The Daikin DSC0603D000001S is a 5-ton commercial packaged air conditioner designed to provide reliable, efficient cooling for light commercial applications. Combining 57,500 BTU/h of cooling capacity with a direct-drive supply fan, high-performance scroll compressor, and R-32 refrigerant, this all-in-one rooftop system helps deliver dependable cooling while simplifying installation and preserving valuable indoor space.
The integrated air conditioning system uses R-32 refrigerant and a high-performance scroll compressor to provide 57,500 BTU/h of nominal cooling capacity. The single-stage cooling system is designed to provide dependable comfort cooling for light commercial applications while using a refrigerant with zero ozone depletion potential.
The DSC0603D000001S provides 57,500 BTU/h of nominal cooling capacity with 13.7 SEER2 and 11.8 EER2 efficiency ratings. This helps provide dependable commercial cooling performance while supporting efficient operation during warm-weather conditions.
With 13.7 SEER2 and 11.8 EER2 efficiency ratings and a direct-drive evaporator motor, this system is designed to provide efficient air movement and reliable cooling performance. The unit uses a 12-inch by 11-inch direct-drive indoor fan wheel and provides 1,860 CFM of nominal indoor airflow with standard external static pressure.
The packaged rooftop configuration combines the compressor, condenser, evaporator coil, supply fan, controls, and other air distribution components into a single outdoor unit, helping simplify equipment placement and preserve valuable indoor space. The DSC0603D000001S is designed for new construction and retrofit applications and is built to be a direct replacement for most rooftop units without the need for a curb adapter. The convertible airflow orientation allows the unit to serve downflow or horizontal applications. The unit measures approximately 74 inches wide, 48 5/16 inches deep, and 39 7/8 inches high.
The DSC0603D000001S includes a 24-volt electromechanical controls package for straightforward commercial system operation. Its single-stage cooling system and direct-drive supply fan provide dependable air distribution for connected ductwork, while the convertible airflow orientation accommodates either downflow or horizontal installation configurations. The unit is configured for 208/230-volt, three-phase electrical service.
The Daikin DSC0603D000001S is designed for comfort cooling applications in light commercial buildings and other commercial environments requiring packaged rooftop air conditioning. Its 57,500 BTU/h cooling capacity, direct-drive supply fan, R-32 refrigerant, durable cabinet construction, and flexible airflow orientation make it well suited for applications where reliable cooling, efficient operation, and installation flexibility are important.
The DSC0603D000001S is designed for convenient service access, including tool-less filter access for routine filter maintenance. The standard filter arrangement uses two 20-inch by 25-inch by 2-inch filters. Screw-on style pressure switches provide ease of replacement, while the factory-wired and tested electrical system helps simplify installation and start-up. The unit uses a copper tube/aluminum fin evaporator coil and a Micro Channel condenser for efficient heat transfer.
The Daikin DSC0603D000001S includes a 5-Year Parts Limited Warranty. Complete warranty details are subject to applicable Daikin warranty terms and conditions.
Experience reliable, efficient commercial cooling with the Daikin DSC0603D000001S. Combining R-32 refrigerant, high-performance scroll compressor technology, direct-drive air distribution, and flexible downflow or horizontal airflow configuration in one packaged rooftop air conditioning system.
