ACiQ 10 Ton 180,000 BTU 11 EER Light Commercial Gas Packaged Unit | 460V 3 Phase - R410A - Two Stage

ACiQ 10 Ton 180,000 BTU 11 EER Light Commercial Gas Packaged Unit | 460V 3 Phase - R410A - Two Stage
SAVE $4,353.66
By

ACiQ

In stock
Model

RGV120LE3A0AAA

ID

143655

Was $16,124.66 Your Low Price Special Price $11,771.00
ONLY 4 LEFT!

Product Features
  • Designed for Easy Retrofit Installs
  • Custom Roof Curbs designed to fit your current adapter!
  • Precharged with R410a Refrigerant
  • 2-Stage Condenser
  • 460V 3 Phase
  • Up to a 10-Year Limited Warranty with Online Registration

Call 800-397-1392 for Best Prices!

OVERVIEW

ACiQ's 10 Ton Gas/Electric Packaged Units with X-Vane Fan Technology provide value-added benefits never seen in this type of equipment before.

Features

  • 10 Ton, 15.0 IEER, 11.0 EER
  • Up to 180,000 Heating BTUs with 80% efficiency
  • High Static, Medium Heat
  • Beltless direct-drive vane axial fan for rooftop units with electric commutated variable speed motor (ECM)
  • Reliable fixed speed scroll compressor with internal line-break overload protection
  • Upgraded unit control board with intuitive indoor fan adjustment
  • Reliable copper tube / aluminum fin condenser coil with 5/16-in. tubing to help reduce refrigerant charge
  • New outdoor fan system with rugged, lightweight high impact composite fan blade
  • R-410A refrigerant and a fixed refrigerant metering device
  • Single point gas and electrical connections
  • Optional Hot Gas Re-Heat dehumidification system for improved part load humidity performance
  • Field-convertible to horizontal airflow

Installation Ease

All RGV units are field convertible to horizontal airflow, which makes it easy to adjust to unexpected job site complications. Gas/Electric Packaged Units are specifically designed to fit on our existing roof curbs dating back to 1989 for worry-free original fit. Also, our large control box gives you room to work and room to mount accessory controls. Intuitive controls make setting up the required fan speed simple and accurate. Access to the blower section is no longer needed with the new design.

Easy to Maintain

With the new vane axial fan and direct drive ECM motor, there is no longer a need to adjust belts or pulleys as in past designs, reducing maintenance and installation time. Easy access handles provide fast access to all normally serviced components. The "œno-strip" screw system has superior holding power and guides screws into position while preventing the screw from stripping the unit's metal. Sloped, corrosion resistant composite drain pan sheds water and prevents rust. RGV units are designed with a naturally draining heat exchanger. Unlike positive pressure heat exchangers, this does not need to be periodically, manually drained, saving costs on labor and maintenance.

Easy to Use

The unit control board puts all connections and troubleshooting points in one convenient place. Most low voltage connections are made to the same board for easy access. Setting up the fan is made simple by an intuitive switch and rotary dial arrangement. Gas/Electric Packaged Units have high and low pressure switches, a filter drier, and 2-in. filters standard.

X-Vane Fan Technology

The direct drive X-Vane indoor fan system uses a vane axial fan design and electrically commutated motors. This vane axial design compared to past belt drive systems has 75% fewer moving parts, uses up to 40% less energy and has no fan belts, blower bearings, or shaft.

Warranty

ACiQ offers a very comprehensive warranty policy on Gas/Electric Packaged Units, including a 10 year warranty on the aluminized heat exchanger, a 5 year warranty on the compressor, and a 1 year warranty on any replacements parts. For these warranties to be upheld, the packaged unit must be installed following your state and local codes. They must also be properly serviced maintained over the warranty's life, requiring a minimum of once-per year maintenance.

