heating technology, enabling it to provide effective heating even at extremely low outdoor temperatures, ensuring comfort throughout the year, regardless of climate conditions.
• Inverter Technology: Equipped with an inverter-driven compressor, the MSZ-FX06NL adjusts its output to match the cooling or heating demand, providing more efficient energy use and reducing wear on the system for improved longevity and performance.
• Remote Control: The unit comes with a user-friendly remote control, allowing convenient adjustments to temperature, fan speed, and operating mode from anywhere in the room, offering ease of use and flexibility in controlling the climate.
• Auto Restart Function: After a power outage, the MSZ-FX06NL automatically restarts and resumes operation with the previous settings, eliminating the need for manual reset and ensuring continuous operation without disruption.
• Self-Diagnosis and Error Reporting: The MSZ-FX06NL has a built-in self-diagnosis feature that detects potential issues and provides error codes for easy troubleshooting, helping to maintain the system's optimal performance and reducing the need for service calls.

Installation and Maintenance

• Flexible Installation: The MSZ-FX06NL is designed for simple and flexible installation. Its compact size and versatility allow it to be mounted in a variety of spaces, ideal for homes, offices, or small commercial applications.
• Low Maintenance Requirements: With easy-to-clean filters and a durable design, the MSZ-FX06NL requires minimal maintenance. Regular cleaning and occasional servicing ensure continued efficiency and long-term reliability.
• Washable Filters: The MSZ-FX06NL includes washable filters that can be easily removed and cleaned, ensuring consistent air quality and airflow, reducing the need for frequent replacements and extending the lifespan of the system.

Applications

• Residential Use: The MSZ-FX06NL is perfect for small to medium-sized homes or apartments, providing efficient climate control for living rooms, bedrooms, or home offices. Its quiet operation and compact design make it ideal for residential settings.
• Commercial Use: The MSZ-FX06NL is also suited for light commercial applications, such as offices, retail stores, and server rooms, where energy-efficient heating and cooling are essential for maintaining a comfortable environment.

In conclusion, the MSZ-FX06NL air handler offers an efficient, quiet, and compact solution for cooling and heating in residential and light commercial spaces. With features such as Hyper Heating technology, inverter-driven performance, advanced filtration, and low maintenance requirements, it ensures reliable comfort and energy savings year-round. Its sleek design and flexibility make it an excellent choice for various applications, providing long-lasting performance and improved air quality.

MSZ-FX09NL Air Handler Overview

The MSZ-FX09NL is a high-performance air handler designed to deliver efficient and reliable cooling and heating for residential and light commercial applications. When paired with the MUZ-FX09NLHZ outdoor unit, this air handler provides year-round comfort while maintaining low operating costs. Its energy-efficient operation, quiet performance, and compact design make it an ideal solution for spaces where both comfort and space are a priority.

Key Features

• Energy Efficiency: The MSZ-FX09NL is engineered for high energy efficiency, which helps reduce electricity consumption and lower utility bills while providing consistent comfort throughout the year.
• Quiet Operation: Operating at low sound levels, the MSZ-FX09NL ensures a peaceful indoor environment, making it ideal for residential areas, bedrooms, or offices where noise reduction is important.
• Compact and Sleek Design: The MSZ-FX09NL features a modern, compact design that fits seamlessly into various interior environments. Its small footprint makes it a versatile choice for tight spaces.
• Advanced Filtration: Equipped with a high-performance filtration system, the MSZ-FX09NL helps to remove dust, allergens, and other airborne particles, contributing to a healthier and cleaner indoor air quality.
• Corrosion-Resistant Coating: The air handler is built with a corrosion-resistant coating, ensuring durability and reliable performance, even in environments with higher humidity or moisture exposure.

Specifications

• Cooling Capacity: 9,000 BTU/h
• Heating Capacity: 10,900 BTU/h
• Power Supply: 208-230V, 60Hz, 1-phase
• Dimensions: 33-7/16" (W) x 11-5/8" (H) x 25-1/4" (D)
• Weight: 24 lbs

Advanced Features and Benefits

• Hyper Heating Technology: The MSZ-FX09NL incorporates Hyper Heating technology, enabling the system to provide efficient heating even in extremely low outdoor temperatures. This ensures consistent heating performance during cold weather.
• Inverter Technology: The air handler utilizes an inverter-driven compressor that adjusts its speed based on cooling or heating demand. This provides precise temperature control, enhances energy efficiency, and reduces wear on the system.
• Remote Control: The MSZ-FX09NL comes with a convenient remote control, allowing users to adjust temperature settings, fan speed, and operating modes from across the room, providing flexibility and ease of use.
• Auto Restart Function: If the unit experiences a power outage, it automatically restarts and resumes operation using the previous settings, eliminating the need for manual reset and ensuring uninterrupted comfort.
• Self-Diagnosis and Error Reporting: The air handler features a self-diagnosis system that detects potential issues and provides error codes for easier troubleshooting, ensuring the unit remains in optimal condition and minimizing downtime.

