Mitsubishi 24,000 BTU P-Series 21.2 SEER2 Single Horizontal-Ducted Mini Split Heat Pump System – R454B | 230V

24,000 BTU Mitsubishi P-Series 21.2 SEER2 Single Horizontal-Ducted Mini Split Heat Pump System - R454B | SUZ-AA24NL / PEAD-AA24NL

The Mitsubishi 24,000 BTU P-Series Horizontal-Ducted Mini Split Heat Pump System offers a perfect balance of high efficiency, compact design, and powerful performance. Featuring the discreet PEAD-AA24NL indoor unit and the energy-efficient SUZ-AA24NL outdoor condenser, this system is engineered to provide reliable year-round comfort while maximizing energy savings. Ideal for both residential and light commercial applications, it uses R454B refrigerant for a more eco-friendly footprint.

• High Efficiency: With a 21.2 SEER2 rating, this system ensures outstanding energy performance and cost savings.
• Low-Profile Indoor Unit: PEAD-AA24NL offers a slim, horizontal-ducted design that fits seamlessly into tight spaces or ceiling cavities.
• Eco-Friendly Refrigerant: Operates on R454B, a low-GWP refrigerant designed for sustainability and compliance with modern standards.
• Whisper-Quiet Operation: Both indoor and outdoor units operate with minimal noise, enhancing indoor comfort.
• Year-Round Comfort: Capable of efficient heating and cooling, making it ideal for any season.

• Indoor Unit: PEAD-AA24NL Horizontal-Ducted Air Handler
• Outdoor Unit: SUZ-AA24NL Standard Heat Pump Condenser

• Energy-conscious homeowners and business owners looking for efficient HVAC solutions.
• Spaces requiring a concealed, ducted air distribution system.
• Retrofit or new construction projects with limited indoor clearance.

Optimize your indoor comfort while reducing your environmental impact with the Mitsubishi 24,000 BTU P-Series Horizontal-Ducted System - a smart, sleek, and efficient solution built for performance and sustainability.

* Please Note * This product does NOT include a remote controller and one would need to be purchased separately.

Mitsubishi 24,000 BTU M-Series Single Zone Mini Split Heat Pump Condenser – R454B | 230V

SUZ-AA24NL - 24,000 BTU/H Heat Pump Outdoor Unit

The SUZ-AA24NL is a powerful and efficient outdoor heat pump unit designed for residential and light commercial use. It delivers reliable performance for both heating and cooling, ensuring optimal comfort in varying temperature conditions.

Outdoor Unit Features (SUZ-AA24NL):

• Quiet Operation: Operates with noise levels similar to a typical conversation, offering a quiet and peaceful environment.
• Pulse Amplitude Modulation Technology: Enhances energy efficiency by adjusting the power supply for optimal compressor performance, reducing energy consumption.
• Inverter-Driven Compressor: Provides precise capacity control for maintaining consistent temperature and energy savings.
• Hot-Start Technology: Prevents cold air blasts during startup by ensuring the fan activates only once the heat exchanger is warm.
• High-Performance Grooved Piping: Improves heat exchange efficiency, enhancing overall system performance.
• Blue Fin Coating: Protects the heat exchanger from corrosion caused by environmental factors like salt and sulfur, particularly useful in coastal or industrial locations.
• Outdoor Unit Directed Power: Powers the indoor unit and includes an automatic restart feature in case of power loss.
• Joint Lap DC Motor: Ensures reliable and efficient operation with a high-performance motor design.

Specifications:

• Cooling Capacity: 24,000 BTU/h maximum, with a minimum capacity of 9,100 BTU/h at 95°F outdoor temperature.
• Heating Capacity: 28,200 BTU/h at 47°F, with capacities ranging from 17,100 BTU/h at 17°F to 11,200 BTU/h at -4°F outdoor temperature.
• Energy Efficiency: SEER2 rating of 21.2, EER2 of 12.2, and HSPF2 of 10 for optimal performance and reduced energy consumption.
• Refrigerant: Uses R454B refrigerant with a pre-charged amount of 3 lbs 4 oz, offering a maximum piping length of 65 feet.
• Noise Levels: 55 dB(A) during both cooling and heating modes.
• Unit Dimensions: 33-1/16 x 13 x 34-11/16 inches, with a unit weight of 117 lbs.

