The Daikin DSC1203D000001S is a 10-ton commercial packaged air conditioner designed to provide reliable, efficient cooling for light commercial applications. Combining 116,000 BTU/h of cooling capacity with two individually circuited scroll compressors, a direct-drive supply fan, and R-32 refrigerant, this all-in-one rooftop system helps deliver dependable cooling and efficient part-load operation while simplifying installation and preserving valuable indoor space.
The integrated air conditioning system uses two single-stage scroll compressors that are individually circuited to provide 116,000 BTU/h of nominal cooling capacity. The two refrigeration circuits provide single-stage cooling operation, allowing the system to better match cooling output to changing load requirements. The DSC1203D000001S uses R-32 refrigerant.
The DSC1203D000001S provides 116,000 BTU/h of nominal cooling capacity with an 11.4 EER and 15 IEER rating. This helps provide dependable commercial cooling performance while supporting efficient operation across full-load and part-load conditions.
With an 11.4 EER and 15 IEER rating and a direct-drive evaporator motor, this system is designed to provide efficient air movement and reliable cooling performance. The 15-inch by 15-inch direct-drive indoor fan provides 3,380 CFM of nominal indoor airflow, operates from 300 to 1,600 RPM, and supports a maximum external static pressure of 0.8 in. W.C.
The packaged rooftop configuration combines the compressors, condenser, evaporator coil, supply fan, controls, and other air distribution components into a single outdoor unit, helping simplify equipment placement and preserve valuable indoor space. The DSC1203D000001S is built to be a direct replacement for most rooftop units without the need for a curb adapter. Its convertible airflow orientation allows the unit to serve downflow or horizontal applications. The unit measures 93 3/4 inches wide by 60 3/8 inches deep by 54 5/8 inches high and has a ship weight of 1,142 pounds.
The DSC1203D000001S features a 24-volt electromechanical controls package for straightforward commercial system operation. Two individually circuited scroll compressors provide single-stage cooling, while the direct-drive supply fan provides dependable air distribution. The unit is configured for 208/230-volt, three-phase, 60 Hz electrical service.
The Daikin DSC1203D000001S is designed for comfort cooling applications in light commercial buildings and other commercial environments requiring packaged rooftop air conditioning. Its 116,000 BTU/h cooling capacity, single-stage cooling system, direct-drive supply fan, and convertible airflow orientation make it well suited for applications where reliable cooling, efficient part-load operation, and installation flexibility are important.
The DSC1203D000001S is designed for convenient service access, including tool-less filter access for routine filter maintenance. The standard filter arrangement uses two 20-inch by 25-inch by 2-inch filters and two 25-inch by 25-inch by 2-inch filters. Screw-on style pressure switches provide ease of replacement, while the factory-packaged design keeps the major refrigeration, airflow, and control components together in one outdoor unit. The unit uses a Microchannel condenser and a round-tube plate-fin evaporator coil for efficient heat transfer.
The Daikin DSC1203D000001S includes a Daikin limited warranty. Complete warranty details are available from the local Daikin distributor or manufacturer's representative and are subject to applicable warranty terms and conditions.
Experience reliable, efficient commercial cooling with the Daikin DSC1203D000001S. Combining R-32 refrigerant, two individually circuited scroll compressors, 15 IEER / 11.4 EER efficiency, direct-drive air distribution, and flexible downflow or horizontal airflow configuration in one packaged rooftop air conditioning system.
