28,600 BTU 19 SEER Mitsubishi Tri Zone Heat Pump System 9+9+9

By

Mitsubishi

In Stock - Ready to Ship
Model

MXZ-3C30NA2 / 3-MSZ-GL09

ID

8096

Authorized Mitsubishi Dealer

Your Low Price $4,480.50
Bread Checkout


Please enter your room sizes to narrow your results

Room #1

Room #2

Room #3

Free Shipping

Required Fields *

Customize 28,600 BTU 19 SEER Mitsubishi Tri Zone Heat Pump System 9+9+9
28,600 BTU Heat Pump Condenser (In Stock - Ready to Ship)   + $2,822.25 View Item
28,600 BTU Heat Pump Condenser (In Stock - Ready to Ship)   + $2,822.25
9,000 BTU Wall Mount (In Stock - Ready to Ship)   + $552.75 View Item
9,000 BTU Wall Mount (In Stock - Ready to Ship)   + $552.75
9,000 BTU Wall Mount (In Stock - Ready to Ship)   + $552.75 View Item
9,000 BTU Wall Mount (In Stock - Ready to Ship)   + $552.75
9,000 BTU Wall Mount (In Stock - Ready to Ship)   + $552.75 View Item
9,000 BTU Wall Mount (In Stock - Ready to Ship)   + $552.75
28,600 BTU 19 SEER Mitsubishi Tri Zone  Heat Pump System 9+9+9

$4,480.50

Accessories for this product

Description

The Mitsubishi Tri Zone Mini Split Systems are state of the art ductless mini split heat pump systems, providing both heating and cooling for your home. Rated at 19 SEER, with an inverter-driven compressor, this efficient system will keep operating costs down while providing year-round comfort. Each living space has its own air-handling unit and each unit has its own wireless electronic temperature controller.

Indoor Units

The Mitsubishi MSZ-GL Series Wall Mount Air Handler is a perfect fit for your home. With multiple operating modes, multiple fan speeds, and multiple airflow directions, this unit fits the needs of nearly any room. The MSZ-GL Series combines a hybrid catechin deodorizing filter with an enzyme-based filter for managing allergens. The anti-allergy filter captures offending particles while also breaking them down, cleaning the air as it is conditioned. Mitsubishi's hot start technology prevents cold drafts by delaying fan operation until the heat exchanger has warmed up. By adjusting the cooling set point and swinging the horizontal vanes, the unit can improve the efficiency of operation without compromising the comfort provided. When the indoor unit is run in dry mode, the coil's temperature stays just below the dew point of the return air, removing unwanted moisture. This improves comfort and reduces the chance of mold growth and other property damage in the conditioned space. Auto mode selects the best vane position based on operating mode, and the swing modes cycle through all positions for maximum coverage.

Outdoor Unit

The Mitsubishi Ductless Mini Split MXZ Series Heat Pump and Air Conditioner Condenser has an INVERTER-driven compressor pump that cools or warms refrigerant and sends it inside to an air handler through small pipes. Each living space has its own air-handling unit and each unit has its own wireless electronic temperature controller.

With the Mitsubishi Ductless Mini Split MXZ Series Heat Pump Air Conditioner Multi zone condenser each room or zone operates independently with its own wireless or wired remote controller so people in different rooms can choose the temperature that makes them most comfortable. This unit will work with a variety of indoor unit combinations; with indoor options such as Wall mounted ductless, Floor mounted ductless, Ceiling recessed cassette ductless, horizontal ducted ductless or even multi position ducted air handlers.

Checkout more Mitsubishi tri zone ductless mini split systems here!

30,000 BTU Ductless Mitsubishi Mini-Split Multi Zone MXZ-C Series - Heat Pump Condenser

OVERVIEW

The Mitsubishi MXZ-3C30NA2 is a heat pump condenser designed to be used in multi zone system setups. As one air handler is needed per room that you are trying to heat and cool, multiple single zone condensers can take up a lot of space in your yard, making a multi zone unit more practical in many applications.