The SUZ-AA24NL is designed to offer high efficiency and reliable comfort, making it an ideal choice for both residential and commercial installations. With its advanced features and durable construction, this outdoor unit ensures excellent performance and long-lasting operation.

Mitsubishi 24,000 BTU P-Series Single or Multi Zone Concealed Duct Mini Split Air Handler – R454B | 230V

PEAD-AA24NL Air Handler Overview

The PEAD-AA24NL is an efficient and reliable air handler designed to provide optimal comfort and air distribution in both residential and light commercial applications. Paired with the PUY-AH24NL outdoor unit, this system ensures outstanding performance, energy savings, and consistent climate control. Its advanced features and robust design make it a perfect solution for homeowners and businesses looking for an efficient, quiet, and effective air handling solution.

Key Features

• Inverter Technology: The PEAD-AA24NL incorporates inverter-driven technology, which allows for variable speed control of the compressor. This results in superior energy efficiency and better overall comfort by adjusting the system's output based on the heating or cooling demand.
• Quiet Operation: Designed to operate with minimal noise, the PEAD-AA24NL ensures a quiet, comfortable environment in spaces such as living rooms, offices, or bedrooms.
• Energy Efficiency: The inverter technology helps to reduce energy consumption by adjusting the compressor speed, allowing the system to run at the most efficient level for each situation, resulting in reduced operating costs.
• Compact and Flexible Installation: The PEAD-AA24NL is designed with flexibility in mind. It can be installed in a variety of configurations, making it suitable for a wide range of applications and installation spaces.
• Durability: Built with high-quality components, the PEAD-AA24NL is engineered for long-lasting performance with minimal maintenance. It provides reliable cooling and heating over the years with proper care.

Specifications

• Cooling Capacity: 24,000 BTU/h
• Heating Capacity: 24,000 BTU/h
• Power Supply: 208-230V, 60Hz, 1-phase
• Dimensions (W x H x D): 31-1/2" x 11-3/4" x 24-1/8”
• Weight: 36 lbs
• Refrigerant: R410A
• Airflow: 1,050 CFM

Benefits

• Improved Comfort: The PEAD-AA24NL provides consistent temperature control, ensuring optimal comfort in any room. Whether heating or cooling, the system ensures even temperature distribution for a more comfortable environment.
• Energy Savings: With its inverter-driven compressor, the PEAD-AA24NL consumes less energy compared to traditional units. It adjusts its operation based on demand, which reduces energy usage and lowers your utility bills.
• Quiet Operation: The PEAD-AA24NL operates at low noise levels, making it perfect for environments where a quiet atmosphere is important, such as bedrooms or offices.
• Environmentally Friendly: The use of R410A refrigerant makes the PEAD-AA24NL an environmentally friendly option, as this refrigerant has a lower global warming potential (GWP) compared to older refrigerants.
• Reliable and Durable: The PEAD-AA24NL is designed to provide years of reliable service. With proper maintenance, this air handler offers dependable performance in both heating and cooling modes.

Maintenance

• Easy Access for Maintenance: The PEAD-AA24NL is designed for easy servicing. Components are accessible, simplifying regular maintenance tasks such as cleaning or replacing filters, ensuring that the system operates at peak efficiency.
• Filter Maintenance: The unit includes washable filters that help maintain indoor air quality. Regular cleaning of these filters is recommended to ensure optimal airflow and system performance.
• Long Lifespan: Built with high-quality materials, the PEAD-AA24NL is designed for long-term durability with minimal maintenance needs, extending the lifespan of your system.

