Canarm 12 Inch Explosion Proof Standard Fan 1,640 CFM 115/230V

SAVE $588.20
By

Canarm

In stock
Model

SD12-XPF

ID

2224

Was $1,442.00 Your Low Price Special Price $853.80

Product Features
  • Made from rugged steel welded box housing
  • With tie bar shutters and magnets for quiet operation
  • High-Efficiency Motor
  • Suitable for garages, warehouses and other industrial/commercial buildings.

Canarm 12 Inch Explosion Proof Standard Fan 1,640 CFM 115/230V

Canarm LFI’s 12" Explosion Proof Standard Fan delivers reliable ventilation in hazardous environments where flammable gases or combustible dusts may be present. Built with high-quality materials and construction standards, this fan combines safety, performance, and efficiency. Featuring a robust single-speed, dual voltage explosion proof motor, it is ideal for use in industrial applications requiring compliance with stringent safety regulations.

Explosion Proof Rating:

  • Class I, Group C: Suitable for atmospheres containing ethyl ether, ethylene, and similar gases.
  • Class I, Group D: Suitable for atmospheres such as acetone, ammonia, benzene, propane, gasoline, methane, etc.
  • Class II, Group F: For environments with carbonaceous dusts like coal, charcoal, and coke dusts.
  • Class II, Group G: For areas with combustible dusts including flour, wood, grain, and plastic dusts.

Features

  • Explosion proof, single speed, dual voltage motor (115/230V) with thermal overload protection.
  • Heavy-duty aluminum fan blades, precision balanced for optimal airflow and durability.
  • Rugged welded steel box housing finished with a durable powder coat for corrosion resistance.
  • Aluminum louver shutters mounted on long-lasting nylon bushings for smooth operation.
  • Chrome plated OSHA-compliant intake guard for added workplace safety.
  • Ships completely assembled for fast and easy installation.
More Information
Canarm 12 Inch Explosion Proof Standard Fan 1,640 CFM 115/230V
SKUSD12-XPF
Weight (in lbs)42.000000
Brand/ManufacturerCanarm
Maximum CFM1,640 CFM at 0 in Static Pressure
Propeller Diameter12 inches
Motor RPM1625
Horsepower1/3
Electrical115/230V
PhaseSingle Phase
Height17.25"
Width17.25"
Depth20.50"
