Trane 80% 40,000 BTU Single Stage Gas Furnace - 14" Width - Multi-Positional - RunTru by Trane

Trane

In stock

Model

A801X040AM3SD

158047

Rating:

96% of 100

See 7 Reviews Add Your Review

4 Questions Answered

Ships in 3-5 Business Days

$1,210.00

Free Shipping

Product Features

Standard efficiency 80% furnace
Single stage burner
Can be installed in upflow, downflow, or horizontal applications
Well-suited for small homes in various climates
9-speed constant torque ECM blower motor
14" cabinet width

Requires: Metal Flue Vent Piping

Description

OVERVIEW

The RunTru by Trane A801X040AM3SD is an inexpensive model of furnace to provide reasonable comfort to your home. At a basic efficiency, this furnace will heat your home adequately with the right output, providing comfort to your home even in the coldest parts of the year.

QUICK FACTS

40,000 BTU, 80% AFUE natural gas furnace
Proudly Made in the USA: High-quality HVAC equipment crafted with precision and reliability
Generally suitable for up to a small house in ideal applications
Multi-positional design - can be installed in the upflow, downflow, or horizontal orientations
Single stage burner with a multi-speed blower
Field-convertible to propane with an optional LP kit
On board self-diagnostics

40,000 BTU, 80% AFUE

The RunTru by Trane A801X040AM3SD has an input of 40,000 BTU. With an efficiency of 80%, this means that the furnace has an output of 32,000 BTU. The 80% AFUE also means that for the gas going into the furnace, 80% of it is used to heat your home while the remaining 20% is lost out the flue piping and lost to normal furnace operations. All 80% furnaces require metal flue venting, and if you need it to be plastic/PVC venting a furnace with an efficiency of 90% or above is required. While this unit uses natural gas as fuel out of the box, we also have an LP conversion kit, available at an additional cost. Please note that this furnace is not Low NOx or Ultra Low NOx compliant and if shipped to California may be subject to a mitigation fee.

Warranty

RunTru by Trane offers 10 year parts and 20 year heat exchanger limited warranties. Please note that in order for the heat exchanger and parts warranties to be upheld, the unit must be registered through the manufacturer within 90 days of installation. The installation must also follow your state and local codes.

Installation and Durability

With its ability to be installed in any configuration (upflow, downflow, or horizontal) the RunTru by Trane A801X040AM3SD is very versatile in application potential. The unit has a durable outer casing that can withstand wear-and-tear through its entire lifetime, providing the peace of mind that your home will stay comfortable year-round.

Product Specifications

More Information
Trane 80% 40,000 BTU Single Stage Gas Furnace - 14" Width - Multi-Positional - RunTru by Trane
SKU	A801X040AM3SD
Weight (in lbs)	102.000000
AHRI Certificate Number	204606299
Airflow Direction	Multi-Positional
Exhaust Flue Requirement	Metal
Brand/Manufacturer	Trane
Replaces	A801X040AM3SC
Product Features	New Refrigerant Compliant
Furnace Efficiency / AFUE	80%
Heating BTU	40,000
Blower Motor	Constant Torque ECM Motor
Configuration	Multi-Positional
Electrical	120v 1 Phase 60Hz
Max Breaker Size	15 Amps
Burner Stages	Single
Fuel Type	Propane, Natural Gas
Height	34"
Width	14.5"
Depth	28.75"
Warranty	20 Years Heat Exchanger and 10 Years Parts with Online Registration
Resources	A801X Installation Manual A801X080CM5SC Specifications Sheet RunTru by Trane Warranty You will need Adobe® Acrobat® Reader to view PDF documents.
Safety Information	PROPOSITION 65 WARNING This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please Click Here.

Reviews 7

Questions and Answers

Customer Questions

Who makes RunTru?

RunTru HVAC products are made by Trane Technologies, a well-known and reputable manufacturer in the heating, ventilation, and air conditioning (HVAC) industry. RunTru is a brand developed by Trane to offer reliable and cost-effective HVAC solutions, maintaining Trane’s commitment to quality and performance.

I'm looking to replace my Trane unit and this RunTru unit seems to have about the same specs - are they the same product?

RunTru is made by the same company as Trane as well as brands like American Standard, Ameristar, and OxBox. Many of the internal components can be cross-referenced for shared parts. So, yes, apart from the name on the badge – very similar if not identical.

What happens if it arrives damaged?

If you are present during drop-off and you see obvious signs of damage or rough handling in transit - please ask the driver to wait while you inspect the equipment. If it is damaged badly enough that you believe it can not function, you have the right to refuse the damaged portion of the shipment. If you discover the damage after the driver has left, take photos of the damage and send them to customerservice@hvacdirect.com. Please refer to your order number in the email. This starts the process and one of our representatives will be in touch with you promptly.

How can I find an installer?

It’s easier than you think – the key is to find an independent contractor or small company as opposed to a larger HVAC service. A one or two person outfit will do the work more quickly and cheaply than a bigger company, too. Yelp.com, Thumbtack.com, and Porch.com are websites that are designed to help you connect with a professional in your area. You could also place a call to the last professional who did work on your home and see if they have any recommendations.