Applications

• Residential Use: The PEAD-AA24NL is ideal for single-family homes, apartments, or townhouses that require efficient and reliable heating and cooling. It provides year-round comfort while reducing energy consumption.
• Light Commercial Use: This air handler is also well-suited for small commercial applications, such as offices, restaurants, or retail stores, where comfort and energy efficiency are a priority.

In conclusion, the PEAD-AA24NL air handler offers an exceptional combination of energy efficiency, quiet operation, and long-lasting durability. Its inverter-driven technology ensures optimal performance while reducing energy consumption, making it a cost-effective choice for both residential and light commercial applications. With easy maintenance, flexible installation, and reliable operation, the PEAD-AA24NL is an excellent choice for those seeking efficient, comfortable climate control solutions.

* Please Note * This product does NOT include a remote controller and one would need to be purchased separately.

Installation Kit for Condensers - Accessory Set

4Ensure a professional and secure installation for your condenser with this comprehensive installation kit. Designed to provide all the essential components needed for a smooth setup, this kit helps protect your system while ensuring proper electrical and refrigerant connections.

Key Features:

✔ All-in-One Kit: Includes key accessories for a professional-grade installation.
✔ Enhanced System Protection: Features a surge protector and disconnect safety switch for added safety.
✔ Reliable Electrical Connections: Comes with a whip and charging adapter to ensure proper power supply.
✔ Secure Wall Penetration: Telescoping wall sleeve protects and stabilizes refrigerant and electrical lines.
✔ HVAC Professional Recommended: Ideal for new installations and system replacements.

What’s Included:

• 3/4" x 6' Electrical Whip – SKU: 84138
• 60A Non-Fused Disconnect – SKU: 83335
• Surge Protector – SKU: ICM517
• CPS Charging Adapter – SKU: 87-AD87
• Telescoping Wall Sleeve – SKU: NFP-75

Equip your condenser with everything needed for a safe, durable, and professional installation. Order your Condenser Installation Kit today!

E Lite Equipment Pad 18" x 38" x 3"

E Liteis a plastic pad designed as a mounting base for air conditioning condensers. The rugged design provides uniform and generous ribbing for optimum, self-leveling ground support without inserts. E Lite is injection molded from polypropylene, resulting in a pad that is lightweight, but not too light. A subtle texture prevents unit slide and presents a classic appearance, which is enhanced by rounded edges and a concrete gray color. Each pad is molded with its size in raised letters.

• High recycled plastic content
• Subtle texture resists unit slide
• Unaffected by UV or weather
• Uniform ribbing transfers load evenly
• Drillable for securing unit
• Lightweight, yet rugged

No Return Policy

All sales of this product are final and are non-refundable.

Condenser Risers - 4" x 18" - 2 Pack

Provides simple and secure mounting for small and large piping systems, ductwork runs, cable trays and smaller equipment such as condensers. Linear track offers adjustable mounting. Manufactured from exterior grade materials.

Features

• Ideal for piping, duct runs, cable trays and condensers
• Weather resistant PVC
• Linear track holds 3/8" hex head bolts
• Two 7/8" long bolts included
• Weighs up to 397 Ib

E Lite Equipment Pad and Risers Kit 18" x 38" x 3"

E Lite Condenser Pad and Risers

E Lite Condenser Pad

E Lite Condenser Pad is designed to provide solid support for air conditioning condensers. It's made from sturdy polypropylene, striking a balance between lightness and stability. Its robust design ensures a level ground without the need for extra components.

Key Features:

• Reliable Support: Abundance of ridges for stable ground support.
• Durable and Lightweight: Tough yet not excessively heavy, thanks to polypropylene construction.
• Anti-Slip: The surface prevents slipping, and rounded edges enhance safety.
• Simple Appearance: Gray color with size labels.
• Versatile Use: Suitable for condensers, pipes, ducts, cables, and more.

E Lite Risers

E Lite Risers complement the Condenser Pad, allowing you to adjust your setup as needed. They are constructed from weather-resistant PVC for outdoor use.

