Daikin 5 Ton 13.7 SEER2 Commercial Packaged Air Conditioner | 460V 3 Phase - R32 - Single Stage

Efficient 5-Ton Air Conditioner Rooftop Unit for Light Commercial Applications with Direct-Drive Supply Fan

The Daikin DSC0604D000001S is a 5-ton commercial packaged air conditioner designed to provide reliable, efficient cooling for light commercial applications. Combining 57,500 BTU/h of cooling capacity with a direct-drive supply fan, scroll compressor technology, and R-32 refrigerant, this all-in-one rooftop system helps deliver dependable cooling while simplifying installation and preserving valuable indoor space.

Key Benefits

• 13.7 SEER2 / 11.8 EER2 Efficiency – Provides efficient cooling performance to help manage energy use during warm-weather operation.
• 57,500 BTU/h Cooling Capacity – Provides nominal cooling capacity for a range of light commercial applications.
• High-Performance Scroll Compressor – Provides reliable single-stage cooling performance for commercial comfort applications.
• Direct-Drive Supply Fan – Provides dependable air movement without belt-driven components, helping simplify service and maintenance.
• Packaged Rooftop Configuration – Combines major air conditioning components in one outdoor unit to simplify equipment placement and preserve valuable indoor space.
• Galvanized-Steel Cabinet – Heavy-gauge galvanized-steel construction with a UV-resistant powder-paint finish helps provide durability for outdoor rooftop operation.
• Convertible Airflow Orientation – Supports downflow or horizontal applications for greater installation flexibility.
• Tool-Less Filter Access – Provides convenient access to the filter section to simplify routine maintenance.

R-32 Refrigerant & Scroll Compressor – Primary Cooling Benefit

The integrated air conditioning system uses R-32 refrigerant and a high-performance scroll compressor to provide 57,500 BTU/h of nominal cooling capacity. The single-stage cooling system is designed to provide dependable comfort cooling for light commercial applications while using a refrigerant with zero ozone depletion potential.

57,500 BTU/h Cooling Performance

The DSC0604D000001S provides 57,500 BTU/h of nominal cooling capacity with 13.7 SEER2 and 11.8 EER2 efficiency ratings. This helps provide dependable commercial cooling performance while supporting efficient operation during warm-weather conditions.

Efficient Direct-Drive Operation

With 13.7 SEER2 and 11.8 EER2 efficiency ratings and a direct-drive evaporator motor, this system is designed to provide efficient air movement and reliable cooling performance. The direct-drive indoor fan uses a 12-inch by 11-inch wheel and provides 1,860 CFM of nominal indoor airflow with standard external static pressure.

Packaged Rooftop Installation Design

The packaged rooftop configuration combines the compressor, condenser, evaporator coil, supply fan, controls, and other air distribution components into a single outdoor unit, helping simplify equipment placement and preserve valuable indoor space. The DSC0604D000001S is designed for new construction and retrofit applications and is built to be a direct replacement for most rooftop units without the need for a curb adapter. The convertible airflow orientation allows the unit to serve downflow or horizontal applications.

Controls & Comfort

The DSC0604D000001S includes a 24-volt electromechanical controls package for straightforward commercial system operation. Its single-stage cooling system and direct-drive supply fan provide dependable air distribution for connected ductwork, while the convertible airflow orientation accommodates either downflow or horizontal installation configurations. The unit is configured for 460-volt, three-phase electrical service.

Commercial Applications

The Daikin DSC0604D000001S is designed for comfort cooling applications in light commercial buildings and other commercial environments requiring packaged rooftop air conditioning. Its 57,500 BTU/h cooling capacity, direct-drive supply fan, R-32 refrigerant, durable cabinet construction, and flexible airflow orientation make it well suited for applications where reliable cooling, efficient operation, and installation flexibility are important.

Service & Maintenance

The DSC0604D000001S is designed for convenient service access, including tool-less filter access for routine filter maintenance. The standard filter arrangement uses two 20-inch by 25-inch by 2-inch filters. Screw-on style pressure switches provide ease of replacement, while the factory-wired and tested electrical system helps simplify installation and start-up. The unit uses a copper tube/aluminum fin evaporator coil and a Micro Channel condenser for efficient heat transfer.

Warranty

The Daikin DSC0604D000001S includes a 5-Year Parts Limited Warranty. Complete warranty details are subject to applicable Daikin warranty terms and conditions.

Recommended Accessories

• 14-Inch Roof Curb – Compatible 3- to 6-ton packaged unit installations.
• 14-Inch Seismic & Wind-Rated Roof Curb – For applicable installations.
• Low-Leak Downflow Economizer with JADE Controller & Dry Bulb Sensor.
• Low-Leak Downflow Economizer with JADE Controller & Enthalpy Bulb Sensor.
• Low-Leak Downflow Economizer with Honeywell DDC MotorC.

Reliable Commercial Cooling with the Daikin DSC0604D000001S

Experience reliable, efficient commercial cooling with the Daikin DSC0604D000001S. Combining R-32 refrigerant, high-performance scroll compressor technology, direct-drive air distribution, and flexible downflow or horizontal airflow configuration in one packaged rooftop air conditioning system.