Installation and Maintenance

• Easy Installation: The MSZ-FX09NL is designed for quick and easy installation. Its compact size allows it to be mounted in a variety of spaces, making it a perfect solution for residential and light commercial environments.
• Low Maintenance Requirements: The system is built for easy maintenance, with washable filters and simple servicing procedures that ensure continued optimal performance without the need for frequent professional maintenance.
• Washable Filters: The MSZ-FX09NL features washable filters, allowing users to clean them regularly for improved airflow and better air quality. This feature helps reduce maintenance costs and extends the lifespan of the system.

Applications

• Residential Use: The MSZ-FX09NL is perfect for small to medium-sized homes, apartments, and living spaces. It provides efficient cooling and heating while maintaining a low-profile design that blends seamlessly into the environment.
• Commercial Use: This air handler is also ideal for light commercial applications, such as small offices, retail stores, or server rooms, where energy-efficient temperature control is needed without occupying too much space.

In conclusion, the MSZ-FX09NL air handler offers a highly efficient and reliable solution for cooling and heating needs in both residential and light commercial spaces. With advanced features like Hyper Heating technology, inverter-driven performance, and an easy-to-use remote control, it ensures year-round comfort while keeping energy costs low. Its quiet operation, compact design, and advanced filtration system make it a top choice for those seeking a high-quality, durable air handler that provides consistent and reliable performance.

MXZ-3D24NL - Heat Pump Outdoor Unit

The MXZ-3D24NL is a high-performance outdoor heat pump unit designed for residential and light commercial applications. It offers efficient heating and cooling capabilities, ensuring year-round comfort. Below are the key features and specifications of this model:

Key Features:

• Variable Speed INVERTER-Driven Compressor: Adjusts compressor speed to match heating or cooling demand, optimizing energy efficiency and maintaining consistent indoor temperatures.
• Quiet Operation: Operates at sound pressure levels as low as 51 dB(A) in cooling mode and 55 dB(A) in heating mode, minimizing noise disturbances.
• Blue Fin Heat Exchanger Coating: Enhances corrosion resistance, extending the unit's lifespan, especially in coastal or humid environments.
• Built-in Base Pan Heater: Prevents ice buildup in the base pan during heating operation in cold weather conditions.
• Advanced Protections: Includes high-pressure protection, fan motor overheating/voltage protection, compressor thermal protection, and compressor overcurrent detection for enhanced safety and reliability.
• Seacoast Protection: Rated for 2,000 hours of spraying time per ASTM B117 Standard, making it suitable for coastal areas.

Specifications:

• Cooling Capacity at 95°F:
  • Maximum: 22,000 BTU/h
  • Rated: 22,800 BTU/h (Mixed), 23,600 BTU/h (Ducted)
  • Minimum: 11,600 BTU/h (Non-Ducted), 11,300 BTU/h (Mixed), 11,000 BTU/h (Ducted)
• Heating Capacity at 47°F:
  • Maximum: 30,600 BTU/h
  • Rated: 25,200 BTU/h (Mixed), 25,400 BTU/h (Ducted)
  • Minimum: 13,200 BTU/h (Mixed), 12,800 BTU/h (Ducted)
• Heating Capacity at 17°F:
  • Rated: 15,600 BTU/h (Mixed), 16,000 BTU/h (Ducted)
• Heating Capacity at 5°F:
  • Maximum: 19,800 BTU/h
• Efficiency Ratings:
  • SEER2: 18 (Mixed), 16 (Ducted)
  • EER2: 12.70 (Mixed), 11.70 (Ducted)
  • HSPF2 (IV): 9.30 (Mixed), 8.60 (Ducted)
• Electrical Requirements:
  • Power Supply: 208/230 V AC, Single-phase, 60 Hz
  • Guaranteed Voltage Range: 198 - 253 V AC
  • Voltage (Indoor to Outdoor, S1-S2): 208/230 V AC
  • Voltage (Indoor to Outdoor, S2-S3): 24 V DC
  • Recommended Wire Size (Indoor to Outdoor): AWG 14
  • Short-circuit Current Rating (SCCR): 5 kA
  • Minimum Circuit Ampacity (MCA): 28.7 A
  • Maximum Overcurrent Protection (MOCP): 48 A
• Fan Motor:
  • Full Load Amperage: 1.74 A
  • Output: 88 W
  • Airflow Rate: 2,119 CFM (Cooling), 2,228 CFM (Heating)
• Unit Dimensions:
  • Width: 37-11/32 inches
  • Depth: 13 inches
  • Height: 31-11/32 inches
  • Weight: 137 lbs

The MXZ-3D24NL is ideal for applications requiring efficient heating and cooling performance. Its advanced features ensure reliable operation and enhanced comfort throughout the year.

Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 3/8 inch O.D. flared ends, length 50 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.

Features:

• One pair, heavy duty refrigerant lines
• Flared line ends

Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 3/8 inch O.D. flared ends, length 30 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.

Features:

• One pair, heavy duty refrigerant lines
• Flared line ends

Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 3/8 inch O.D. flared ends, length 25 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.

Features:

• One pair, heavy duty refrigerant lines
• Flared line ends

Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 3/8 inch O.D. flared ends, length 15 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.

Features:

• One pair, heavy duty refrigerant lines
• Flared line ends