Key Features:

• Weather Resistance: Made from tough PVC for long-lasting performance.
• Secure Setup: The track securely holds bolts in place.
• Bolts Included: Each set comes with two bolts.
• Strong Support: Capable of handling loads of up to 397 pounds.

E Lite Condenser Pad and Risers offer reliable support without any complications. They are built to last and deliver efficient performance. Consider E Lite for your support needs – it's a practical solution for your projects.

No Return Policy

All sales of this product are final and are non-refundable.

Wall Mount Bracket for Mini Split Systems

This wall mount bracket is perfect for outdoor mini split condensers. The length of the the wall bracket arms are 17” long. The condensing unit is mounted onto the L-shaped brackets and fastened using the bolts and anti-vibration washers provided.

Features:

• 17” Arm Length
• Weight capacity of 220 lbs per arm
• Bolts and anti-vibration washers included

No Return Policy

All sales of this product are final and are non-refundable.

Refrigerant Line Set with 1/4" and 5/8" Line Ends - 15 feet

Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 5/8 inch O.D. flared ends, length 15 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.

Features:

• One pair, heavy duty refrigerant lines
• Flared line ends

Refrigerant Line Set with 1/4" and 5/8" Line Ends - 30 feet

Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 5/8 inch O.D. flared ends, length 30 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.

Features:

• One pair, heavy duty refrigerant lines
• Flared line ends

Refrigerant Line Set with 1/4" and 5/8" Line Ends - 50 feet

Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 5/8 inch O.D. flared ends, length 50 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.

Features:

• One pair, heavy duty refrigerant lines
• Flared line ends

Refrigerant Line Set with 1/4" and 5/8" Line Ends - 25 feet

Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 5/8 inch O.D. flared ends, length 25 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.

Features:

• One pair, heavy duty refrigerant lines
• Flared line ends

Refrigerant Line Set with 1/4" and 5/8" Line Ends - 35 feet

Refrigerant line set (pair) for mini split systems, liquid line size 1/4 inch O.D. flared ends, suction line size 5/8 inch O.D. flared ends, length 35 feet, insulation thickness of 1/2 inch. For use with air conditioning and refrigeration systems, includes both the liquid line and the suction line.

Features:

• One pair, heavy duty refrigerant lines
• Flared line ends

Cielo Breez Max Mini Split Thermostat with WiFi

Introducing Cielo Breez Max, the ultimate smart thermostat for your mini-splits, designed to elevate your comfort with intelligent climate control. Transform your air conditioner into a smart powerhouse and manage your cooling or heating from anywhere using your phone. This award-winning device, available in black and white, prevents overheating or overcooling with AI-powered Comfy Max, while seamlessly detecting any mini-split brand for hassle-free setup.

Features:

• Energy Savings
• WiFi Connectivity
• Weekly Schedule
• Geofencing
• Temperature Range Lock
• Real-Time Notifications
• HVAC Zoning

Weekly Schedule lets you set on and off periods throughout the week based on your needs.

Geofencing uses your smartphone's location to trigger actions in your system, such as turning the air conditioner on or off based on your proximity to home.

Temperature Range Lock ensures your air conditioner operates within a set temperature range for optimal comfort and efficiency.

Real-Time Notifications keep you informed with important updates, helping you manage your air conditioner better.

HVAC Zoning allows you to create customized temperature control zones by grouping multiple mini-split units.

The Cielo Breez Max offers innovative features and extraordinary performance, making it a perfect fit for any room air conditioner. Enjoy maximum energy savings and simplified home comfort with this advanced smart thermostat.

Mitsubishi MHK2 Wireless Remote Controller

The Mitsubishi MHK2 is the second revision of Mitsubishi's most popular wireless controller set, now available for M & P Series residential and light commercial units. This controller offers in-depth 7-day scheduling and an easy to read, backlit display.