FEATURES

  • 30,000 BTU multi zone heat pump condenser
  • Variable speed Inverter-driven compressor
  • Quiet operation
  • Supports enhanced comfort down to -4°F
30,000 BTU

The Mitsubishi MXZ-3C30NA2 is rated at 30,000 BTU, which generally should be the same or greater than the total BTU count across all air handlers that this unit is paired with. In some instances, a certified pairing will have a higher BTU count total than this condenser’s rating. This is intentional, as the condenser can easily handle more, however anything higher than this rating can potentially lower the speed that the unit can heat and cool, as well as limit the functional outputs of each air handler if they are all running at the same time.
Please note that in order to function, this heat pump condenser must be installed with compatible air handlers, controllers, and other installation equipment, available at an additional cost

Warranty

Mitsubishi offers a 5 year parts and 7 year compressor warranty on all of its products. When the unit is registered online through the manufacturer after an installation that follows your state and local codes, the warranty is upgraded to a 10 year parts and compressor warranty.

Enhanced Comfort

With its variable speed compressor, the MXZ-3C30NA2 can provide more precise adjustments to the covered spaces with the right air handlers. This also slightly improves electrical efficiency by ramping the compressor up and down based on the unit’s air handlers’ needs, as well as providing a more stable temperature output from the connected air handlers to provide superior comfort.

Intelligent Control

For ease of control, many air handlers that are compatible with the MXZ-3C30NA2 can use any Mitsubishi-brand thermostat or adapter. The most convenient to control— the Kumo cloud WiFi adapter, found here—allows each air handler to be accessed from anywhere that you have Internet. Please note that in most applications, you will need one thermostat or adapter per indoor air handler that you want to be able to control with it.

9,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone GL - Air Handler

The Mitsubishi MSZ-GL09NA air handler is designed to be able to function as a single zone system or with a multi zone system setup. This unit is manufactured as part of Mitsubishi’s standard air handler series, making it an inexpensive choice for efficient home comfort. With its ability to work with both cooling-only and heat pump condensers, the MSZ-GL09NA can function in almost any basic configuration and application. The unit also has the ability to ramp up and down based on the thermostat’s needs along with an automated vertical air swing adjustment system to direct the airflow where it needs to go, keeping you comfortable year-round with the right condenser.

Please note that in order to function, this air handler must be installed with a condenser and other installation equipment, available at an additional cost.

  • Able to cover up to a small room in ideal conditions
  • 9,000 BTU wall-mounted air handler with remote
  • Automatic adjustments to match the thermostat’s needs
  • .225 gallon per hour dehumidification rate

Product Specifications

More Information
30,000 BTU Ductless Mitsubishi Mini-Split Multi Zone MXZ-C Series - Heat Pump Condenser
Refrigerant Charge Pre-Charged For: 98'
Weight (in lbs) 140.000000
AHRI Certificate Number 201755942, 201754907, 201755017
Manufacturer Mitsubishi
Additional Information Heat Pump
Additional Information Maximum Line Set Length: 82'
Additional Information Maximum System Line Length: 230'
HSPF 10.6
Cooling BTU 28,400 BTU
Heating BTU 28,600 BTU
Decibel Level (dBA) 52-56
Energy Star No
Refrigerant R410A
SEER 18-20
EER 10.6
Liquid Line 1/4" (3)
Suction Line 1/2" (1), 3/8" (2)
Electrical 208/230V 1 Phase 60 Hz
Max Breaker Size 25
Min. Breaker Size 22.1
Min/Max Outdoor Temp for Heating 5°-65°
Min/Max Outdoor Temp for Cooling 14°-115°
Zone Compatibility Multi Zone
Operating Mode Cooling, Heating
Height 31"
Width 37"
Depth 13"
Warranty 10 Years with Online Registration
Resources You will need Adobe® Acrobat® Reader to view PDF documents.
Safety Information PROPOSITION 65 WARNING
9,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone GL - Air Handler
Weight (in lbs) 26.000000
Manufacturer Mitsubishi
Controller Wireless Included
Additional Information Drain: 5/8"
Cooling BTU 9,000 BTU
Heating BTU 10,900 BTU
Maximum CFM 109-406 CFM
Decibel Level (dBA) 19-43
Refrigerant R410A
Capacity Dehumidification Rate: 0.23 gal/hr
Liquid Line 1/4"
Suction Line 3/8"
Electrical 208/230v 1 Phase 60 Hz
Mini-Split Type Wall Mounted
Zone Compatibility Multi Zone
Operating Mode Cooling, Heating
Height 11-5/8"
Width 31-7/16"
Depth 9-1/8"
Warranty 10 Years with Online Registration
Resources You will need Adobe® Acrobat® Reader to view PDF documents.
Safety Information PROPOSITION 65 WARNING
