80,000 BTU 80% AFUE Single Stage Gas Furnace | 17.5" Width | Upflow/Horizontal

SAVE $186.00
By

Private Brand

In stock
Model

AQ-GR9S800803BN

ID

197205

Was $1,236.00 Your Low Price Special Price $1,050.00
In Stock - 89 Ready to Ship
Free Shipping


Requires: Metal Flue Vent Piping

OVERVIEW

The AQ-GR9S800803BN ACiQ gas furnace features high-quality construction and efficient operation at a great value. The AQ-GR9S800803BN single-stage, 9-speed furnace utilizes ACiQ's superior heat exchanger design to provide efficient, reliable heating to your home. If you're looking to cut your energy bills and improve your comfort without breaking the bank, your search stops with the ACiQ AQ-GR9S800803BN.

QUICK FACTS

  • This furnace is ideal to heat a medium-sized house (depending on climate)
  • 80,000 BTU 80% efficient natural gas furnace
  • Requires metal flue venting
  • Complies with Clean Air Act New Refrigerant Requirements
  • Can be used in the upflow or horizontal orientation
  • Can be converted to an LP furnace with a conversion kit (sold separately)
  • Innovative design for electrical efficiency, safety, and lower sound output

80,000 BTU

The AQ-GR9S800803BN ACiQ gas furnace is 80,000 BTU's. This BTU count is a measure of the input of the furnace per hour, while the output of this furnace is 64,000 BTU's (80,000 X 80% AFUE) per hour. In ideal climate conditions, this 80,000 BTU furnace is usually used to heat a medium-size house.

80% Efficiency Rating

The AQ-GR9S800803BN ACiQ gas furnace is 80% efficient, which meets the market's minimum furnace efficiency standards. This means that 80% of the gas going into the furnace is used to heat your home and the remaining 20% is lost out of the flue venting. Please note that all 80% furnaces must be vented using metal flue venting, while any furnace with an efficiency of 90% or higher must be vented using plastic/PVC venting.

Please note that this furnace does not comply with California Low NOx or Ultra-Low NOx regulations. If you have any questions, please contact us.

Single Stage Furnace

The AQ-GR9S800803BN ACiQ gas furnace is a single stage furnace has only one heat output. Regardless of the indoor temperature, this furnace will burn at 100% output whenever the thermostat calls for it. Like a light switch, this furnace's burner will either be on or off and nothing in between. A single stage furnace is the standard efficient furnace since every time your furnace turns on the furnace uses the same amount of energy.

Natural Gas or LP Furnace

From the factory, the AQ-GR9S800803BN runs on natural gas. However all ACiQ gas furnaces can be converted to propane using the furnace's corresponding LP conversion kit, an optional accessory at an additional cost that consists of a replacement set of orifices and springs.

9-Speed ECM Blower Motor

Instead of the last generation PSC blower motor, the AQ-GR9S800803BN utilizes a 9-speed ECM motor, which uses less power and provides smarter air circulation. All of this causes an overall increase in the electrical efficiency of your furnace, which saves you money.

Warranty

With installation that follows your state and local codes and with online registration, all ACiQ furnaces come with a 10-year parts and lifetime heat exchanger warranty through the manufacturer.

Durable Hot Surface Ignitor

The hot surface ignitor on modern ACiQ furnaces are more durable than previous designs, decreasing related issues and lowering maintenance costs. These hot surface ignitors are also more efficient than standing pilot and older HSI designs, saving you even more money.

Self-Diagnostic Control Board

The ACiQ brand has improved technology from years of production experience, allowing for a long-lasting product that rarely has any issues. However, if something does go wrong on the furnace, the control board has a set of sensors that allow it to diagnose basic issues, allowing for easy troubleshooting and to notify the owner if basic maintenance or warranty work is recommended. This increases the overall safety of the unit, for the furnace itself and the occupants of the home where it is installed.

Heavy Gauge Steel Cabinet

The heavy-gauge steel cabinet on new ACiQ furnaces provide adequate protection to the internal mechanisms of the unit. The cabinet is also more air-tight than previous models, allowing for a quiet, more economical unit due to losing less heat and preventing more sound from exiting the unit.

Ease of Installation

The value of modern ACiQ furnaces doesn't end at efficiency. Today's ACiQ furnaces feature many different connection options to reduce installation. The AQ-GR9S800803BN model has a more universal design, which consists of its ability to be installed in both an upflow or horizontal configuration. This allows for an easier installation in more locations, from your attic to your basement. The furnace also comes with color-coded low-voltage terminals that allow for a shorter and easier installation time, which decreases installation costs.

More Information
80,000 BTU 80% AFUE Single Stage Gas Furnace | 17.5" Width | Upflow/Horizontal
FeatureSpec
SKUAQ-GR9S800803BN
Weight (in lbs)116
AHRI Certificate Number215358053
Airflow DirectionUpflow/Horizontal
Exhaust Flue RequirementMetal
Brand/ManufacturerPrivate Brand
Furnace Efficiency / AFUE 80%
Heating BTU80,000
Blower Motor9-Speed - ECM
Maximum CFM1200
ConfigurationUpflow/Horizontal
Electrical115v 1 Phase 60 Hz
Max Breaker Size15 Amps
Min. Breaker Size7.7 Amps
Burner StagesSingle
Fuel TypePropane, Natural Gas
Height33 3/8"
Width17 1/2"
Depth28"
WarrantyLifetime Heat Exchanger and 10 Years Parts with Online Registration
Resources You will need Adobe® Acrobat® Reader to view PDF documents.
Safety Information
This gas appliance requires a trained technician to install. Improperly connecting gas lines or improperly connecting a gas flue or venting may result in death. By purchasing this item, you are agreeing that you are using a trained technician to install this gas appliance. We will not be responsible for any injury or property damage arising from improper service or service procedures. Whoever installs or services this unit assumes responsibility for any personal injury or property damage which may result. Many jurisdictions require a license to install this equipment.