The updated MHK2 can now be used in tandem with the Kumo Cloud wi-fi adapter, sold separately. No longer do you have to choose between internet and wireless control: you can use both!

The MRCH2 is the main body of the thermostat. This can be placed anywhere within 200 feet of the indoor unit and does not require line of sight. The ;MRC2 cable will connect to the CN105 connector on the indoor unit's control board. The other end of this cable will connect to the MIFH2 receiver. The MIFH2 should be placed on the right side of a wall mounted unit, in the pocket of a MLZ-KP cassette, or anywhere near the control side of a ducted or square cassette unit.

Features:

• Includes MRCH2 thermostat, MIFH2 wireless receiver, and MRC2 cable
• Backlit display
• Can sense temperature at indoor unit (default) or at controller
• Fahrenheit °F / Celsius °C
• No batteries required
• Single zone compatible
• Multi zone compatible
• English, French, Spanish

Compatible Indoor Units:

Wall Mounted

• GL Series: MSZ-GL06NA-U1, MSZ-GL09NA-U1, MSZ-GL12NA-U1, MSZ-GL15NA-U1, MSZ-GL18NA-U1, MSZ-GL24NA-U1, MSY-GL09NA-U1, MSY-GL12NA-U1, MSY-GL15NA-U1, MSY-GL18NA-U1, MSY-GL24NA-U1
• FH Series: MSZ-FH06NA, MSZ-FH09NA, MSZ-FH12NA, MSZ-FH15NA, MSZ-FH18NA2
• EF Series: MSZ-EF09NAB-U1, MSZ-EF09NAS-U1, MSZ-EF09NAW-U1, MSZ-EF12NAB-U1, MSZ-EF12NAS-U1, MSZ-EF12NAW-U1, MSZ-EF15NAB-U1, MSZ-EF15NAS-U1, MSZ-EF15NAW-U1, MSZ-EF18NAB-U1, MSZ-EF18NAS-U1, MSZ-EF18NAW-U1
• JP Series: MSZ-JP09WA-U1, MSZ-JP12WA-U1
• WR Series: MSZ-WR09NA-U1, MSZ-WR12NA-U1, MSZ-WR18NA-U1, MSZ-WR24NA-U1
• D Series: MSZ-D30NA-8, MSZ-D36NA-8, MSY-D30NA-8, MSY-D36NA-8
• P Series: PKA-A12HA7, PKA-A18HA7,PKA-A24KA7, PKA-A30KA7, PKA-A36KA7

Ducted

• KD Series: SEZ-KD09NA4R1.TH, SEZ-KD12NA4R1.TH, SEZ-KD15NA4R1.TH, SEZ-KD18NA4R1.TH
• P Series: PEAD-A09AA7, PEAD-A12AA7, PEAD-A15AA7, PEAD-A18AA7, PEAD-A24AA7, PEAD-A30AA7, PEAD-A36AA7, PEAD-A42AA7

Ceiling Cassette

• KF Series: SLZ-KF09NA, SLZ-KF12NA, SLZ-KF15NA, SLZ-KF18NA
• KP Series: MLZ-KP09NA, MLZ-KP12NA, MLZ-KP18NA
• P Series: PLA-A12EA7, PLA-A18EA7, PLA-A24EA7, PLA-A30EA7, PLA-A36EA7, PLA-A42EA7

Floor Mounted

• MFZ-KJ09NA-U1, MFZ-KJ12NA-U1, MFZ-KJ15NA-U1, MFZ-KJ18NA-U1

Multi Position Air Handler

• KP: SVZ-KP12NA, SVZ-KP18NA, SVZ-KP24NA, SVZ-KP30NA, SVZ-KP36NA
• P Series: PVA-A12AA7, PVA-A18AA7, PVA-A24AA7, PVA-A30AA7, PVA-A36AA7, PVA-A42AA7

Ceiling Suspended

• P Series: PCA-A24KA7, PCA-A30KA7, PCA-A36KA7, PCA-A42KA7
