9,000 BTU Mitsubishi Hyper Heat 17.6 SEER2 Single Zone Concealed Duct Mini Split Heat Pump System - R454B | 208/230V

Required Fields *

By

Mitsubishi

In stock

Model

SUZ-AA09NLHZ / SEZ-AD09NL

ID

216063

Was $3,975.01
Your Low Price $3,180.00

Free Shipping
Customize 9,000 BTU Mitsubishi Hyper Heat 17.6 SEER2 Single Zone Concealed Duct Mini Split Heat Pump System - R454B | 208/230V
9,000 BTU Mitsubishi Single Zone Condenser - R454B
9,000 BTU Mitsubishi Single Zone Condenser - R454B   + $1,948.50
9,000 BTU Mitsubishi KD-Series Concealed Duct Mini Split Air Handler - R454B
9,000 BTU Mitsubishi KD-Series Concealed Duct Mini Split Air Handler - R454B   + $1,231.50
9,000 BTU Mitsubishi Hyper Heat 17.6 SEER2 Single Zone Concealed Duct Mini Split Heat Pump System - R454B | 208/230V - SUZ-AA09NLHZ / SEZ-AD09NL

$3,180.00

9,000 BTU Mitsubishi SEZ-AD Hyper Heat 17.6 SEER2 Single Zone Concealaed Duct Mini Split Heat Pump System – R454B | 208/230V

The SEZ-AD09NLHZ / SUZ-AA09NLHZ is a Mitsubishi Hyper-Heating Single Zone Mini-Split Heat Pump, designed to deliver efficient heating and cooling even in extremely cold climates. Its ductless design makes it ideal for room additions, converted spaces, or areas without ductwork.

Product Overview

  • Cooling Capacity: 9,000 BTU
  • Heating Capacity: 9,000 BTU (Hyper Heat for extreme cold)
  • SEER2: Up to 17.6
  • Refrigerant: R454B
  • Voltage: 208/230V

Key Features

  • Hyper-Heating Technology: Maintains high-efficiency heating even at sub-zero temperatures.
  • Quiet Operation: Low sound levels for a comfortable indoor environment.
  • Durable Design: Corrosion-resistant components for long-lasting performance.
  • Energy Efficient: High SEER2 rating helps reduce energy costs.
  • Ductless Installation: Quick setup without the need for ductwork.
  • Self-Diagnostics: Built-in error codes and indicators simplify troubleshooting and maintenance.

Warranty

Eligible equipment may receive a 10 Years with Online Registration with Mitsubishi.

* Please Note * This product does NOT include a remote controller and one would need to be purchased separately.
More Information
Mitsubishi 9,000 BTU KD-Series Concealed Duct Mini Split Air Handler – R454B | 230V
SKUSEZ-AD09NL
Weight45.000000
ManufacturerMitsubishi
ReplacesSEZ-KD09NA4R1.TH
ControllerNot Included
Cooling BTU8,100 BTU
Heating BTU9,000 BTU
Maximum CFM194-317 CFM
Decibel Level (dBA)23-30
RefrigerantR454B
CapacityDehumidification Rate: 0.19 gal/hr
Liquid Line1/4"
Suction Line3/8"
Electrical208/230V 1 Phase 60 Hz
Electric Phase FilterSingle Phase
BTU/Tonnage9,000 BTU/0.75 Ton
Mini Split TypeConcealed Duct
Zone CompatibilityMulti Zone
Operating ModeCooling, Heating
Height7-7/8"
Width31-1/8"
Depth27-9/16"
Warranty10 Years with Online Registration
Resources
Safety InformationPROPOSITION 65 WARNING
Mitsubishi 9,000 BTU M-Series Single Zone Mini Split Hyper Heat Pump Condenser – R454B | 230V
SKUSUZ-AA09NLHZ
Weight115.000000
ManufacturerMitsubishi
ReplacesSUZ-KA09NAHZ.TH
Cooling BTU9000
Heating BTU9,000 BTU
Decibel Level (dBA)55
RefrigerantR454B
SEER216.7
Compressor TypeHigh Efficiency Rotary
Liquid Valve Size 1/4
Suction Valve Size 3/8
Electrical208/230V 1 Phase 60 Hz
Max Breaker Size41
Min. Breaker Size24
BTU/Tonnage9,000 BTU/0.75 Ton
Zone CompatibilitySingle Zone
Height34.63"
Width33.06"
Depth13"
Warranty10 Years with Online Registration
Resources You will need Adobe® Acrobat® Reader to view PDF documents.
Write Your Own Review
You're reviewing:9,000 BTU Mitsubishi Hyper Heat 17.6 SEER2 Single Zone Concealed Duct Mini Split Heat Pump System - R454B | 208/230V
Your Rating
Customer Questions
No Questions
Did you find what you were looking for?
Why Choose Mitsubishi Mini Splits?
Why Choose Mitsubishi Mini Splits?

Mitsubishi mini split air conditioners and heat pumps provide exceptional comfort, energy efficiency, and ultra-quiet performance in any climate. Engineered for reliability and precision, these systems offer year-round heating and cooling while reducing energy costs and enhancing indoor air quality.
