Mitsubishi 6,000 BTU GX-Series Single or Multi Zone Wall Mounted Mini Split Air Handler R454B | 230V

MSZ-GX06NL 6,000 BTU/H Wall-Mounted Indoor Unit

The MSZ-GX06NL is a 6,000 BTU/H wall-mounted indoor unit designed to provide efficient cooling and heating solutions. Its advanced features ensure both comfort and energy savings for residential or light commercial spaces.

• Cooling Capacity: 6,000 BTU/h
• Heating Capacity: 7,200 BTU/h
• Electrical Specifications: 208/230 V, 1 Phase, 60 Hz
• Airflow Rate (Cooling, Dry): 151-448 CFM
• Airflow Rate (Heating, Dry): 151-459 CFM
• Unit Dimensions: 31-13/32 x 9-21/32 x 11-25/32 inches (798 x 245 x 299 mm)
• Weight: 23 lbs (10.4 kg)
• Piping: Liquid pipe size 1/4 inch (6.35 mm), Gas pipe size 3/8 inch (9.52 mm)
• Drain Pipe: 5/8 inch (16 mm)

Key Features

• Dual Barrier Coating: Prevents dust, fibers, and smoke from collecting on the heat pump's inner surface, ensuring optimal airflow.
• Econo Cool: Adjusts the airflow based on heat exchanger temperature to save energy while maintaining comfort.
• Electrostatic Enzyme Filter: Attracts charged particles, including airborne non-living particulates like dust and smoke.
• Quiet Operation: Both the indoor and outdoor units operate quietly, providing a peaceful environment.
• Powerful Mode: Temporarily increases fan speed to quickly bring the room to the desired temperature.
• Smart Dry Mode: Improves humidity control with minimal over-cooling.
• Wi-Fi Enabled: Pairs with the Comfort app for remote control over temperature, fan speeds, and settings.
• Multiple Control Options: Includes a back-lit remote controller, comfort app, and both wired and wireless controllers.

Indoor Unit Accessories

• Wireless Remote Controller: RCMKP1CB
• Microparticle Filter: MAC-EMF515FT-E
• Condensate Pump Options: Blue Diamond Advanced Mini Condensate Pump X87-721, Refco Condensate Pump COMBI
