Daikin 25 Ton 10 EER Light Commercial Packaged Air Conditioner - 208/230V 3 Phase - R32

The DSC light commercial packaged air conditioner offers energy-efficient cooling performance in one self-contained unit. The 25-ton Daikin Light Commercial DSC3003D000001S packaged air conditioner unit is suitable for ground-level or rooftop installations in downflow applications. The heavy-gauge, galvanized steel cabinet with UV-resistant powder-paint finish withstands all weather conditions and time.

Features

• 25 tons, 13 IEER / 10 EER
• R32 chlorine-free refrigerant
• 290,000 BTU Cooling capacity
• High-efficiency scroll compressor
• Copper tube/aluminum fin coils
• High and low pressure switches
• High-capacity, steel-cased filter drier
• 24 volt terminal strip
• Downflow orientation
• Built in filter rack with standard 2" filters

Compressor & Supply Fan

High performance, low noise scroll compressors to match the required total load. Supply fan will be 2 direct-drive motors. Ball bearing DirectDrive EEM motor removes the need for belts, sheaves, bearings and lubrication.

Installation

Daikin Packaged units are designed with fast and easy installation in mind and are ideal for new construction and retrofit projects.

Applications & Serviceability

Daikin Rooftop units are intended for comfort cooling applications in normal heating, ventilating, and air conditioning. For proper operation, units should be rigged in accordance with instructions stated on the installation manual. Follow factory check, test and start procedures explicitly to achieve satisfactory start-up and operation. Daikin packaged rooftop units are built with serviceability in mind, designed to make future maintenance and service on the unit easy and accessible.
