AHRI Number:201754296
Designed with enhanced efficiency and supreme comfort, the Mitsubishi MSZ-FS09NA / MUZ-FS09NA single-zone mini-split is an ideal wall mounted unit to heat and cool a single room of your home or office. With its enhanced sensors and automatic intelligent controls, the MSZ-FS09NA / MUZ-FS09NA is considered a superior unit from a superior manufacturer.
At an output of 9,000 BTU and an efficiency rating of 30.5 SEER, Mitsubishi designed the MSZ-FS09NA / MUZ-FS09NA to be a good suit for any small rooms in ideal climate conditions. With a higher efficiency over many other options, this unit is efficient enough Energy Star certified.
Mitsubishi provides a 5 year parts and 7 year compressor warranty out of the box. When the unit is installed following your state and local codes and is registered online through the manufacturer, the warranty is upgraded to a 10 year parts and compressor warranty.
The Mitsubishi MSZ-FS09NA / MUZ-FS09NA will provide heat down as low as a -4°F outdoor temperature, reliably providing warmth to the room it is covering year-round in mild climates.
The Mitsubishi MSZ-FS09NA / MUZ-FS09NA mini-split comes with an IR remote in the box so that the unit can be controlled anywhere in the room. conveniently providing you access to the unit’s controls from anywhere in the world as long as you have Internet access through the app.
The Mitsubishi MSZ-FS09NA / MUZ-FS09NA is engineered to perfection in its intelligent automated temperature controls. The Mitsubishi MSZ-FH09NA / MUZ-FH09NA is designed to automatically ramp up and down depending on your room’s cooling needs in order to keep a stable temperature. Moreover, the system is built with an integrated I-SEE sensor, which constantly measures temperatures in different points in the room to change the direction of air flow as needed. Effectively, this feature allows the unit to focus its efforts on the part of the room that needs heat or cooling the most, keeping a much more stable temperature in the room than units without the I-SEE sensor. With all of these enhanced comfort features, the MSZ-FS09NA / MUZ-FS09NA definitely lives up to Mitsubishi’s superior standards.
| 9,000 BTU 30.5 SEER Wall Mounted Mitsubishi Mini-Split Single Zone Heat Pump - MZ-FS09NA | |
|---|---|
| Refrigerant Charge | Pre-Charged For: 25' |
| Weight (in lbs) | 114.000000 |
| AHRI Certificate Number | 201754296 |
| Brand/Manufacturer | Mitsubishi |
| Controller | Wireless Included |
| Additional Information | Heat Pump |
| Additional Information | Maximum Line Set Length: 65' |
| Additional Information | Drain: 5/8" |
| HSPF | 13.5 |
| Cooling BTU | 9,000 BTU |
| Heating BTU | 10,900 BTU |
| Maximum CFM | 117-381 CFM |
| Decibel Level (dBA) | Indoor Unit: 20-42 | Outdoor Unit: 48-49 |
| Energy Star | Yes |
| Refrigerant | R410A |
| Capacity | Dehumidification Rate: 0.23 gal/hr |
| SEER (Efficiency) | 26-30 |
| EER | 16.1 |
| Liquid Line | 1/4" |
| Suction Line | 3/8" |
| Electrical | 208/230V 1 Phase 60 Hz |
| Max Breaker Size | 15 |
| Min. Breaker Size | 11 |
| Amperage Requirement | 15 |
| Mini-Split Type | Wall Mounted |
| Min/Max Outdoor Temp for Heating | -13°-75° |
| Min/Max Outdoor Temp for Cooling | 14°-115° |
| Operating Mode | Cooling, Heating |
| Height | Indoor Unit: 12-11/16" | Outdoor Unit: 21-5/8" |
| Width | Indoor Unit: 36-7/16" | Outdoor Unit: 31-1/2" |
| Depth | Indoor Unit: 9-3/16" | Outdoor Unit: 11-1/4" |
| Additional Info | Indoor Unit Weight: 34 lbs | Outdoor Unit Weight: 88 lbs |
| Warranty | 10 Years with Online Registration |
| Resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
| Safety Information | PROPOSITION 65 WARNING |
