6,000 BTU Mitsubishi FS Series 32.2 SEER2 Single Zone Wall Mount Mini Split Heat Pump System – R410A | 230V

Mitsubishi MUZ-FS06NA 6,000 BTU Wall-Mounted Outdoor Heat Pump Unit – R-410A

The Mitsubishi MUZ-FS06NA is a high-efficiency, single-zone heat pump outdoor unit designed for residential and light commercial applications. Engineered with Hyper-Heating INVERTER™ (H2i®) technology, this unit delivers reliable heating performance even in extreme outdoor temperatures as low as -13°F, ensuring comfort throughout the year.

Key Features:

• Cooling Capacity: 6,000 BTU/h
• Heating Capacity: 8,700 BTU/h
• Refrigerant: R-410A – eco-friendly and energy-efficient
• Compressor Type: Twin Rotary inverter-driven for precise temperature control
• Electrical Requirements: 208/230V, 1-Phase, 60 Hz
• Operating Range:
  • Cooling: 14°F to 115°F DB
  • Heating: Wet Bulb -13°F to 65°F
• Quiet Operation: Sound pressure levels as low as 20 dB(A)
• Durable Construction: Weather-resistant exterior for long-lasting performance
• Base Pan Heater: Prevents ice buildup in cold climates
• Compatibility: Pairs with MSZ-FS06NA indoor units for single-zone operation
• Refrigerant Piping: Flared connections, liquid line 1/4", suction line 3/8"

Benefits:

• Provides consistent, efficient heating and cooling year-round
• Energy-saving inverter technology reduces electricity consumption
• Compact and durable design suitable for a variety of residential installations
• Easy integration with Mitsubishi wall-mounted indoor units for single-zone systems

Please note that in order to function, this air handler must be installed with a condenser and other installation equipment, available at an additional cost.

• Able to cover up to a small room in ideal conditions
• 6,000 BTU wall-mounted air handler with remote
• Built-in I-SEE sensor to direct airflow more effectively
• .225 gallon per hour dehumidification rate

The Mitsubishi MSZ-FS06NA air handler is designed to be able to function as a single zone system or with a multi zone system setup. With integrated I-SEE sensor technology, this air handler can constantly read the temperature from multiple directions in the room, allowing it to aim airflow in the direction that it is needed most. This allows your room to maintain a more constant temperature and decreases the unit’s run time.Keeping health in mind, Mitsubishi also factory-installed an enhanced filtration system.

This insulated refrigerant line set for mini split systems comes as a pair, including both the liquid line and suction line. It is used to connect the indoor air handler to the outdoor condenser. The line set is 35’ feet long. The liquid line has 1/4 inch outside diameter flared ends. The suction line has 3/8 inch outside diameter flared ends.

Features:

• Insulated
• Flared Line Ends
• Heavy Duty Refrigerant Lines