Packaged Unit Buyers Guide

  • How packaged units work for residential and commercial use
  • The different types of packaged units
  • Figuring out the right size unit for your needs
  • The importance of a custom curb adapter
  • And much more!
More Information
ACiQ 10 Ton 180,000 BTU 11 EER Light Commercial Gas Packaged Unit | 460V 3 Phase - R410A - Two Stage
FeatureSpec
SKURGV120LE3A0AAA
Refrigerant ChargePre-Charged
Weight878
ManufacturerACiQ
UPC634707279584
EquivalentCarrier Equivalent: 48FCEM12A3A6-0A0A0
Furnace Efficiency / AFUE 80%
Cooling BTU118,000 BTU
Heating BTU180,000 BTU
Drive TypeDirect
Maximum CFM3500
Decibel Level (dBA)79 Decibels
RefrigerantR410A
EER11.0
IEER15.0
Condenser StagesTwo Stage
Compressor TypeScroll
Electrical460v 3 Phase 60 Hz
Electric Phase FilterThree Phase
Tonnage10 Ton
Burner StagesTwo
Height49 3/8"
Width53 7/8"
Warranty10 Years Aluminized Heat Exchanger, 5 Years Compressor, and 1 Year Parts
Resources You will need Adobe® Acrobat® Reader to view PDF documents.
Safety Information
This gas appliance requires a trained technician to install. Improperly connecting gas lines or improperly connecting a gas flue or venting may result in death. By purchasing this item, you are agreeing that you are using a trained technician to install this gas appliance. We will not be responsible for any injury or property damage arising from improper service or service procedures. Whoever installs or services this unit assumes responsibility for any personal injury or property damage which may result. Many jurisdictions require a license to install this equipment.

PROPOSITION 65 WARNING
Write Your Own Review
You're reviewing:ACiQ 10 Ton 180,000 BTU 11 EER Light Commercial Gas Packaged Unit | 460V 3 Phase - R410A - Two Stage
Your Rating
Customer Questions
What does BTU and Tonnage Mean?
BTU (British Thermal Unit) measures the amount of heating or cooling energy a commercial rooftop packaged unit can produce per hour, while tonnage measures the unit's nominal cooling capacity. One ton of cooling equals 12,000 BTU/h, meaning a 10-ton commercial rooftop unit provides approximately 120,000 BTU/h of cooling capacity. Both measurements help contractors and customers determine the appropriate HVAC system size and output for a building's heating and cooling requirements.
What accessories or additional components are needed to install a Commercial Rooftop Units?
Installing a commercial rooftop unit may require several accessories and additional components depending on the building's existing setup and installation requirements. Common components include a roof curb or curb adapter, ductwork transitions, electrical disconnects, thermostats, economizers, dampers, and supplemental heating kits when applicable. Additional accessories, such as hail guards, smoke detectors, and condensate drain components, may also be recommended based on the application. Always verify equipment compatibility and manufacturer installation requirements before purchasing additional components.
Can I replace my existing Commercial Rooftop Unit without replacing the ductwork?
Yes. In many cases, an existing commercial rooftop unit can be replaced without replacing the current ductwork, provided the duct system is in good condition and compatible with the new equipment. Before installation, an HVAC professional should evaluate the ductwork, airflow requirements, unit capacity, and existing connections to ensure proper system performance. Additional modifications may be necessary if the new unit has different dimensions, airflow configurations, or connection requirements.
What is the difference between EER and IEER ratings on Commercial Rooftop Units?
EER (Energy Efficiency Ratio) and IEER (Integrated Energy Efficiency Ratio) are ratings used to measure the cooling efficiency of commercial HVAC equipment. EER measures how efficiently a unit operates under specific full-load outdoor temperature and operating conditions, while IEER evaluates efficiency across multiple operating conditions, including part-load performance. IEER provides a broader picture of how efficiently a commercial rooftop unit operates under varying cooling demands throughout the year. Higher EER and IEER ratings generally indicate greater energy efficiency and potentially lower operating costs.
Can a Commercial Rooftop Unit be installed on the ground instead of the roof?
Yes. Some commercial packaged rooftop units can be installed at ground level when the equipment is designed for horizontal airflow rather than vertical rooftop discharge. These horizontal-flow units require adequate space, a stable mounting surface, proper ductwork connections, and sufficient clearance for airflow and servicing. Always verify the manufacturer's installation requirements and local building codes before selecting a ground-level installation.
Do Commercial Rooftop Units require professional installation?
Yes. Commercial rooftop units should be installed by qualified HVAC professionals to ensure proper equipment placement, electrical connections, ductwork compatibility, refrigerant handling, and system performance. Professional installation helps ensure the unit operates safely and efficiently while meeting applicable building codes, manufacturer requirements, and local regulations.
