ACIQ 7.5 Ton 180,000 BTU 11.2 EER Commercial Gas Packaged Unit - Medium Heat | 460V 3 Phase - R454B - Two Stage

Reliable Two-Stage 7.5-Ton Gas/Electric Packaged Rooftop Unit for Light Commercial Applications with X-Vane™ Fan Technology

The ACiQ RGF090LE2A0AAA is a commercial gas/electric packaged rooftop unit designed to provide reliable year-round heating and cooling for light commercial applications. The RGF090-180 platform combines two-stage cooling with two-stage gas heating, direct-drive ECM/Vane Axial X-Vane™ fan technology, and convertible airflow in a single outdoor package. The RGF090-180 platform is available with 208/230V, 460V, or 575V three-phase electrical configurations; the L configuration uses 460V, three-phase power.

Key Benefits

• Up to 11.2 EER / 15.2 IEER – Provides efficient cooling performance across full-load and part-load operating conditions within the RGF090-180 platform.
• Two-Stage Gas Heating – Provides two levels of gas-heating operation to better match changing commercial heating requirements.
• Two-Stage Cooling – Provides staged cooling capacity to help match changing building loads while supporting consistent comfort.
• Direct-Drive X-Vane™ Fan – Uses direct-drive ECM/Vane Axial technology to eliminate conventional belt-driven fan components.
• Convertible Airflow Design – Provides installation flexibility by supporting field-convertible airflow configurations.
• Multiple Static Fan Options – Standard, medium, and high-static fan motor options are available across the RGF platform for different duct-system requirements.
• Packaged Rooftop Configuration – Combines gas heating, electric cooling, indoor air movement, and controls in one outdoor unit to help conserve indoor space.
• Factory-Installed Economizer Option – Provides an available outdoor-air economizer option for applications requiring ventilation and free-cooling capability.

Two-Stage Gas Heating

The integrated gas heating system uses two-stage operation to provide heating capacity appropriate for changing commercial load conditions. The RGF090-180 platform is offered with low-, medium-, and high-heat configurations, allowing the equipment to be selected for the heating requirements of the application.

7.5-Ton Two-Stage Cooling Performance

The RGF090 model is part of the RGF090-180 packaged gas/electric platform covering nominal sizes from 7.5 to 15 tons. The platform uses scroll compressor technology and two-stage cooling. Cooling efficiency for the RGF090-180 platform reaches up to 11.2 EER and 15.2 IEER, depending on model and configuration.

Efficiency and X-Vane™ Fan Technology

The RGF090LE2A0AAA uses the RGF platform's direct-drive ECM/Vane Axial fan with X-Vane™ technology. This direct-drive design avoids conventional belt, pulley, shaft, and blower-bearing components associated with belt-driven fan assemblies. Standard, medium, and high-static fan motor options are available across the platform to accommodate different airflow requirements.

Packaged Rooftop Installation Design

The packaged rooftop configuration combines the gas furnace, electric cooling system, indoor fan, refrigeration components, and controls into one outdoor cabinet. The RGF090-180 platform supports convertible airflow, helping accommodate different duct and rooftop installation requirements. The L electrical designation corresponds to 460V, three-phase, 60 Hz service.

Controls & Comfort

The RGF platform provides two-stage heating and two-stage cooling operation for improved capacity matching. Direct-drive X-Vane™ fan technology provides controlled indoor airflow, while available control and ventilation options include factory-installed economizers and other commercial accessories for compatible applications.

Light Commercial Applications

The ACiQ RGF090LE2A0AAA is designed for light commercial rooftop applications requiring integrated gas heating and electric cooling. Its 7.5-ton nominal size, two-stage heating and cooling, 460V three-phase electrical configuration, convertible airflow design, and direct-drive X-Vane™ fan technology make it suitable for commercial buildings requiring a packaged rooftop heating and cooling solution.

Service & Maintenance

The direct-drive X-Vane™ fan design eliminates conventional belt-driven fan components, helping reduce routine belt and pulley maintenance. The RGF platform is designed with service accessibility in mind and supports options including hinged panels, fan/filter status monitoring, condensate overflow protection, non-fused disconnects, smoke detectors, and fault detection and diagnostics.

Warranty

The ACiQ RGF090LE2A0AAA is covered by applicable manufacturer limited warranty provisions for the RGF packaged rooftop product family. The RGF platform includes a 15-year limited warranty on stainless-steel heat exchangers, a 10-year limited warranty on aluminized heat exchangers, and applicable parts warranty coverage. Warranty periods, registration requirements, and other conditions are subject to the applicable manufacturer warranty certificate.

Recommended Accessories

• POL224 Economizer Controller – Optional economizer control for compatible outdoor-air applications.
• Hot Gas Re-Heat Adaptive Dehumidification – Optional humidity-control system for applicable installations.
• Non-Fused Disconnect – Optional factory-installed electrical disconnect.
• Power Exhaust – Optional exhaust system for compatible economizer applications.
• Condensate Overflow Switch – Optional condensate protection accessory.

Reliable Commercial Comfort with the ACiQ RGF090LE2A0AAA

Experience reliable year-round commercial comfort with the ACiQ RGF090LE2A0AAA. Combining two-stage gas heating and two-stage electric cooling with direct-drive X-Vane™ fan technology and convertible airflow in one packaged rooftop system.
