1.5 Ton 15 SEER Variable Speed Goodman Heat Pump Air Conditioner System
Model: GSZ160181 / AVPTC25B14

Price as configured: $2,571.00

1.5 Ton 15 SEER Variable Speed Goodman Heat Pump Air Conditioner System

By: Goodman Model: GSZ160181 / AVPTC25B14 ID: 1562

More Views

Suggested Retail: $3,085.00

Price as configured: $2,571.00

Bread Checkout

FREE SHIPPING
Goodman Manufacturing

New

* Required Fields

Price as configured: $2,571.00

Accessories

Description

Details

2 Ton Multi-Positional Variable Speed Goodman Air Handler

The Goodman AVPTC25B14 Multi-Position, Variable-Speed Air Handler is suitable for use with refrigerant R-410A and is compatible with the ComfortNet Communicating System family of products.

The AVPTC's Goodman 2 ton air handler blower design includes a variable-speed direct current motor, which helps eliminate the cold blast of air upon heating start-up often associated with single-speed units. This air handler is ideal for either new or retrofit installations.

Standard Features

  • Compatible with the ComfortNet Communicating System family of products
  • Maximum four low-voltage wires required for operation in communicating mode
  • Auto configuration of the airflow and tonnage in communicating mode
  • In non-communicating mode, up to 12 field-selectable airflow settings can be adjusted to optimize the system's CFM for each individual mode of operation
  • R-410A refrigerant-compatible
  • Factory-installed thermal expansion valves for cooling and heat pump applications
  • Tool-less filter access accommodates standard-size filters
  • Variable-speed ECM blower motor
  • All-aluminum evaporator coil
  • Provides constant CFM over a wide range of static pressure conditions independent of duct system
  • Provides adjustable low CFM for efficient fan-only operation
  • CFM indicator with front-panel sight glass
  • Improved humidity control and comfort
  • Compatible with variable-capacity heat pumps and cooling applications
  • Built-in coil has horizontal, vertical, and downflow drain pans with secondary drain connections
  • AHRI Certified; ETL Listed

Cabinet Features

  • Fully insulated, painted steel cabinet with attractive Architectural Gray finish
  • Compact, versatile upflow, downflow, or horizontal multi-position installations
  • Low-voltage cabinet connections; control circuit is arranged to permit staging
  • Power supply on top; low-voltage entry on top or side
  • Foil-faced insulation is glued in place and covers the entire blower case to reduce operating sound and cabinet condensation

1.5 Ton 16 SEER Goodman Heat Pump

OVERVIEW

At one of the higher efficiencies on the market, the Goodman GSZ160181 heat pump condenser is designed to save you money both up front and in energy bills over time. With its high-quality construction, the GSZ160181 is considered a good all-around choice for many applications.

QUICK FACTS

  • Designed to cover a smaller house in average climates
  • 1.5 ton, 16 SEER heat pump condenser
  • Low sound output
  • Fully charged for up to 15’ of line set
  • Factory-installed bi-flow filter drier
1.5 ton

The Goodman GSZ160181 heat pump is rated for 1.5 tons, which is normally enough to cover a smaller house in average climates. A heat pump coil or air handler is required for this condenser to function, and some indoor units will be larger in tonnage than this condenser in some bundles to maintain the unit’s overall efficiency.

16 SEER

With its high-end 16 SEER efficiency rating, the GSZ160181 is designed to save you money over the entire life of the unit. 16 SEER units will save you about 12% more in energy bills over a 14 SEER system, making this upgrade a smart upgrade to save you money over time with a small increase in your initial investment in the system.

Warranty

The GSZ160181 condenser comes with Goodman’s standard 10 year parts warranty with online registration through the manufacturer. An installation that follows your state and local codes is required for the warranty to be upheld.

Durability and Reliability

The cabinet on the GSZ160181 heat pump is designed to be durable in harsh conditions. With its baked-on polyester coat of paint, the unit is approved for up to 500 hours of salt spray. The enhanced durability and paint coat makes the GSZ160181 compliant with 2010 Florida building codes for unit integrity for hurricane-like winds when the unit is properly anchored. For reliability, there is also a built-in bi-flow filter drier that lowers general wear-and-tear on the internals of the unit.

Installation and Maintenance

In order to provide a faster and less expensive installation, the Goodman GSZ160181 heat pump is factory-installed with pressure switches, a high-capacity muffler, easily accessible gauge ports, and service valves with sweat connections. The cabinet of the unit is also fitted with dual access panels—one on the side and one on the top—to allow for a much easier maintenance procedure should the need for maintenance arise.

Comfort in Mind

The Goodman company has always promoted enhanced comfort, higher efficiency, and lower cost to all of its units. With SmartShift technology and an enhanced sound insulation structure, the GSZ160181 is whisper-quiet, allowing Goodman to continue to follow its goals in achieving the best comfort levels possible at a low cost.

5 Kilowatt 16,200 BTU Goodman Heater Coil

The Goodman HKS-C Series Heat Strip have rust resistant nickel chromium heat elements. Completely assembled and tested including a plug in wiring harness for ease of installation in Air Handlers. The Goodman HKS-C Series Heat Strips offer sequencers for better temperature control. Goodman has become one of the largest manufacturers of residential and light commercial air conditioning, heating, and indoor air quality products and systems by focusing on just one thing, building the most reliable and refreshingly affordable indoor comfort products in the market.