PROPOSITION 65 WARNING

Customers Say

Reviewers report effective, quiet heating: one says a 120,000-BTU, 80%-efficiency furnace keeps a 2,100-square-foot home comfortable, while another says their furnace heats a 1,320-square-foot house. Several found installation manageable, including an owner who replaced a 24-year-old Carrier in three hours, but others reported missing instructions or shipping damage, and one warned that DIY installers need a certified technician’s troubleshooting report for warranty claims.

AI Generated from the text of customer reviews

Top reviews
  1. ACIQ furnace assembly, good deal but slight quality issues
    Quality
    60%
    Service
    100%
    Price
    100%
    I just installed this furnace in a household, and it has been running well over the past 2 weeks. Once furnace was out of the box, I could confirm no physical damage had occurred to the outside casing from shipping. However, I found half installed screws/ bolts upon removal of the service covers. The blower motor fan bracket had 1 of 3 bolts backed almost all the way out, and the control board bracket had both bottom self tappers missing (found them at the bottom of the case) the blower motor bolt tightened down correctly to the blower shroud, no issue. The control board screws felt like they had been overtightened on initial install and would no longer hold torque when trying to reinstall them. This was not a major Issue to install and tighten hardware. Build quality and resilience over time is the main concern. If those bolts/ screws were not tightened properly, what else may be loose? If the hardware got loosened from shipping vibrations, will the hardware become loose again after hours of system run time? Overall, it seems like a good reliable unit. Just make sure to do a very good inspection for loose parts or other defects even if the casing looks to be in good condition.

    Review by

    Posted on

  2. Great products at good prices.
    Quality
    100%
    Service
    100%
    Price
    100%
    Amana, Goodman, and now A/C iq. I've sold Amana tubular heat exchangers in Alaska for years and never saw a failure one time.

    Review by

    Posted on

  3. Great product
    Quality
    100%
    Service
    100%
    Price
    100%
    Pretty easy installation in a 3’ crawl space, this was 6” shorter than my previous application but I was able to rework my ducting. Just know that it initially needs programming if you’re using as a furnace only application. Read the instructions thoroughly and you’ll be fine. Overall very satisfied.

    Review by

    Posted on

  4. Replacment
    Quality
    100%
    Service
    100%
    Price
    100%
    Ordered the furnance, it was a great price arrived in less than a week. Works great will use for future orders

    Review by

    Posted on

  5. Excellent furnace!
    Quality
    100%
    Service
    100%
    Price
    100%
    This is my second Goodman furnace from HVAC direct. I'm very happy with both of them!

    Review by

    Posted on

  6. Impeccable timing
    Quality
    100%
    Service
    100%
    Price
    100%
    Had to replace a furnace for a customer at last minute before the snow flys up here in michigan. And HVAC direct was quick. Within 5 days QUICK!!! and affordable TOO. We will deff be using you in the future for all our furnace needs.

    Review by

    Posted on

  7. So great
    Quality
    100%
    Service
    100%
    Price
    100%
    Just as described and works great so far. We have only tested the furnace

    Review by

    Posted on

  8. As advertised, no issues.
    Quality
    100%
    Service
    100%
    Price
    100%
    All was good.

    Review by

    Posted on

See more reviews
Customer Questions
Who makes this HVAC equipment?
This HVAC equipment is manufactured by a leading U.S. HVAC manufacturer known for producing high-quality, reliable heating and cooling systems. It is built to rigorous industry standards and designed to deliver lasting performance and efficiency.
Does this gas furnace provide air conditioning?
A standalone gas furnace provides heating but does not include an air conditioner condenser or evaporator coil. It may be able to circulate cooled air as part of a properly matched central air conditioning system when compatible equipment is installed separately.
Can this furnace work with my existing air conditioner?
It may work with an existing air conditioner if the indoor blower, refrigerant coil, controls, and airflow capacity are compatible. Your installer should confirm the equipment match and check any additional safety controls required when updating part of an existing system.
How do I know what size furnace I need for my home?
The correct furnace capacity depends on the home’s heating load, climate, insulation, windows, and ductwork—not square footage alone. A qualified HVAC professional can perform a heating load calculation and compare the results with the furnace’s published heating output.
Can this furnace use natural gas or propane?
The supported fuel options depend on the exact furnace model and its approved conversion requirements. Review the product specifications and installation manual before selecting natural gas or propane, and have any required conversion performed by a qualified professional.
What installation requirements should I check before replacing my furnace?
Confirm the required venting type, airflow direction, gas supply, electrical connections, cabinet dimensions, and available installation space. A qualified installer should also evaluate the existing ductwork, combustion air, and local code requirements.
