MRCOOL Olympus 9,000 BTU Ductless Mini Split Wall Mounted Air Handler 230 V | R410A

MRCOOL Olympus 9,000 BTU Ductless Mini Split Wall Mounted Air Handler 230 V | R410A - O-09-HP-WMAH-230B
MRCOOL Olympus 9,000 BTU Ductless Mini Split Wall Mounted Air Handler 230 V | R410A - O-09-HP-WMAH-230B MRCOOL Olympus 9,000 BTU 3/4 Ton Ductless Mini Split Wall Mounted Air Handler - 230V/60Hz - O-09-HP-WMAH-230A MRCOOL Olympus 9,000 BTU 3/4 Ton Ductless Mini Split Wall Mounted Air Handler - 230V/60Hz - O-09-HP-WMAH-230A MRCOOL Olympus 9,000 BTU 3/4 Ton Ductless Mini Split Wall Mounted Air Handler - 230V/60Hz - O-09-HP-WMAH-230A MRCOOL Olympus 9,000 BTU 3/4 Ton Ductless Mini Split Wall Mounted Air Handler - 230V/60Hz - O-09-HP-WMAH-230A HVAC Direct HVAC Direct HVAC Direct HVAC Direct HVAC Direct HVAC Direct HVAC Direct HVAC Direct
MRCOOL Olympus 9,000 BTU Ductless Mini Split Wall Mounted Air Handler 230 V | R410A
SAVE $259.00
Be the first to review this product
Out of stock
By

MRCOOL

Out of stock
Model

O-09-HP-WMAH-230B

ID

210802

No Return Policy: All sales of this product are final and are non-refundable.

MRCOOL® Olympus O-09-HP-WMAH-230B 9k Ductless Mini-Split Wall-Mounted Air Handler

The MRCOOL® Olympus O-09-HP-WMAH-230B Wall-Mounted Air Handler delivers 9,000 BTU of reliable heating and cooling for single-zone comfort. ENERGY STAR® certified and designed for efficiency, it combines quiet performance with smart control options, making it a dependable solution for year-round comfort in rooms up to 750 sq. ft.

Easily control your comfort with the included remote, the SmartHVAC app, or hands-free voice commands via Amazon Alexa or Google Assistant. Installation is straightforward when paired with a compatible MRCOOL Olympus condenser, and the unit’s ductless design eliminates the need for extensive remodeling.

Key Features

  • 9,000 BTU cooling capacity / ~9,800 BTU heating capacity
  • ENERGY STAR® certified for high efficiency
  • SmartHVAC app control with Alexa and Google Assistant compatibility
  • Follow Me mode for precise temperature control
  • Auto Swing for consistent air distribution
  • Sleep Mode for quiet, energy-efficient operation
  • Turbo Mode for rapid heating or cooling
  • Auto Restart for seamless recovery after power loss
  • Refrigerant Leakage Detection for added safety
  • Washable, reusable air filter
  • Line Set Size: 1/4" – 3/8"

Specifications

  • Model: O-09-HP-WMAH-230B
  • Voltage: 208–230V, 1 Phase, 60Hz
  • Net Dimensions (W x D x H): 32.87 in x 7.25 in x 11 in
  • Net Weight: ~30 lbs
  • Recommended Coverage Area: up to ~750 sq. ft.
  • Certifications: ENERGY STAR®, AHRI Certified, ETL Listed
  • Installation by a Licensed Professional required (where applicable)
More Information
MRCOOL Olympus 9,000 BTU Ductless Mini Split Wall Mounted Air Handler 230 V | R410A
FeatureSpec
SKUO-09-HP-WMAH-230B
Weight (in lbs)28.88
Brand/ManufacturerMRCOOL
UPC605468087022
Cooling BTU9000 BTU
Heating BTU9000 BTU
RefrigerantR410A
Liquid Line1/4 in
Suction Line3/8 in
Electrical230 V. 1 Phase 60 Hz
Max Breaker Size15 amp
Min. Breaker Size3 amp
BTU/Tonnage9,000 BTU/0.75 Ton
Mini Split TypeWall Mounted
CertificationEnergy Star, ETL Listed, cUL/UL Listed, Prop65
Dimensions2.87 W x 7.80 D x 11.02 H
Height11.02 in
Width32.87 in
Depth7.8 in
Warranty5-year Parts/7-year Compressor/1-year Remote