Compatible With

  • Goodman ARPT Air Handlers
  • Goodman ARUF Air Handlers
  • Goodman ASPT Air Handlers
  • Goodman ASUF Air Handlers
  • Goodman AVPTC Air Handlers

8 Kilowatt 23,800 BTU Goodman Heater Coil

The Goodman HKS-C Series Heat Strip have rust resistant nickel chromium heat elements. Completely assembled and tested including a plug in wiring harness for ease of installation in Air Handlers. The Goodman HKS-C Series Heat Strips offer sequencers for better temperature control. Goodman has become one of the largest manufacturers of residential and light commercial air conditioning, heating, and indoor air quality products and systems by focusing on just one thing, building the most reliable and refreshingly affordable indoor comfort products in the market.

Compatible With

  • Goodman ARPT Air Handlers
  • Goodman ARUF Air Handlers
  • Goodman ASPT Air Handlers
  • Goodman ASUF Air Handlers
  • Goodman AVPTC Air Handlers

10 Kilowatt 34,100 BTU Goodman Heater Coil

The Goodman HKS-C Series Heat Strip have rust resistant nickel chromium heat elements. Completely assembled and tested including a plug in wiring harness for ease of installation in Air Handlers. The Goodman HKS-C Series Heat Strips offer sequencers for better temperature control. Goodman has become one of the largest manufacturers of residential and light commercial air conditioning, heating, and indoor air quality products and systems by focusing on just one thing, building the most reliable and refreshingly affordable indoor comfort products in the market.

Compatible With

  • Goodman ARPT Air Handlers
  • Goodman ARUF Air Handlers
  • Goodman ASPT Air Handlers
  • Goodman ASUF Air Handlers
  • Goodman AVPTC Air Handlers

30 Feet of 3/8" LL x 3/4" SL x 3/8" Insulated Line Set

Line sets are the copper lines which connect an outdoor condensing unit/heat pump to an inside air handler or evaporator coil. Line sets are available in different lengths and diameters to fit most applications.

50 Feet of 3/8" LL x 3/4" SL x 3/8" Insulated Line Set

Line sets are the copper lines which connect an outdoor condensing unit/heat pump to an inside air handler or evaporator coil. Line sets are available in different lengths and diameters to fit most applications.

Specifications

2 Ton Multi-Positional Variable Speed Goodman Air Handler

skuAVPTC25B14
manufacturerGoodman
blower_motorVariable Speed - ECM
cfm1,165
electric_options5 Kilowatts, 8 Kilowatts, 10 Kilowatts
refrigerantR410A
liquid_line3/8"
suction_line3/4"
electrical208/240 V, 1 Phase, 60 Hz
max_breaker_size15 amps
min_breaker_size4.9 amps
nominal_capacity2 Ton
height45"
width17.5"
depth21"
weight100.0000
warranty10 Years with Online Registration
resources You will need Adobe® Acrobat® Reader to view PDF documents.
safety_informationPROPOSITION 65 WARNING


1.5 Ton 16 SEER Goodman Heat Pump

skuGSZ160181
manufacturerGoodman
cooling_btu18,000
heating_btu18,000
decibel72
energy_starYes
refrigerantR410A
seer16
compressor_stageSingle Stage
compressor_typeScroll
liquid_valve_size3/8"
suction_valve_size3/4"
electrical208 / 230 V. 1 Phase 60 Hz
max_breaker_size20 amps
min_breaker_size12.4 amps
nominal_capacity1.5 Ton
valve_typeSweat
height36"
width29"
depth29"
weight189.0000
warranty10 Years with Online Registration
resources You will need Adobe® Acrobat® Reader to view PDF documents.
safety_informationPROPOSITION 65 WARNING


5 Kilowatt 16,200 BTU Goodman Heater Coil

skuHKSC05XC
manufacturerGoodman
electrical208 / 230 / 240 Volts / Phase 1
max_breaker_size35 amps
min_breaker_size32 amps
weight8.0000
warranty10 Years with Online Registration
resources You will need Adobe® Acrobat® Reader to view PDF documents.
safety_informationPROPOSITION 65 WARNING


8 Kilowatt 23,800 BTU Goodman Heater Coil

skuHKSC08XC
manufacturerGoodman
electrical208 / 230 / 240 Volts / Phase 1
max_breaker_size50 amps
min_breaker_size48 amps
weight9.0000
warranty10 Years with Online Registration
resources You will need Adobe® Acrobat® Reader to view PDF documents.
safety_informationPROPOSITION 65 WARNING


10 Kilowatt 34,100 BTU Goodman Heater Coil

skuHKSC10XC
manufacturerGoodman
electrical208 / 230 / 240 Volts / Phase 1
max_breaker_size60 amps
min_breaker_size57 amps
weight9.0000
warranty10 Years with Online Registration
resources You will need Adobe® Acrobat® Reader to view PDF documents.
safety_informationPROPOSITION 65 WARNING


30 Feet of 3/8" LL x 3/4" SL x 3/8" Insulated Line Set

skuLS38343830
manufacturerGoodman
liquid_line3/8"
suction_line3/4"
suction_line_insulation3/4"
length30 feet
weight35.0000


50 Feet of 3/8" LL x 3/4" SL x 3/8" Insulated Line Set

skuLS38343850
manufacturerGoodman
liquid_line3/8"
suction_line3/4"
suction_line_insulation3/4"
length50 feet
weight22.0000
safety_informationPROPOSITION 65 WARNING
